3. Operations

3-2. LCD Panel

Mute operation
Input & Battery
Voltage Info
Display
Backup time information
Configuration and fault information
Mute operation
Output information
Load information
Programmable outlets information
Mode operation information
10
Battery Info
Mode operation
Info
Function
Indicates the estimated backup time.
H: hours, M: minute, S: second
Indicates the configuration items, and the configuration items are listed in
details in section 3-5.
Indicates the warning and fault codes, and the codes are listed in details in
section 3-7 and 3-8.
Indicates that the UPS alarm is disabled.
Indicates the output voltage and output frequency.
Vac: AC voltage, Vdc: DC voltage, Hz: frequency
Indicates the load level by 0-24%, 25-49%, 50-74% and 75-100%.
Indicates overload.
Indicates the load or the UPS output is short circuit.
Indicates that programmable management outlets are working.
Indicates the UPS connects to the mains.
Indicates the battery is working.
Indicates the bypass circuit is working.
Load Info
Remaining Backup
Programmable
Info
outlet Info
UPO11-1/1.5/2/3 AX Online UPS
User Manual
Output voltage
Info
Fault &Warning
