Warnings And Safety Tips; Specifications; Key Operation Instructions (Under Standby Interface) - ISDT K2 User Manual

Please visit: www.isdt.co for more details on the functions of this smart charger, as well as purchase various accessories.
Functions of products will be kept on upgrading, the manual in your hand may be different from the actual operation,

Warnings and Safety Tips

For your safety and a better user experience, please read this manual and follow the instruction before using the new charger.
• Never use the charger without supervision, please stop using the charger and refer to the manual for reasons if any functional abnormity.
• Keep the charger away from dust, humidity, rain and high temperature, as well as avoid direct exposure to the sunlight and intense
vibration.
• Place the charger on a heat-resisting, non-flammable and insulating surface. Do not use it on the car's seats, carpet or other similar
places. Keep inflammable and explosive objects away from operation areas of the charger.
• Read the instruction manual carefully to be familiar with the features of the charger, and set proper charging parameters before
operating. Setting the parameters incorrectly will result in damage to the product, personal property and cause serious injury as well.
NEVER USE CHARGER UNSUPERVISED
• Never attempt to charge primary (non-rechargeable) batteries.
• Batteries pose a severe risk of fire if not properly handled.
• Read entire operation manual before using charger.
• This unit may emit heat during use.
Specifications
Model No.: K2
Input voltage: AC 100~240V / DC 10~30V
Max. input current: DC 35A
Output voltage: DC 1~30V
Charging current: 0.2~20A ×2
Discharging current: 0.2~1.5A ×2
Balance current: 1.5A/Cell Max
Max. charging power: AC 200W / DC 500W ×2
Max. discharging power: 15W ×2
Supported battery types and cell count: LiFe, LiIon, LiPo, LiHv 1~6S; Pb 1~12S; NiMH/Cd 1~16S

Key operation instructions (under standby interface)

CH1 Menu key: Short press to enter the CH1 detailed parameter interface, long press to enter the CH1 task setting menu.
CH2 Menu key: Short press to enter the CH2 detailed parameter interface, long press to enter the CH2 task setting menu.
Long press the CH1 and CH2 Menu keys at the same time: Enter the advanced settings menu.
Thanks for purchasing the ISDT K2 Smart Charger.
please refer to the actual functions.
• Only operate this device in a cool ventilated area
away from flammable objects.
• Failure to observe safety procedures may cause
damages to property or injury.
Parallel charging power/current: 800W/35A
Parallel discharging power/current: 30W/3A
Abnormal voltage alarm: Support
Incorrect cell count setting alarm: Support
Support Working temperature: 0~40℃
Storage temperature: -20~60℃
Dimension: 142×135×64mm
Weight: About 700g
XBSOJOH"! GJSF!IB[BSE"
