CSL DualCom Pro Series Quick Manual & Instruction Manual page 3

Figure 1 - Diagram
Aerial Connectors
(2nd connector only
available for dual radio
systems)
Remote Module Bus
Dial Capture
Power +ve & -ve
RTN R T
TTL / RS485 / RS232
panel connections
B A R T NO3 C3 NC3
Outputs
2nd Radio Module
(under lid)
NO2 C2 NC2 NO1 C1 NC1 1
1 - 3
3
2 3 4 5 6 7 8
Pins 1-12
Reset Button
LEDs
LAN Connector
9 10 11 12
