CSL DualCom Pro Quick Manual

DualCom Pro Pin Triggering

Step 1 - Put the DualCom Pro on test with the ARC

Step 2 - Mount the DualCom Pro in the panel and connect the aerial provided
Step 3 - Wire panel digi outputs to the DualCom Pro's inputs and connect the FLT relay to
the panel (see figure 1). There are 2 options, wire to a zone or utilise panel's FLT
input (panel dependant)

Step 4 - Apply 12-24v power

Step 5 - Wait 5 minutes whilst your DualCom Pro downloads its configuration
Step 6 - Check LED status. LEDs 1 & 2 should have solid green or flashing lights, whilst
LED 3 should have a solid green light. If showing otherwise please contact
CSL Technical Support on +44 (0) 1895 474 444

Step 7 - Self learn

• Ensure all required pins are in a normal/quiescent state and the panel is in its day
state
• Press and hold the C button until L appears on the display, then release the C
button
• The display will confirm successful operation by displaying 'LEARN OK'

Step 8 - Test available paths to the ARC

• Tap button A until S is shown
• Tap button C to indicate Path Test
• The display will read out PATH TEST
Step 9 - Test all channels to the ARC, confirm test calls and inputs have all been received
correctly
Quick Guide
