Page 1
DualCom Pro 2 Range QUICK GUIDE & INSTRUCTION MANUAL...
Page 2
Always Connected. Always Secure. Always Live. Take control of your connected devices, wherever you are. For more information: t: +44 (0) 1895 474 474 e: sales@csl-group.com visit: www.csl-group.com...
Page 3
Figure 1 - Diagram 2nd Radio Module (under lid) Aerial Connectors (2nd connector only available for dual radio systems) Remote Module Bus Reset Button Dial Capture LEDs Power +ve & -ve LAN Connector RTN R T NO3 Outputs TTL / RS485 / RS232 Pins 1-12 1 - 3 panel connections...
Page 4
Pro 2 downloads its and serial connections configuration You’re good to go! For customisation use the CSL My Base App/Web Portal. For panel configuration instructions see our online guides Need Access to My Base? Have your login details? Scan here to download the App now.
VARIANTS WITH RADIO Use a Signal Analyser (available from the CSL Installer Shop) to determine if enough base stations (2 or more) are available at the site and that they can supply sufficient signal strength (30% and above). This will determine the optimum location for the DualCom’s aerial to be mounted.
Page 6
STEP 3. COMISSIONING On power-up, the DualCom Pro 2 will automatically contact the Gemini Global Platform to perform its commissioning process, which will take up to 5-8 minutes. Once commissioning is complete, LED 3 will go green to indicate that the device is fully commissioned - see figure 2. Figure 2 - Commissioning First time use.
Page 7
PIN TRIGGERING For this operation the device is triggered by removing or applying zero volts to input terminals 1-12. No external pull-up resistors will be required. This is generally achieved via the digital communicator outputs of a control panel. On receiving an input to the pins terminals the unit will signal alarm conditions and will generate the relevant messages and forward them via the Gemini Global Platform to the ARC.
OUTPUTS All 3 outputs can be configured as either N.O or N.C as required. Output 1 is defaulted to indicate a total path fail condition to the control panel. Output 1 can be reconfigured to indicate another path failure type, Output 2 can be configured to indicate a path fail condition or be used as a manual trigger and Output 3 can be used as a manual trigger.
Page 9
TTL-T For RISCO, Eaton, UTC and other panels, please purchase the relevant cable from CSL Live. For other connections or further instructions on Control Panel programming, panel guides can be found by clicking the panel type (after selection) via the My Base App, by scanning the QR code below or visiting the Installer Zone of our website.
Page 10
My Base provides Installers with the ability to manage and configure DualCom Pro 2 devices on a handy App/Web portal. Simply download CSL My Base from your appropriate App store and obtain log-in information from CSL (or the CSL web administrator within your company) to access these great features:...
Page 11
LEDS & TROUBLESHOOTING Figure 9 - Commissioning LEDs As the DualCom Pro 2 powers up for the very first time it will run through a commissioning process. You will need to wait for LEDs 1, 2 & 3 to go green before the unit reboots. LED 1 LED 2 LED 3...
Figure 12 – Simulate Path Fails (testing the system) It is possible to simulate a path fail for the primary and secondary path. Once in the connectivity section, press and hold B to fail the primary path and/or C to fail the secondary path. The path will stay in fail for 15 mins unless you tap B or C again.
Figure 14 - DUALCOM PRO 2 RANGE DigiAir Pro 2 PATH AVAILABLE GRADES WHAT’S IN THE BOX PART NUMBER DigiAir Pro 2, serial cable & small Radio CS.51.R2 aerial DigiAir Pro 2, serial cable, ethernet CS.51.L2 cable DigiAir Pro 2, serial cable, ethernet Wi-Fi cable, Wi-Fi board &...
