- Page 1 DualCom Pro Range QUICK GUIDE & INSTRUCTION MANUAL...
- Page 2 SMart rePorting of aLarMS • Zero Line faiLS • SuPer-faSt inStaLL 2 roaMing 4g SiMS • DuaL Path raDio • reMote 2 MoDuLe • SingLe harDware aLL graDeS www.csl-group.com/pro @CSLGroupLtd © CSL Group CSL DC Pro A4 ad 201910 v17-print.indd 1 24/10/2019 15:08...
- Page 3 Figure 1 - Diagram ENSURE AERIAL/AERIALS ARE INSERTED INTO THE MMCX CONNECTOR WITH THE RED DOT. Additional radio module for GradeShift Pro variant Connection terminal block Aerial Connectors Display Reset Button Ethernet LED LEDs LAN Connector Outputs Remote module PWR +ve & -ve TTL/RS485/RS232 Pins 1-8 Aerial Connectors...
- Page 4 2. Wait 5 minutes Whilst your DualCom Pro downloads its configuration 3. You’re good to go For customisation use CSL Live or the My Base App Don’t have the My Base App? Download via the Play & Apple store...
- Page 5 INTRODUCTION DualCom Pro offers Installers easier, faster installation of professional signalling systems with even greater resilience. It also provides access to CSL Live, our brand new device management portal, as well as the My Base App. Using the onboard serial connections or pin triggering, DualCom Pro is compatible with a wide range of control equipment including systems installed to EN50136 &...
- Page 6 STEP 3. COMISSIONING On power-up, the DualCom Pro will automatically contact the Gemini Global Platform to perform its commissioning process, which will take up to 5-8 minutes. During this time the display will show ‘N’ to indicate it is a new device, followed by ‘C’ as commissioning is in progress and ‘R’ to indicate it is fully commissioned and ready for use.
- Page 7 PIN TRIGGERING For this operation the device is triggered by removing or applying zero volts to input terminals 1-8. No external pull-up resistors will be required. This is generally achieved via the digital communicator outputs of a control panel. The unit will signal alarm conditions and will generate the relevant messages and forward them via the Gemini Global Platform to the ARC.
- Page 8 Your device will come pre-configured without a panel connection (pins only). To enable serial connection to a control panel, go to My Base and select the panel type. Alternatively contact CSL Technical Support via support@csl-group.com or call +44 (0)1895 474444. SERIAL / RS232 / 485 / TTL PANEL CONNECTIONS As standard, the DualCom Pro range is supplied with a serial cable compatible with Honeywell (RS485), Orisec (TTL), Pyronix (RS232) and Texecom (TTL) panels - see Figure 6 for more information.
- Page 9 (cable provided) TTL-T For Risco, Eaton and UTC, please purchase the relevant cable from the CSL Installer shop. For other connections or further instructions on Control Panel programming please review the Panel Guides on the Installer Zone of our website: www.csl-group.com/uk/installer-zone-panel-guides...
- Page 10 My Base provides Installers with the ability to manage and configure DualCom Pro devices using a handy App or Web portal. Simply download CSL My Base from your appropriate App store and obtain log-in information from CSL (or the CSL web administrator within your company) to access the great new features: •...
- Page 11 Figure 9 – Button Configuration HOLD Scrolls up through menu options Scrolls down through menu options Edit selected menu programming settings. When the button is held an ‘_’ (underscore) will Read menu option appear. You can then scroll through the available options...
- Page 12 Where you are using a dual radio variant, it is possible to purchase an additional Radio/Wi-Fi Module Enclosure with in-built aerials. This will enable you to locate the secondary radio module in a different location. Please visit the CSL Installer Shop for more information.
- Page 13 Figure 11 - DUALCOM PRO RANGE DIGIAIR PRO PATH AVAILABLE GRADES WHAT’S IN THE BOX PART NUMBER DigiAir Pro, serial cable & small Radio 4G CS.51.R2 aerial DigiAir Pro, serial cable, Ethernet CS.51.L2 Cable & LAN connector adaptor DigiAir Pro, serial cable, Ethernet Wi-Fi (coming soon) Cable, Wi-Fi board &...
- Page 14 CSL Technical Support: UK Tel: +44 (0)1895 474 444 Ireland Tel: 1800 855 695 Email: support@csl-group.com Hours: 08.30 to 18.00 weekdays, 10.00 to 16.00 Saturday Visit www.csl-group.com for the latest copies of all manuals. CSL1101V3 30032020 PD001101-003 © Copyright CSL Group...
