DualCom Pro
Visonic PowerMaster
Panel Connection – MCM
Manufacturer
Model
Version
Minimum Panel Firmware
Cable required?
Panel Profile
Panel Bus Connection
Technical Notes
Panel Connection Information
Visonic
PowerMaster
Below
MCM version less or equal to V1.05 - Needs SPT version
less or equal to V2.06
MCM version greater or equal to V1.06 - Needs SPT
version greater or equal to V2.07
Standard alarm cable
VISONIC-PMAX/MASTER-MCM
MCM
Reporting of Pro path states to the panel is not supported
via the serial interface. [Please use the Pro Outputs]
** UPDATE ** UK Panel Firmware V3.3.3 (UK only) - All
tested and working fine on SIA & UDL via the DualCom
Pro
CSL1783V2 21082020
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for CSL DualCom Pro Visonic PowerMaster
Summary of Contents for CSL DualCom Pro Visonic PowerMaster
- Page 1 DualCom Pro Visonic PowerMaster Panel Connection – MCM Manufacturer Visonic Model PowerMaster Version Below MCM version less or equal to V1.05 - Needs SPT version less or equal to V2.06 Minimum Panel Firmware MCM version greater or equal to V1.06 - Needs SPT version greater or equal to V2.07 Cable required? Standard alarm cable...
- Page 2 Panel Programming Enable “Installer Access” - Default user code = 1111 > Press the “Unlock Icon” button > Enter “User Code” Enter “Engineer Mode” > Press “OK” > Enter “Installer Code” Enter “Communications Menu” > Press “OK” ...
