Smiths Medical Graseby 1200 Quick Reference Manual

Infusion program setting
The Graseby 1200 infusion pump can be used for consecutive
™
infusions through two different infusion programs. Before setting up
the infusion pump,first install the infusion tubing.
1. In the programming mode, press the Select key until the screen
is changed to the infusion program setting screen
2. To set Infusion Program 1: Use to input the infusion
rate and press to move the cursor to the infusion volume.
Use to input the infusion volume and press
the cursor to the infusion rate for Infusion Program 2.
3. To set Infusion Program 2: Use the same method from Infusion
Program 1 to set the infusion rate and infusion volume for
Infusion Program 2.
4. After the correct infusion program is displayed, press
move the cursor to "OK", then press the Select key to confirm
and save the infusion program setting and return to the main
screen. On the Infusion Program Setting screen, press the
Stop key and then the Select key concurrently to clear the
infusion program.
Note: When infusion programs are applied, the infusion pump
will perform Infusion Program 2 automatically after the end of
Infusion Program 1.
Alarms
If the infusion pump alarms, listen for the beeps and check the
display screen for alarm messages or symbols.
Alarms Tips/reason
The battery capacity
Battery low
is low/infusion pump
could run for 30
3 beeps
minutes more
to move
The battery capacity
Battery depleted
is empty, the infusion
1 beep
pump has stopped
Nearly completed
The infusion is
infusion
about to complete
to
in 3 minutes
3 beeps
The infusion is
Completed
completed, the
infusion
pump will operate
3 beeps
in the KVO rate
Tubing route
The infusion tubing or
occlusion
cannula is blocked
3 beeps
Indicates that the user
has forgotten
Forget to operate
to start the pump
and the pump has
3 beeps
been on stand-by for a
long time
The door isn't closed,
The door
the infusion has
isn't closed
stopped or the
3 beeps
infusion cannot begin
PRODUCT(S) DESCRIBED MAY NOT BE LICENSED OR
AVAILABLE FOR SALE IN CANADA AND OTHER COUNTRIES
Smith Medical
EC Authorized
International
Representative
1500 Eureka Park, Smiths Medical
Lower Pemberton International Ltd.
Ashford Kent, TN25 4BF TN25 4BF, UK
Tel: +44 (0)845 850 0445 Tel: +44 (0) 1233 722100
www.smiths-medical.com
Find your local contact information at:
www.smiths-medical.com/customer-support
Smiths Medical is part of the global technology business Smiths Group plc. Please see
the Instructions for Use/Operator's Manual for a complete listing of the indications,
contraindications, warnings and precautions. Graseby and the Smiths Medical design mark are
trademarks of Smiths Medical. The symbol ® indicates the trademark is registered in the U.S.
Patent and Trademark Office and certain other countries. All other names and marks mentioned
are the trademarks or service marks of their respective owners. ©2017 Smiths Medical.
All rights reserved. IN193909GB-112017
Operation
Press the Mute key ,
connect the pump to an
AC power supply as soon as
possible
Connect the infusion pump
to an AC power supply
immediately
,
Press the Mute key
prepare to stop
the infusion
Press the Stop key to
stop the infusion
Turn off the flow regulator
and press the Stop key
. After the occlusion is
eliminated, open the flow
regulator and press the
Start key to continue the
infusion or start over
Press the Mute key to
silence the alarm and start
the infusion or turn off the
infusion pump
Read the entire Instruction Manual before operating the Graseby™
Press the Stop key
1200 Infusion Pump . Failure to properly follow warnings, cautions
to stop infusion or
and instructions could result in death or serious injury to the patient.
close the door and
repress. Start key The Graseby™ 1200 is a volumetric infusion pump that provides
to continue infusion accurate and reliable infusions at a rate of 1 - 1200 mL/h
Start the pump
MZHCCA-0009
Before starting, the infusion pump must be placed horizontally for
use, and should be placed on a stable surface or attached to an IV
pole. Please keep a safe distance between the infusion pump and the
patient to help prevent the IV pole from falling over onto the patient.
1. Connect the AC power supply plug to the pump
2. Press the Power key
3. The pump switches on and automatically performs a self-check
4. After the self-check, continue installing the infusion tubing if
there isn't an alarm. Make sure the infusion tubing is in good
shape before starting the pump.
Graseby 1200
™
