SFP+ Port

IOM-2Q8SFP+ -200,IOM-2Q8SFP+ and IOM-8SFP+ provide eight SFP+ ports. IOM-P40-300
and SIOM-P40-300 provide twelve SFP+ ports. SIOM-P100D-300 provides twenty SFP+ ports.
SIOM-P100-300 provides eight SFP+ ports. SIOM-P100-260 provides sixteen SFP+ ports.
SFP+ Port Attributes is shown as below:
Attribute Description
Connector SFP+
Frame Format Ethernet_II
Ethernet_SNAP
Negotiation SFP+ optical module
Mode
The following types of SFP+ optical module are supported. The optical modules are available
with LC-type connectors and are all hot-swappable.
SFP+ Optical Module Attributes is shown as below:
Short-haul
Attribute
Multimode
Optical Mod-
ule (850nm)
Connector LC
Fiber Type 50/125μm
multimode
fiber
Maximum 0.3km
Transmission （984.3ft）
50
10Gbps
Description
Short-haul Medium-haul
Multimode Single-mode
Optical Mod- Optical Mod-
ule (850nm) ule (1310nm)
62.5/125μm 9/125μm
multi-mode single-mode
fiber fiber
0.033km 10km
（108.3ft）
Ultra-long
Long-haul
Haul Single-
Single-mode
mode Optical
Optical Mod-
Module
ule (1550nm)
(1550nm)
9/125μm 9/125μm
single-mode single-mode
fiber fiber
40km 80km
