Preface About This Manual Thanks for choosing the network security products from Hillstone Networks. This document is an installation manual for the Hillstone SG-6000 X-Series device to help you install the device properly. This manual includes the following chapters: Introduction...
Page 17: Chapter 1 Product Profile
Designed for ISP, data centers, and large enterprises, the SG-6000-X series has a strong pro- cessing ability of 1Tbps, integrates high performance, reliability and capacity, reduces network complexity, centralizes management, and lowers TCO.
Page 18: Expansion Module Introduction
Switch Module (SWM): SWM connects the expansion slots of the front panel to forward the data. Only SG-6000-X10800, and SG-6000-X9180 support SWM modules. Hillstone provides the following 3 SWM models: SWM-300, and SWM-280. Bypass module: The bypass module can bypass the device.
Page 19: Security Service Module (Ssm)
If a second SCM is installed, it works as a backup SCM. In this case, master SCM and backup SCM are independent of their slots. If the master SCM fails, the backup SCM automatically takes over the work of the master SCM to ensure business continuity. Notes: Do not perform any configuration on the backup SCM.
Page 20: I/O Module (Iom)
I/O Module (IOM) I/O Module (IOM) is a hardware platform card with ports that provides the following functions: Receive data Fast forward data Transfer data to SSM, QSM, or SWM (only SG-6000-X10800, and SG-6000-X9180 support the SWM module) modules. The device should have at least one IOM installed and you can install more to increase the port amount.
Page 21: Configuring An Interface Module
Configuring an Interface Module When an interface module is recognized and functions normally, its ports work the same way as other ports on the device. For more information about port configuration, for example, binding a port to a zone, specifying an IP address, and configuring policy rules, see StoneOS WebUI User Guide .
Page 22: Expansion Modules Compatible With Sg-6000 X Series
(connected to port 0) directly connects to LAN2 (connected to port1), therefore, the device is bypassed. Cable Connection on the Bypass Module Expansion Modules Compatible with SG-6000 X Series Expansion modules compatible with Hillstone SG-6000 X series devices are listed below. Table 2-1 Table: Expansion modules compatible with X series devices Expansion Module Model...
Page 23 Expansion Module Model Device Model SIOM Bypass SIOM- P100D-300 X9180 SCM-280 SSM- QSM- IOM- SIOM-P40- SWM- P100-300 IOM-P40- SIOM-P100- SIOM- P100D-300 X8180 SCM-260 SIOM-P100- IOM-8MM- SCM-D1T- B-260 SIOM- SCM-D2T- P100H-260 X7180 SCM-100 SSM- QSM- IOM- IOM-2SM- 16SFP- SSM- QSM- IOM-2MM- IOM- 4XFP-100 IOM-...
Page 24: Sg-6000-X10800
SG-6000-X10800 Hillstone SG-6000-X10800 chassis is a standard 19-inch chassis that can be installed in a standard cabinet/rack if the cabinet/rack can handle the total weight of all hardware components. Hillstone SG-6000-X10800 consists of twelve general expansion slots (for SSM, IOM, SIOM, or QSM modules), two SWM expansion slots, and two SCM expansion slots.
Page 25 6000-X10800 requires at least two fan trays and three (in the country or region where the stand- ard voltage is 110V, at least six) 220V AC power modules or four -48V DC power modules. SG-6000-X10800 supports the following expansion modules: SCM: SCM-300 SSM:...
Page 26: Hardware Parameters
Relative Humidity 10%-95% (non-condensing) Front Panel Hillstone SG-6000-X10800 front panel consists of twelve general expansion slots, two fan trays, two ESD points, two rack-mounting ears, one air inlet, and several LED indicators (one PWR, one STA, one ALM, one HA, two FANs).
Page 27 Fig: Front View of the SG-6000-X10800 Front Panel Figure 2-2 Preface...
Page 28: Back Panel
Tips: For more information about the FAN LED indicators on the front panel, see Indicators. Back Panel SG-6000-X10800 back panel consists of eight power supply slots (PS0-PS7), two SWM slots (SWM0 and SWM1), and two SCM slots (SCM0 and SCM1), one ESD point, one power switch, one CLR button, two grounding screws, and air outlets.
Page 29: Expansion Modules
Expansion Modules SG-6000-X10800 requires at least one SCM, one SSM, one IOM, and one SWM, or at least one SCM, one SIOM, and one SWM to function normally. SG-6000-X10800 supports the following expansion modules: SCM: SCM-300 SSM: SSM-300 QSM: QSM-300 IOM: IOM-P100-300, IOM-P40-300 SIOM: SIOM-P40-300, SIOM-P100-300,...
Page 30 SCM-300 SCM-300 is compatible with SG-6000-X10800. The 3D diagram and specifications of the SCM- 300 module are shown below. Figure 2-5 Fig: 3D Diagram of the SCM-300 Module Table 2-3 Table: Parameters of the SCM-300 Module Model Parameter Specifications SCM-300 Size (WxDxH 440mm x 215mm (the depth of the lever not included) x 45mm...
Page 31: Clr Button
Model Parameter Specifications 1 STA LED Indicator Every optical port has 1 LINK LED Indicator and 1 ACT LED Indicator CLR Button CLR Button The CLR button of SG-6000-X10800 is in the pinhole of the SCM module. The CLR button is used to reset the device back to the factory default settings.
Page 32 Table: Parameters of the SSM-300 Module Table 2-4 Model Parameter Specifications SSM-300 Size (WxDxH 390mm x 415mm (the depth of the lever not included) x 35mm Weight 5.70kg Port None Memory 128GB Flash Memory 8GB LED Indicator 1 PWR LED Indicator 1 STA LED Indicator QSM-300 QSM-300 is compatible with SG-6000-X10800.
Page 33: Iom-P100-300
Table: Parameters of the QSM-300 Module Table 2-5 Model Parameter Specifications QCM-300 Size (WxDxH 390mm x 415mm (the depth of the lever not included) x 35mm Weight 5.70kg Port None Memory 64GB Flash Memory 8GB LED Indicator 1 PWR LED Indicator 1 STA LED Indicator IOM-P100-300 IOM-P100-300 is compatible with SG-6000-X10800.
Page 34: Iom-P40-300
Table 2-6 Table: Parameters of the IOM-P100-300 Module Model Parametert Specifications IOM-P100- Size (WxDxH 390mm x 415mm (the depth of the lever not included) x 35mm Weight 5.65kg Port 4 QSFP28 ports (100GE) and 8 SFP+ ports (10GE) Memory 32GB Flash Memory 8GB LED Indic- 1 PWR LED Indicators...
Page 35: Siom-P40-300
Table: Parameter of the IOM-P40-300 Module Table 2-7 Model Parameter Specifications IOM-P40-300 Size (WxDxH 390mm x 415mm (the depth of the lever not included) x 35mm Weight 5.65kg Port 12 SFP+ ports (10GE), 2 QSFP+ ports (40GE) Memory 32GB Flash Memory 8GB LED Indicator 1 PWR LED Indicator 1 STA LED Indicator Every optical port has 1 LINK LED Indicator...
Page 36: Siom-P100-300
Table: Parameters of the SIOM-P40-300 Module Table 2-8 Model Parameter Specifications SIOM-P40- Size (WxDxH 390mm x 415mm (the depth of the lever not included) x 35mm Weight 5.65kg Port 2 QSFP+ ports (40GE), 12 SFP+ ports (10GE) Memory 64GB Flash Memory 8GB LED Indicator 1 PWR LED Indicator 1 STA LED Indicator Every optical port has 1 LINK LED Indicator...
Page 37: Siom-P100D-300
Table 2-9 Table: Parameters of the SIOM-P100-300 Module Model Parameter Specifications SIOM-P100- Size (WxDxH 390mm x 415mm (the depth of the lever not included) x 35mm Weight 5.65kg Port 4 QSFP28 ports (100GE), 8 SFP+ ports (10GE) Memory 64GB Flash Memory 8GB LED Indicator 1 PWR LED Indicator 1 STA LED Indicator Every optical port has 1 LINK LED Indicator...
Page 38 Figure 2-10 Fig: 3D Diagram of the SIOM-P100D-300 Module Table 2-10 Table: Parameters of the SIOM-P100D-300 Module Model Parameter Specifications SIOM- Size (WxDxH 390mm x 415mm (the depth of the lever not P100D-300 included) x 35mm Weight 5.65kg Port 2 QSFP28 ports (100GE), 20 SFP+ ports (10GE) Memory 64GB...
Page 39: Led Indicators
SWM-300 SWM-300 is compatible with SG-6000-X10800. The 3D diagram and specifications of the SWM- 300 are shown below. Figure 2-11 Fig: 3D Diagram of the SWM-300 Module Table 2-11 Table: Parameters of the SWM-300 Module Model Parameter Specifications SWM-300 Size (WxDxH 440mm x 215mm (the depth of the lever not included) x 45mm Weight...
Page 40 Color/Status Description Green/Always The system power is functional. Orange/Always The system power is not functional. Red/Always on Power failure so the system is down. The system is powered off or is down. Green/Always The system is booting. Green/Blinking The system is running normally. Red/Always on The system failed to boot or a system exception occurred.
Page 41 Color/Status Description High Availability is disabled. Green/Always The cooling system is working normally. Red/Always on One or more fans have failed. The fan tray is not fully inserted, or a fan circuit exception occurred. LED indicators on the expansion modules Green/Always The link between this port and its peer device is in normal status.
Page 42: Power Supply Module
Color/Status Description module exception occurred. Notes: LED indicators on different expansion modules vary. Please refer to the actual expansion module. Power Supply Module SG-6000-X10800 supports the AC power module and DC power module. You can power the device by installing AC or DC power modules as needed and then connecting them to the cor- responding external power supply.
Page 43: Power Module Diagram
Number of Power Mod- Input Voltage Range of Maximum Output Power Module ules Required for the External Power Sup- Power of the AC Type Normal Device Run- Power Module ning HVDC voltage: 192 ~ 1600W At least 3 288V DC DC power module -36 ~ -72V DC 1100W...
Page 44: Cooling System
Figure 2-13 Fig: DC Power Module Cooling System The cooling system of SG-6000-X10800 consists of two fan trays. The fan trays are horizontally located in the fan slots on the front panel. Each fan tray of SG-6000-X10800 has five fans. Figure 2-14 Fig: Fan Tray of SG-6000-X10800 Preface...
Page 45 The air inlet is at the bottom of the front panel. Air is pushed from the air inlet and then goes through the chassis cage. The air is exhausted out of the air outlet which is at the top of the back panel and the side of the chassis.
Page 46: Port Attributes
Series. SG-6000-X9180 Hillstone SG-6000-X9180 chassis is a standard 19-inch chassis that can be installed in a standard cabinet/rack if the cabinet/rack can handle the total weight of all hardware components. SG-6000-X9180 consists of 6 general expansion slots (for SSM, IOM, SIOM, or QSM modules), two SWM expansion slots, and two SCM expansion slots.
Page 47: Hardware Parameters
SIOM: SIOM-P40-300, SIOM-P100-300, SIOM-P100D-300 SWM: SWM-280 Notes: For SG-6000-X9180, when there is no QSM-300 installed, you can install IOM or SIOM to process QoS (make sure that the device has installed the iQoS license). If you install the IOM to process iQoS, the iQoS does not sup- port the shaping mode.
Page 48: Front Panel
Relative Humidity 10%-95% (non-condensing) Front Panel Hillstone SG-6000-X9180 front panel consists of six general expansion slots, two handles, two rack-mounting ears, two air inlet, one fan tray, one cable rack, one ESD point, and several LED indicators (one PWR, one STA, one ALM, and one HA).
Page 49: Back Panel
Tips: For more information about the FAN LED indicators on the front panel, see Indicators. Back Panel SG-6000-X9180 back panel consists of four power supply slots (PS0-PS3), two SWM slots (SWM0 and SWM1), and two SCM slots (SCM0 and SCM1), one fan tray, one ESD point, one power switch, one CLR button, and two grounding screws.
Page 50: Expansion Modules
Figure 2-19 Fig: Front View of the SG-6000-X9180 Back Panel Expansion Modules SG-6000-X9180 requires at least one SCM, one SSM, one IOM, and one SWM, or at least one SCM, one SIOM, and one SWM to function normally. SG-6000-X9180 supports the following expansion modules: SCM: SCM-280 SSM:...
Page 51 Figure 2-20 Fig: 3D Diagram of the SCM-280 Module Table 2-15 Table: Parameters of the SCM-280 Module Model Parameter Specifications SCM-280 Size (WxDxH ) 300mm x 260mm (the depth of the lever not included) x 45mm Weight 3.40kg Port 1 Console port (CON port) 1 Auxiliary port (AUX port) 1 USB 2.0 Host port 1 Management Port (MGT Port)
Page 52: Clr Button
Model Parameter Specifications CLR Button CLR Button The CLR button of SG-6000-X9180 is in the pinhole of the SCM module. The CLR button is used to reset the device back to the factory default settings. You can restore access to the device with this button if the login password is lost.
Page 53 Table: Parameters of the SSM-300 Module Model Parameter Specifications SSM-300 Size (WxDxH ) 390mm x 415mm (the depth of the lever not included) x 35mm Weight 5.70kg Port None Memory 128GB (DDR4) Flash Memory LED Indicator 1 PWR LED Indicator 1 STA LED Indicator QSM-300 QSM-300 is compatible with SG-6000-X9180.
Page 54: Iom-P100-300
Table: Parameters of the QSM-300 Module Model Parameter Specifications QCM-300 Size (WxDxH ) 390mm x 415mm (the depth of the lever not included) x 35mm Weight 5.70kg Port None Memory 64GB (DDR4) Flash Memory LED Indicator 1 PWR LED Indicator 1 STA LED Indicator IOM-P100-300 IOM-P100-300 is compatible with SG-6000-X9180.
Page 55: Iom-P40-300
Table 2-16 Table: Parameters of the IOM-P100-300 Module Model Parameter Specifications IOM-P100- Size (WxDxH ) 390mm x 415mm (the depth of the lever not included) x 35mm Weight 5.65kg Port 4 QSFP28 ports (100GE) and 8 SFP+ ports (10GE) Memory 32GB Flash Memory LED Indicators...
Page 56 Figure 2-22 Fig: 3D Diagram of the IOM-P40-300 Module Table 2-17 Table: Parameter of the IOM-P40-300 Module Model Parameter Specifications IOM-P40-300 Size (WxDxH ) 390mm x 415mm (the depth of the lever not included) x 35mm Weight 5.65kg Port 12 SFP+ ports (10GE), 2 QSFP+ ports (40GE) Memory 32GB (DDR4)
Page 57: Siom-P40-300
SIOM-P40-300 SIOM-P40-300 is compatible with SG-6000-X9180. The 3D diagram and specifications of the SIOM-P40-300 are shown below. Fig: 3D Diagram of the SIOM-P40-300 Module Table: Parameters of the SIOM-P40-300 Module Model Parameter Specifications SIOM-P40- Size (WxDxH ) 390mm x415mm (the depth of the lever not included) x 35mm Weight 5.65kg...
Page 58: Siom-P100-300
SIOM-P100-300 SIOM-P100-300 is compatible with SG-6000-X9180. The 3D diagram and specifications of the SIOM-P100-300 are shown below. Figure 2-23 Fig: 3D Diagram of the SIOM-P100-300 Module Table: Parameters of the SIOM-P100-300 Module Table 2-18 Model Parameter Specifications SIOM-P100- Size (WxDxH ) 390mm x 415mm (the depth of the lever not included) x 35mm Weight...
Page 59: Siom-P100D-300
SIOM-P100D-300 SIOM-P100D-300 is compatible with SG-6000-X9180. The 3D diagram and specifications of the SIOM-P100D-300 are shown below. Figure 2-24 Fig: 3D Diagram of the SIOM-P100D-300 Module Table 2-19 Table: Parameters of the SIOM-P100D-300 Module Model Parameter Specifications SIOM-P100D- Size (WxDxH ) 390mm x 415mm (the depth of the lever not included) x 35mm Weight...
Page 60 Model Parameter Specifications and 1 ACT LED Indicator SWM-280 SWM-280 is compatible with SG-6000-X9180. The 3D diagram and specifications of the SWM- 280 are shown below. Fig: 3D Diagram of the SWM-280 Module Figure 2-25 Table: Parameters of the SWM-280 Module Table 2-20 Model Parameter...
Page 61: Instructions For Using Ssm/Iom/Qsm/Siom
Instructions for Using SSM/IOM/QSM/SIOM For SG-6000-X9180, consider the following when using SSM/IOM/QSM/SIOM modules: Notes: Mixed use of SIOM module and SSM/IOM/QSM modules is not supported. SG-6000-X9180 devices installed with the SIOM module cannot be down- graded to versions lower than StoneOS 5.5R6P9.9. Otherwise, the SIOM module cannot be recognized by the system.
Page 62 Table 2-21 Table: Description of the SG-6000-X9180 LED Indicators Color/Status Description Green/Always The system power is functional. Orange/Always The system power is not functional. Red/Always on Power failure so the system is down. The system is powered off or is down. Green/Always The system is booting.
Page 63 Color/Status Description Red/Blinking HA function has failed. High Availability is disabled. LED on the fan Green/Always The cooling system is working normally. tray Red/Always on One or more fans have failed. The fan tray is not fully inserted, or a fan circuit exception occurred.
Page 64: Power Supply Module
Color/Status Description Red/Always on The expansion module failed to boot or an expansion module exception occurred. Notes: LED indicators on different expansion modules vary. Please refer to the actual expansion module. Power Supply Module SG-6000-X9180 supports the AC power module and DC power module. You can power the device by installing AC or DC power modules as needed and then connecting them to the cor- responding external power supply.
Page 65: Power Module Diagram
Number of Power Mod- Input Voltage Range of Maximum Output Power Module ules Required for the External Power Sup- Power of the AC Type Normal Device Run- Power Module ning HVDC voltage: 192 ~ 1600W At least 2 288V DC DC power module -36 ~ -72V DC 1100W...
Page 66: Cooling System
Fig: DC Power Module Cooling System The cooling system of SG-6000-X9180 consists of two fan trays. The fan trays are horizontally located in the FAN0 slot on the front panel and the FAN1 slot on the back panel. Each fan tray of SG-6000-X9180 has ten fans. Figure 2-26 Fig: Front Panel Fan Tray of SG-6000-X9180 Preface...
Page 67 Figure 2-27 Fig: Back Panel Fan Tray of SG-6000-X9180 The air inlet is at the top and right side of the front panel. Air is pushed from the air inlet and then goes through the chassis cage. The air is exhausted out of the air outlet which is at the side of the back panel.
Page 68: Port Attributes
Series. SG-6000-X8180 Hillstone SG-6000-X8180 chassis is a standard 19-inch chassis that can be installed in a standard cabinet/rack if the cabinet/rack can handle the total weight of all hardware components. SG-6000-X8180 consists of three general expansion slots (for SIOM and Bypass modules) and two SCM expansion slots.
Page 69: Hardware Parameters
SCM: SCM-260, SCM-D1T-260, SCM-D2T-260 SIOM: SIOM-P100-260 SIOM-P100H-260 Bypass: IOM-8MM-B-260 Notes: SG-6000-X8180 does not support QSM. SG-6000-X8180 can process QoS with SIOM (make sure that the device has installed the iQoS license). In this case, iQoS is the same as the iQoS realized by installing QSM. For more information about the expansion modules, see Expansion Module Introduction.
Page 70: Front Panel
Relative Humidity 10%-95% (non-condensing) Front Panel Hillstone SG-6000-X8180 front panel consists of three general expansion slots, one air inlet, one ESD point, and several LED indicators (one PWR, one STA, one ALM, one HA, PS0, and PS1). Figure 2-29...
Page 71: Back Panel
Back Panel Hillstone SG-6000-X8180 back panel consists of two power supply slots (PS0 and PS1), two SWM slots (SWM0 and SWM1), four fan trays (FAN0-FAN3), and one grounding screw. Fig: 3D Diagram of the SG-6000-X8180 Back Panel Figure 2-31 Fig: Front View of the SG-6000-X8180 Back Panel...
Page 72 SCM-260 SCM-260 is compatible with SG-6000-X8180. The 3D diagram and specifications of the SCM- 260 are shown below. Figure 2-33 Fig: 3D Diagram of the SCM-260 Module Table 2-24 Table: Parameters of the SCM-260 Module Model Parameter Specifications SCM-260 Size (WxDxH ) 163mm x 230mm (the depth of the lever not included) x 40mm Weight...
Page 73: Clr Button
Model Parameter Specifications 1 STA LED Indicator Every optical port has 1 LINK LED Indicator and 1 ACT LED Indicator CLR Button CLR Button The CLR button of SG-6000-X8180 is in the pinhole of the SCM module. The CLR button is used to reset the device back to the factory default settings.
Page 74 Figure 2-34 Fig: 3D Diagram of the SCM-D1T-260 Module Table: Parameters of the SCM-D1T-260 Module Table 2-25 Model Parameter Specifications SCM-D1T-260 Size (WxDxH ) 163mm x 230mm (the depth of the lever not included) x 40mm Weight 1.10kg Port 1 Console port (CON port) 1 USB 2.0 Host port 1 Management Port (MGT Port) 2 HA ports (HA0 and HA1)
Page 75: Scm-D2T-260
Model Parameter Specifications and 1 ACT LED Indicator CLR Button SCM-D2T-260 SCM-D2T-260 is compatible with SG-6000-X8180. The 3D diagram and specifications of the SCM-D2T-260 are shown below. Figure 2-35 Fig: 3D Diagram of the SCM-D2T-260 Module Table: Parameters of the SCM-D2T-260 Module Table 2-26 Model Parameter...
Page 76: Siom-P100-260
Model Parameter Specifications 2 HA ports (HA0 and HA1) Memory 8GB (DDR4) Flash Memory 64GB LED Indicator 1 PWR LED Indicator 1 STA LED Indicator Every optical port has 1 LINK LED Indicator and 1 ACT LED Indicator CLR Button SIOM-P100-260 SIOM-P100-260 is compatible with SG-6000-X8180.
Page 77: Siom-P100H-260
Model Parameter Specifications SIOM-P100- Size (WxDxH ) 434mm x 335mm (the depth of the lever not included) x 35mm Weight 5.60kg Port 2 QSFP28 ports (100GE) 16 SFP+ ports (10GE) Memory 96GB (DDR4) Flash Memory 16GB LED Indicators 1 PWR LED Indicators 1 STA LED Indicators Every optical port has 1 LINK LED Indicator and 1 ACT LED Indicator...
Page 78: Iom-8Mm
Table 2-28 Table: Parameters of the SIOM-P100H-260 Module Model Parameter Specifications SIOM-P100H- Size (WxDxH ) 434mm x 335mm (the depth of the lever not included) x 35mm Weight 5.80kg Port 4 QSFP28 ports (100GE) 16 SFP+ ports (10GE) Memory 96GB (DDR4) Flash Memory 16GB LED Indicators...
Page 79: Instructions For Using Iom-8Mm
Table 2-29 Table: Parameters of the IOM-8MM-B-260 Module Model Parameter Specifications IOM-8MM-B- Size (WxDxH ) 434mm x 335mm ( with the depth of lever included) x 35mm Weight 3.0KG Port 16 LC-type optical ports (supporting multi- mode 10G, 40G, and 100G) INLINE LED Indic- ator Instructions for Using IOM-8MM-B-260...
Page 80: Monitor The Status Of Ports
Monitor the Status of Ports The device enters Bypass state when a specific incident occurs (such as power failure, abnormal operation, and system reboot). The IOM-8MM-B-260 module has four Bypass pairs which can monitor the interfaces on other expansion modules separately. For example, port0' is connected to "interface1"...
Page 81 Color/Status Description Green/Always The system power is functional. Orange/Always The system power is not functional. Red/Always on Power failure so the system is down. The system is powered off or is down. Green/Always The system is booting. Green/Blinking The system is running normally. Red/Always on The system failed to boot or a system exception occurred.
Page 82 Color/Status Description High Availability is disabled. PS0/PS1 Green/Always The power module is working normally. Orange/Blinking The power supply is abnormal. Red/Blinking The power module is inserted without powered on or the power supply is abnormal. The power module is not correctly inserted. LED on the fan Green/Always The cooling system is working normally.
Page 83: Power Supply Module
Color/Status Description failed so the expansion module is down. The expansion module is powered off. Green/Always The expansion module is booting. Green/Blinking The expansion module is running normally. Red/Always on The expansion module failed to boot or an expansion module exception occurred. INLINE Green/Blinking The bypass module is working in the inline mode.
Page 84 Two power modules can be installed in the power expansion slots located on the back panel of the SG-6000-X8180. In addition, power modules are hot-swappable. Table: Parameters of the SG-6000-X8180 Power Module Table 2-31 Number of Power Mod- Input Voltage Range of Maximum Output Power Module ules Required for...
Page 85: Power Module Diagram
If an HVDC power supply is used, connect it to the AC power module. Power Module Diagram The AC power module and DC power module compatible with SG-6000-X8180 are shown below. Fig: AC Power Module (C14 Connector) Figure 2-39 Fig: DC Power Module Figure 2-40 Preface...
Page 86: Cooling System
Cooling System The cooling system of SG-6000-X8180 consists of two fan trays. The fan trays are horizontally located in the fan slots (FAN0, FAN1, FAN2, and FAN3) on the back panel. Each fan tray of SG-6000-X8180 has five fans. Figure 2-41 Fig: Fan Tray of SG-6000-X8180 The air inlet is at the top of the device front panel and the front panel of the expansion modules.
Page 87: Port Attributes
Series. SG-6000-X7180 Hillstone SG-6000-X7180 chassis is a standard 19-inch chassis that can be installed in a standard cabinet/rack if the cabinet/rack can handle the total weight of all hardware components. SG-6000-X7180 consists of ten general expansion slots (for SSM, IOM, or QSM modules) and two SCM expansion slots.
Page 88: Hardware Parameters
QSM: QSM-200, QSM-100 IOM: IOM-16SFP-100 , IOM-4XFP-100, IOM-2Q8SFP+-200, IOM-2Q8SFP+, IOM- 8SFP+ Bypass Modules: IOM-2SM-BE, IOM-2MM-BE Notes: For SG-6000-X7180, when there is no QSM installed, SG-6000-X8180 can process QoS with IOM (make sure that the device has installed the iQoS license). In this case, the iQoS does not support the shaping mode. When is device is installed with both QSM and IOM, QSM takes effect pref- erentially to process iQoS.
Page 89: Front Panel
Relative Humidity 10%-95% (non-condensing) Front Panel Hillstone SG-6000-X7180 front panel consists of six general expansion slots, one power switch, one MGT port (with one LINK LED Indicator and one ACT LED Indicator), three HA ports( each having one LINK LED Indicator and one ACT LED Indicator), two USB ports, one SD...
Page 90: Clr Button
Tips: For more information about the LED indicators on the front panel, see Indicators. CLR Button The CLR button of SG-6000-X7180 is in the pinhole of the front panel. The CLR button is used to reset the device back to the factory default settings. You can restore access to the device with this button if the login password is lost.
Page 91: Back Panel
3. Keep pressing utill the STA and ALM LEDs turn solid red. The system will start to reset itself. 4. When restoring is complete, the system will reboot automatically. Back Panel SG-6000-X7180 back panel consists of four power supply slots (PS0-PS3), four general expan- sion slots, two SCM slots (SCM0 and SCM1), one ESD point, two grounding screws, one fan tray (FAN1), and one LED on the fan tray.
Page 92: Expansion Modules
Expansion Modules SG-6000-X7180 requires at least one SCM, one SSM, and one IOM to function normally. SG-6000-X7180 supports the following expansion modules: SCM: SCM-100 SSM: SSM-200, SSM-100 QSM: QSM-200, QSM-100 IOM: IOM-16SFP-100 , IOM-4XFP-100, IOM-2Q8SFP+-200, IOM-2Q8SFP+, IOM- 8SFP+ Bypass Modules: IOM-2SM-BE, IOM-2MM-BE SCM-100 The 3D diagram and specifications of the SCM-100 module are shown below.
Page 93 Model Parameter Specifications SCM-100 Size Weight 1.1kg Port None Memory 8GB (DDR2) SWAP Pin- hole SYS LED Indicator SSM-200 The 3D diagram and specifications of the SSM-200 module are shown below. Figure 2-48 Fig: 3D Diagram of the SSM-200 Module Table 2-34 Table: Parameters of the SSM-200 Module Preface...
Page 94 Model Parameter Specifications SSM-200 Size Weight 3.5kg Port None Memory 128GB (DDR4) SWAP Pin- hole SYS LED Indicator SSM-100 The 3D diagram and specifications of the SSM-100 module are shown below. Figure 2-49 Fig: 3D Diagram of the SSM-100 Module Table 2-35 Table: Parameters of the SSM-100 Module Preface...
Page 95 Model Parameter Specifications SSM-100 Size Weight 1.3kg Port None Memory 32GB (DDR3) SWAP Pin- hole SYS LED Indicator QSM-200 The 3D diagram and specifications of the QSM-200 module are shown below. Figure 2-50 Fig: 3D Diagram of the QSM-200 Module Table: Parameters of the QSM-200 Module Table 2-36 Preface...
Page 96 Model Parameter Specifications QCM-200 Size Weight 3.5kg Port None Memory 64GB (DDR4) SWAP Pin- hole SYS LED Indicator QSM-100 The 3D diagram and specifications of the QSM-100 module are shown below. Figure 2-51 Fig: 3D Diagram of the QSM-100 Module Table: Parameters of the QSM-100 Module Table 2-37 Preface...
Page 97: Iom-16Sfp-100
Model Parameter Specifications QCM-100 Size Weight 1.3kg Port None Memory 16GB (DDR3) SWAP Pin- hole SYS LED Indicator IOM-16SFP-100 The 3D diagram and specifications of the IOM-16SFP-100 module are shown below. Figure 2-52 Fig: 3D Diagram of the IOM-16SFP-100 Module Table 2-38 Table: Parameters of the IOM-16SFP-100 Module Preface...
Page 98: Iom-4Xfp-100
Model Parameter Specifications IOM-16SFP- Size Weight 1.3kg Port 16 SFP ports Memory 8GB (DDR3) SWAP Pin- hole SYS LED Indicator IOM-4XFP-100 The 3D diagram and specifications of the IOM-4XFP-100 module are shown below. Figure 2-53 Fig: 3D Diagram of the IOM-4XFP-100 Module Table 2-39 Table: Parameters of the IOM-4XFP-100 Module Preface...
Page 99: Iom-2Q8Sfp+-200
Model Parameter Specifications IOM-4XFP- Size Weight 1.2kg Port 4 XFP ports Memory 16GB (DDR3) SWAP Pin- hole SYS LED Indicator IOM-2Q8SFP+-200 The 3D diagram and specifications of the IOM-2Q8SFP+-200 module are shown below. Figure 2-54 Fig: 3D Diagram of the IOM-2Q8SFP+-200 Module Table: Parameters of the IOM-2Q8SFP+-200 Module Table 2-40 Preface...
Page 100: Iom-2Q8Sfp
Model Parameter Specifications IOM- Size 1U, full width 2Q8SFP+- Weight 3.5kg Port 2 QSFP+ ports (40GE ), 8 SFP+ ports (10GE) Memory 64GB (DDR4) SWAP Pin- hole SYS LED Indicator IOM-2Q8SFP+ The 3D diagram and specifications of the IOM-2Q8SFP+ module are shown below. Fig: 3D Diagram of the IOM-2Q8SFP+ Module Figure 2-55 Table 2-41...
Page 101: Iom-8Sfp
Model Parameter Specifications IOM- Size 1U, full width 2Q8SFP+ Weight 3.1kg Port 2 QSFP+ ports (40GE ), 8 SFP+ ports (10GE) Memory 64GB (DDR3) SWAP Pin- hole SYS LED Indicator Notes: IOM-2Q8SFP+ can not be inserted into the Slot7 of SG-6000-X7180. IOM-8SFP+ The 3D diagram and specifications of the IOM-8SFP+ module are shown below.
Page 102: Iom-2Sm-Be/Iom-2Mm-Be
Model Parameter Specifications IOM-8SFP+ Size 1U, full width Weight 2.9kg Port 8 SFP+ ports (10GE) Memory 32GB (DDR3) SWAP Pin- hole SYS LED Indicator Notes: IOM-8SFP+ can not be inserted into the Slot7 of SG-6000-X7180. IOM-2SM-BE/IOM-2MM-BE IOM-2SM-BE is a type of single-mode Bypass module, while IOM-2MM-BE is a type of multi- mode Bypass module.
Page 103: Swap Pinhole
Model Parameter Specifications IOM-2SM-BE Size IOM-2MM- Weight 0.9kg Port 4 LC-type optical ports Memory None SWAP Pin- 1个 hole SYS LED 1个 Indicator SWAP Pinhole SCM, SSM, QSM and IOM support hot-swapping and hot-plugging. SWAP pinhole is located at the front panel of SCM, SSM, QSM, and IOM of SG-6000-X7180. To remove an expansion module without interrupting the system, take the following steps: 1.
Page 104 Color/Status Description Green/Always on The system power is functional. Orange/Always on The system power is not functional. Red/Always on Power failure so the system is down. The system is powered off or is down. Green/Always on The system is booting. Green/Blinking The system is running normally.
Page 105 Color/Status Description Green/Always on SD card has been inserted and is in normal status. Green/Blinking SD card is transmitting data. Red/Always on SD card has been inserted but cannot be read or writ- ten. SD card is not in the slot. Green/Always on The link between this port and its peer device is in nor- mal status.
Page 106 Color/Status Description Red/Always on SCM in the slot SC0 has an error. Green/Blinking SCM in the slot SC1 serves as the master module and is working normally. Orange/Blinking SCM in the slot SC1 serves as backup module and is working normally. Red/Always on SCM in the slot SC1 has an error.
Page 107: Power Supply Module
Color/Status Description INLINE Green/Always on The Bypass module is working in the inline mode. Orange/Always on The Bypass module is working in the bypass mode. The bypass module is not powered and it is in the bypass mode. Notes: LED indicators on different expansion modules vary. Please refer to the actual expansion module.
Page 108 Input Voltage Range Maximum Output Number of Power Modules Power Module of the External Power of the AC Required for Normal Device Type Power Supply Power Module Running want to install the SSM-200, QSM-200 or IOM-2Q8SFP+- 200 module, please install at least 3 AC power modules.
Page 109: Power Module Diagram
For SG-6000-X7180, mixed use of 650W and 850W power modules is not supported. If you want to change all the 650W power modules to the 850W power modules, please contact the Hillstone Network team. If you want to install the 850W power module in SG-6000-X7180 devices, you must upgrade the devices to these versions: StoneOS R4P16.X and...
Page 110: Sd Card Slot
SD Card Slot Hillstone SG-6000-X7180 has an SD slot on the front panel for inserting SD storage card. SD card stores the data of the Network Behavior Control log messages. So far, the highest capacity of SD card for SG-6000-X7180 is 32GB.
Page 111: Cooling System
3. Remove the seal label applied to the SD slot. 4. Push the SD card slightly and it will pop out. Notes: Hillstone recommends 16GB and 32GB Kingston or SanDisk SD cards. To ensure the storage writing speed, the SD card should have a speed of at least Class Cooling System The cooling system of SG-6000-X7180 consists of two fan trays.
Page 112: Port Attributes
Series. Ports of the SG-6000 X Series The ports available for Hillstone SG-6000-X series are Console port, Auxiliary port, MGT port, HA port, USB port, Cooper port, SFP port, SFP+ port, XFP port, QSFP+ port, and QSFP28 port. This section explains the attributes of each port.
Page 113 Device Description X9180 SG-6000- X8180 SG-6000- 4 Combo ports (e0/0 as the MGT port and others as HA X7180 ports) 2 USB 2.0 Host ports SG-6000- 1 SD slot X6180 1 Console port (CON port) 1 Auxiliary port (AUX port) SG-6000- Note: Each Combo port can be used as a cooper port or a X6150...
Page 114 Device Description IOM-P100-300 4 QSFP28 ports (100GE) 8 SFP+ ports (10GE) IOM-P40-300 2 QSFP28 ports (100GE) 12 SFP+ ports (10GE) IOM-16SFP-100 16 SFP ports (1GE) IOM-16SFP-80 IOM-16SFP IOM-4XFP-100 4 XFP ports (10GE) IOM-4XFP-80 IOM-4XFP IOM-2Q8SFP+ -200 2 QSFP+ ports (40GE) IOM-2Q8SFP+ 8 SFP+ ports (10GE) IOM-8SFP+...
Page 115: Console Port
Device Description 16 SFP+ ports (10GE) Bypass Module IOM-2SM-B 4 LC-type optical ports IOM-2SM-BE IOM-2MM-B 4 LC-type optical ports IOM-2MM-BE IOM-8MM-B-260 16 LC-type optical ports No ports Console Port SG-6000 X series and its supported modules provide RS-232C asynchronous serial console ports for you to configure the device.
Page 116: Auxiliary Port (Aux Port)
Attribute Description Transmission Console cable Medium Auxiliary Port (AUX port) SG-6000 X series and its supported modules provide RS-232C asynchronous serial auxiliary ports. The description of auxiliary port attributes is listed below. Table 2-48 Table: Auxiliary Port Attributes Attribute Description Connector RJ-45 Type...
Page 117: Copper Port
Copper Port Hillstone SG-6000 X series supports copper ports. The MGT port of the SCM module supported by SG-6000-X10800/X9180/X8180 is the copper port. Each Combo port on the front panel of SG-6000-X7180/X6180/X6150 includes one copper port. The description of copper port attrib- utes is listed below.
Page 118: 1Ge(Sfp) Transceiver Module
1000Mbps) Full-duplex/Half-duplex Notes: Make sure you use Hillstone transceiver modules for the optical ports on Hill- stone devices. To avoid dust falling into the SFP socket, you should place a rubber dust cap (originally in the accessory box) over the SFP port.
Page 119: 1Ge(Sfp) Copper Sfp Module
-40ºC-85ºC -40ºC-85ºC -10ºC-70ºC -10ºC-70ºC perature Hot-swappable 1GE(SFP) Copper SFP Module To connect devices via the copper SFP module, use the crossover cable or the standard cable. The model of Hillstone copper SFP is TRAN-GC, whose specifications are listed below. Preface...
Page 120: Sfp+ Port
Table 2-52 Table: Specifications of the 1GE(SFP) Copper SFP Module Model TRAN-GC Form Factors Interface Spe- 10/100/1000 BASE-T cification IEEE Standard IEEE 802.3ab Data Rate 1.25Gbps Connector Type RJ-45 Cable Copper cable Max Transmission 0.1km Distance Hot-swappable SFP+ Port The modules supported by SG-6000 X series (IOM-2Q8SFP+ -200, IOM-2Q8SFP+, IOM- 8SFP+, IOM-P40-300, SIOM-P40-300, SIOM-P100-300, SIOM-P100D-300, SIOM-P100-260, SIOM-P100H-260, and SIOM-P100-400) are designed with different numbers of the SFP+ ports.
Page 121: 10Ge(Sfp+) Transceiver Module
With the copper SFP module 1000Mbps Full-duplex Notes: Make sure you use Hillstone transceiver modules for the optical ports on Hill- stone devices. The default data rate of the SFP+ optical port is 10Gbps, which can be back- ward switched to 1Gbps...
Page 122 TRAN- TRAN-SR- TRAN-LR- TRAN-SFP+- Model SFP+- SFP+ SFP+ LX40 LX80 Form Factors SFP+ SFP+ SFP+ SFP+ Interface Specification 10GBase-SR 10GBase-LR 10GBase-ER 10GBase- IEEE Standard IEEE 802.3 IEEE 802.3ae IEEE 802.3ae IEEE Clause 52 802.3- 2008 Clause 52 Dara Rate 10Gbps 10Gbps 10Gbps 10Gbps...
Page 123: Xfp Port
Frame Format Ethernet_II Ethernet_SNAP Negotiation With XFP transceiver module 10Gbps Mode Notes: Make sure you use Hillstone transceiver modules for the optical ports on Hill- stone devices. To avoid dust falling into the XFP socket, you should place a rubber dust Preface...
Page 124: 10Ge(Xfp) Transceiver Module
cap (originally in the accessory box) over the XFP port. 10GE(XFP) Transceiver Module To connect devices via the 10GE(XFP) transceiver modules, use the optical fiber with the LC- type connector. SG-6000 X series supports four Hilltone 10GE(XFP) transceiver modules: TRAN-XFP-SR, TRAN-XFP-LX, TRAN-XFP-LX40, and TRAN-XFP-LX80. All transceiver modules are hot-swappable.
Page 125: Qsfp+ Port
TRAN-XFP- TRAN-XFP- Model TRAN-XFP-SR TRAN-XFP-LR LX40 LX80 (W/mW) Transmit Power -2.8～-1.5 -6.0～-1.0 -1.0～+2.0 0～+4.0 (dBm) Max Receiver Sens- -7.5 -10.3 -11.3 -22.5 itivity (dBm) Overload Power (dBm) Extinction Ratio (dB) Operating Case -5ºC-70ºC -5ºC-75ºC -5ºC-75ºC 0ºC-70ºC Temperature Hot-swappable QSFP+ Port The modules supported by SG-6000 X series (IOM-2Q8SFP+ -200, IOM-2Q8SFP+, IOM-P40- 300, and SIOM-P40-300) are designed with two 40GE(QSFP+) ports.
Page 126: 40Ge(Qsfp+) Transceiver Module
Mode In the 4*10GE working mode 4*10Gbps Notes: Make sure you use Hillstone transceiver modules for the optical ports on Hill- stone devices. To avoid dust falling into the QSFP+ socket, you should place a rubber dust cap (originally in the accessory box) over the QSFP+ port.
Page 127: Qsfp28 Port
TRAN-QSFP+- Model TRAN-SR-QSFP+ TRAN-LR-QSFP+ SWDM4 Fiber Mode 50/125μm 9/125μm 50/125um (SMF/MMF) Max Transmission 0.3km(OM3 Fiber- 10km 0.3km(OM3 Fiber Distance )/0.4km(OM4 Fiber) )/0.4km(OM4 Fiber) Center Wavelength 850nm 1310nm 850nm/880nm/ 910nm/940nm Power dissipation <1.5W <3.5W <3.5W (W/mW) Transmit Power -7.5～+0.5 -7.5～+2.3 -7.5～+3.0 (dBm) Max Receiver Sens- -7.5...
Page 128: 100Ge(Qsfp28) Transceiver Module
40Gbps ceiver module Notes: Make sure you use Hillstone transceiver modules for the optical ports on Hill- stone devices. To avoid dust falling into the QSFP28 socket, you should place a rubber dust cap (originally in the accessory box) over the QSFP28 port.
Page 129 Model TRAN-SR4-QSFP28 TRAN-LR4-QSFP28 Form Factors QSFP28 QSFP28 Interface Specification 100GBASE-SR4 100GBASE-LR4 IEEE Standard IEEE 802.3-2015 CAUI-4 IEEE 802.3bm Dara Rate 100Gbps 100Gbps Connector Type Fiber Mode (SMF/MMF) 50/125μm OM3/OM4 MMF 9/125μm SMF Max Transmission Distance 0.1km(OM4 optical fiber) 10km 0.07km(OM3 optical fiber) Center Wavelength 850nm 1294.53nm–1296.59nm...
Page 130: Optical Ports Features: Interoperability, Backward, Compatibility, And Copper Sfp Com
Optical Ports Features: Interoperability, Backward, Compatibility, and Cop- per SFP Compatibility Hillstone devices support the following five optical ports: the 100GE(QSFP28) optical port, the 40GE(QSFP+) optical port, the 10GE(XFP) optical port, the 10GE(SFP+) optical port, and the 1GE(SFP) optical port. Their default data rates are 100Gbps, 40Gbps, 10Gbps, 10Gbps, and 1000Mbps (or 1Gbps) respectively.
Page 131: Backward Compatibility
Copper SFP Compatibility If an optical port supports a copper SFP module, it provides copper SFP compatibility. The model of Hillstone copper SFP is TRAN-GC. Only the 10GE(SFP+) optical port and the 1GE (SFP) optical port support copper SFP. 10GE(SFP+) Optical Port: The 10GE(SFP+) optical port supports the copper SFP module.
Page 132 switch the data rate to 1Gbps. 1GE(SFP) Optical Port: Supports copper SFP module. You can insert the copper SFP dir- ectly. To restore the default data rate, use the no channel-speed command in the optical port con- figuration mode. Notes: Delete optical port configuration before switching the data rate.
Page 133: Chapter 2 Installation Preparations
Chapter 2 Installation Preparations Introduction This chapter introduces the preparations before installing the device, including the engineer requirements installation site environment requirements, cabinet and rack requirements, and unpacking. This chapter includes the following sections: Installation site environment requirements Cabinet requirements Rack requirements Verifying the parts received Unpacking...
Page 134: Clearness Requirements
Item Requirements Relative Humidity 10%-95%, non-condensing Clearness Requirements It is required that there are no explosive, conductive, magnetic, and corrosive dusts in the install- ation site. The dust concentration requirement in the equipment room is shown as below: Mechanically Active Sub- Unit Concentration stance...
Page 135: Grounding Requirements
Take measures to protect the power system from the interference of the power grid. Separate the protection ground of the device from the grounding device or lighting protection grounding device of the power supply equipment as far as possible. Keep the device away from radio stations, radar, and other high-frequency and high-current devices.
Page 136: Rack Requirements
Ensure that the ventilation of the cabinet itself is sufficient enough to dissipate the thermal output of the device. Ensure that the hot exhaust air will not be recirculated into the chassis. Route and dress all cables to minimize the blockage of airflow to and from the chassis. Rack Requirements The SG-6000X-Series device (except desktop models) can be installed in a 19-inch rack (four- post).
Page 137: Rack Mounting Requirements
Rack Mounting Requirements Make sure the rack is secured to the structure of the building. If the geographical area is subject to earthquakes, bolt the rack to the floor. For maximum stability, you can secure the rack to the ceil- ing brackets.
Page 138 3. There're many tongues in the wooden case. You are suggested to remove the tongues around the bottom of the wooden case. 4. Insert the straight screwdriver into the hole of the tongue from above, and then make the tongue level. Chapter 2 Installation Preparations...
Page 139 Notes: The edges of tongue are sharp and may cause injury. Chapter 2 Installation Preparations...
Page 140 5. After all the tongues around the bottom are straightened, two people are required to lift up the wooden case and remove it. Chapter 2 Installation Preparations...
Page 141 Chapter 2 Installation Preparations...
Page 142 6. Take out the accessory box and EPE. Check the products received with the packing list. 7. Remove baffles and take the device from the base. a. Use the cross screwdriver to remove the total ten screws on the vertical fixed baffles (as shown by number 1) on both sides.
Page 143 Chapter 2 Installation Preparations...
Page 144: Unpacking The Package Of Sg-6000-X9180/X8180/X7180/X6180/X6150
Notes: Do not discard the packing materials which can be used for repacking or transportation. Unpacking the Package of SG-6000-X9180/X8180/X7180/X6180/X6150 SG-6000-X8180 is wrapped in antistatic bags and EPE, and is shipped in cardboard carton. Besides the chassis, the carton also contains two power modules, an accessory box and a simple mounting rail assemblies.
Page 145 3. Cut the packing belts and remove the cover. 4. Take out the hardware components and accessory box, and then remove the foam. 5. Verify the parts received against the packing list. 6. Open the antistatic bag wrapping the chassis. Chapter 2 Installation Preparations...
Page 146 Chapter 2 Installation Preparations...
Page 147: Other Safety Recommendations
When you receive the product, a packing list is included inside the accessory box. Verify the parts and items you received against the packing list. If any part is missing, contact a customer service representative. Hillstone provides different expansion modules and power supply modules in separate individual packages according to your order. Installation Devices/Tools/Cables...
Page 148 Terminal: Configuration terminal (e.g. an ordinary PC). Tools: Cross screwdriver and ESD wrist strap/antistatic gloves. Cables: Power cable, console cable and Ethernet cable. Chapter 2 Installation Preparations...
Page 149: Chapter 3 Installation
Chapter 3 Installation Overview Before installation, prepare the site according to the requirements in Chapter 2 Installation Pre- paration, and use the procedures below to install the device. 1. Perform security check according to Safety Requirements. 2. Install the simple mounting rail assemblies according to Installing Mounting Rail Assemblies.
Page 150: General Safety Warnings
General Safety Warnings The following guidelines apply to any operational situations: Make sure only authorized personnel can perform operations to the device. Keep the area around the device free from dust, fire and humidity. Keep tools and accessories away from places where people might get tripped while walking. Do not wear loose clothes or jewelry, such as earrings and bracelets, as they might be caught in the chassis.
Page 151 ESD Point of SG-6000-X10800 on the Front Panel ESD Point of SG-6000-X9180 on the Front Panel ESD Point of SG-6000-X8180 on the Front Panel Chapter 3 Installation...
Page 152 ESD Point of SG-6000-X7180 on the Front Panel ESD Point of SG-6000-X10800 on the Back Panel Chapter 3 Installation...
Page 153 ESD Point of SG-6000-X9180 on the Back Panel ESD Point of SG-6000-X7180 on the Back Panel Chapter 3 Installation...
Page 154: Fire Safety Requirements
Always use ESD wrist strap which should be directly contact with your skin. Notes: For safety, periodically check the resistance value of the ESD strap. The measurement should be in the range of 1 to 10 Mega ohms. Avoid contact between the chassis and your clothing. ESD voltages from your clothes may harm the hardware components.
Page 155 The mounting ears are used to fix the position of the chassis but cannot bear weight. The simple mounting rail assemblies shipped with the device are used to support the chassis if there is no tray on your rack. The mounting rail assemblies are used for 19-inch racks, with a height of 1U. 1.
Page 156: Installing The Device In A Rack
Installing the Device in a Rack This section describes how to install a device in a rack. A fully configured SG-6000-X10800 weighs approximately 194.0kg, a fully configured SG-6000-X9180 weighs approximately 93.1kg, a fully configured SG-6000-X8180 weighs approximately 36.5kg and a fully configured SG-6000- X7180 weighs approximately 53.0kg.
Page 157: Installing Sg-6000-X10800
Make sure the rack or cabinet is secured to the floor and the site ventilation is adequate for heat dissipation and maintenance. Installing SG-6000-X10800 In order to install the device conveniently, you should remove all parts that can be removed from the chassis and re-install them when the chassis is properly positioned.
Page 158 7. Verify the alignment of the screws. Make sure every two screw pairs are in the same hori- zontal line. 8. Reinstall all removed hardware components back to the proper locations. See Installing Expansion Modules of SG-6000-X10800, Installing an AC/DC Power Module of SG-6000- X10800, and Replacing a Fan Tray of SG-6000-X10800.
Page 159: Installing Sg-6000-X9180
You should use the handles on the chassis side to remove the device to the rack or cabinet. To avoid damaging the chassis, you shouldn’t use the lever of modules to remove the device. Installing SG-6000-X9180 In order to install the device conveniently, you should remove all parts that can be removed from the chassis and re-install them when the chassis is properly positioned.
Page 160 7. Verify the alignment of the screws. Make sure every two screw pairs are in the same hori- zontal line. 8. Take the cable rack and screws out of the accessory box. Position the cable rack on the left rack-mounting ear, and use a cross screwdriver clockwise to tighten the screws. Chapter 3 Installation...
Page 161: Installing Sg-6000-X8180
9. Reinstall all removed hardware components back to the proper locations. See Installing Expansion Modules of SG-6000-X9180, Installing an AC/DC Power Module of SG-6000- X10800/X9180, and Replacing a Fan Tray of SG-6000-X9180. Notes: Before powering on the device, all empty slots should be covered with blank plates.
Page 162 3. Dismantle all the removable components, including power modules, all expansion modules (SCM and SIOM), blank plates and fan trays. For detailed steps of removing the com- ponents, see Chapter 5 Hardware Maintenance and Replacement. 4. Label all the removed parts so that you can reinstall them in the correct location. 5.
Page 163: Installing Sg-6000-X7180
Notes: Before powering on the device, all empty slots should be covered with blank plates. To prevent the equipment damage or personal injury, three people are needed to install the device. To avoid damaging the chassis, you should not use the lever of modules to remove the device.
Page 164 2. Use rack-mounting ear to mark the positions of floating nuts on the front rack posts. 3. Attach rack-mounting ears to the left and right side panels of the chassis respectively. 4. Load the chassis steadily on the center of the lift platform. 5.
Page 165: Installing The Device Without A Lift
7. Verify the installation. Make sure every two screw pairs are in the same horizontal line and the device is stably placed on the plate. Installing the Device without a Lift If you do not use a lift to install the device, you should remove all parts that can be removed from the chassis and re-install them when the chassis is properly positioned.
Page 166: Installing Expansion Modules
5. Move the chassis in front of the rack. 6. With one person standing on each side, lift the chassis onto the tray of the rack or cabinet. 7. Use the screws to attach the left and right brackets to the rack. 8.
Page 167: Installing An Scm/Swm
Cross screwdriver ESD wrist strap Installing an SCM/SWM SG-6000-X10800 supports up to two SCMs and two SWMs. SCM is located in the slot SCM0 and SCM1 of the back panel, and SWM is located in the slot SWM0 and SWM1 of the back panel. The following takes SCM as an example to introduce how to install an SCM or SWM.
Page 168: Installing An Ssm/Iom/Siom/Qsm/Bypass
levers to outside, and slide the expansion module straight into the slot along the guide rail. 6. When the lever head is inserted into the expansion slot, you should rotate the levers to the front of the module and slide the SCM into the slot until you feel resistant. 7.
Page 169 1. Wear an electrostatic discharge (ESD) strap around your bare wrist and connect the strap to an ESD point on the chassis. See Prevention. 2. Take IOM out from its antistatic bag. 3. Identify the slot of IOM. 4. If the slot is covered with a blank plate, loose its screws with a cross screwdriver and remove the plate, see Replacing an Expansion Module.
Page 170: Installing Expansion Modules Of Sg-6000-X9180
8. To install more IOMs, repeat Step 3 to 7. Installing Expansion Modules of SG-6000-X9180 The device requires at least one SCM, one SSM, one IOM and one SWM. Additional expansion modules are added according to your needs. This part includes the following sections: Tools Required Installing an SCM/SWM Installing an SSM/IOM/SIOM/QSM/Bypass...
Page 171: Installing An Ssm/Iom/Siom/Qsm/Bypass
4. If the slot is covered with a blank plate, loose its screws with a cross screwdriver and remove the plate, see Replacing an Expansion Module of SG-6000-X9180. 5. Position the SWM so that its front side faces you. Make sure that the lever is on the left side and the SWM module is plain with the outside edge of the expansion slot.
Page 172 1. Wear an electrostatic discharge (ESD) strap around your bare wrist and connect the strap to an ESD point on the chassis. See Prevention. 2. Take IOM out from its antistatic bag. 3. Identify the slot of IOM. 4. If the slot is covered with a blank plate, loose its screws with a cross screwdriver and remove the plate, see Replacing an Expansion Module of SG-6000-X9180.
Page 173: Installing Expansion Modules Of Sg-6000-X8180
Installing Expansion Modules of SG-6000-X8180 The device requires at least one SCM-260/SCM-D1T-260/SCM-D2T-260 and one SIOM-P100- 260/ SIOM-P100H-260. Additional expansion modules are added according to your needs. This part includes the following sections: Tools Required Installing an SCM Installing an SIOM Tools Required The following tools are required to install an expansion module: Cross screwdriver...
Page 174: Installing An Siom
5. If the slot is covered with a blank plate, loose its screws with a cross screwdriver and remove the plate. 6. Position the SCM module so that its front side faces you. Make sure that the lever is on the left side and the SCM module is plain with the outside edge of the expansion slot.
Page 175: Installing Expansion Modules Of Sg-6000-X7180
4. Face the front panel of the chassis, identify the slot in which the module should be installed. 5. If the slot is covered with a blank plate, loose its screws with a cross screwdriver and remove the plate, see Replacing an Expansion Module of SG-6000-X8180.
Page 176: Tools Required
This part includes the following sections: Tools Required Installing an SCM Installing an SSM Installing a QSM Installing an IOM Installing a Bypass Module Tools Required The following tools are required to install an expansion module: Cross screwdriver ESD wrist strap Installing an SCM The device supports up to two SCMs.
Page 177: Installing An Ssm
5. Position the SCM so that its front side faces you, and slide the SCM into the slot until you feel resistant, as shown below. 6. Tighten the screws on the SCM with a cross screwdriver. Installing an SSM The device requires at least one SSM and it supports up to 10 SSMs. SSM is located in Slot1 to Slot10.
Page 178: Installing A Qsm
5. Position the SSM so that its front side faces you, and slide the SSM into the slot until you feel resistant, as shown below. 6. Tighten the screws on the SSM with a cross screwdriver. 7. To install more SSMs, repeat Step 2 to 6. Notes: When the modules are of half width, you can take the above steps to install them.
Page 179: Installing An Iom
3. Identify the slot of QSM. 4. If the slot is covered with a blank plate, loose its screws with a cross screwdriver and remove the plate. 5. Position the QSM so that its front side faces you, and slide the QSM into the slot until you feel resistant, as shown below.
Page 180 1. Wear an electrostatic discharge (ESD) strap around your bare wrist and connect the strap to an ESD point on the chassis. See Prevention. 2. Take the IOM out of its antistatic bag. 3. Identify the slot of IOM. 4. If the slot is covered with a blank plate, loose its screws with a cross screwdriver and remove the plate.
Page 181: Installing A Bypass Module
Installing a Bypass Module Hillstone SG-6000-X7180 supports two types of bypass module: single-mode bypass module (IOM-2SM-BE) and multi-mode bypass module (IOM-2MM-BE). The bypass module is installed in Slot1 to Slot10. To install a bypass module, take the following steps: 1. Wear an electrostatic discharge (ESD) strap around your bare wrist and connect the strap to an ESD point on the chassis.
Page 182: Tools Required
This part includes the following sections: Tools Required Installing an AC/DC Power Module of SG-6000-X10800/X9180 Installing an AC/DC Power Module of SG-6000-X8180 Installing a Power Module of SG-6000-X7180 Tools Required To install a power module, you need the tools: Cross screwdriver ESD wrist strap Installing an AC/DC Power Module of SG-6000-X10800/X9180 SG-6000-X10800 requires at least three (in the country or region where the standard voltage is...
Page 183: Installing An Ac/Dc Power Module Of Sg-6000-X8180
click of the lock stuck in the chassis. Verify that the panel of the power module is plain with the chassis panel. Installing an AC/DC Power Module of SG-6000-X8180 SG-6000-X8180 requires at least one (in the country or region where the standard voltage is 110V, two are recommended) 220V AC power modules or one -48V DC power modules.
Page 184: Installing A Power Module Of Sg-6000-X7180
1. Make sure the power module will not be powered during the installation process. 2. Wear an electrostatic discharge (ESD) strap around your bare wrist and connect the strap to an ESD point on the chassis. See Prevention. 3. Face the back panel of the chassis. Make the gold finger on the 4.
Page 185: Installing A Dc Power Module
1. Make sure the power module is not connected to any power source and there is no chance it will be powered during the process. 2. Wear an electrostatic discharge (ESD) strap around your bare wrist and connect the strap to an ESD point on the chassis.
Page 186: Connecting Cables
plain with the chassis panel. Connecting Cables This part describes how to connect the grounding wire, power cable, Ethernet cable, optical cable and power cable. Tools Required Cross screwdriver ESD wrist strap Grounding the Chassis To avoid electrostatic discharge, you must correctly connect the chassis to the earth ground by a grounding wire.
Page 187: Grounding The Chassis Of Sg-6000-X8180
To ground the chassis, take the following steps: 1. Wear an electrostatic discharge (ESD) strap around your bare wrist and connect the strap to an ESD point on the chassis. See Prevention. 2. Take the grounding cable out of the accessory box. 3.
Page 188 chassis. To ground the chassis of SG-6000-X8180, take the following steps: 1. Wear an electrostatic discharge (ESD) strap around your bare wrist and connect the strap to an ESD point on the chassis. See Prevention. 2. Take the grounding cable out of the accessory box. 3.
Page 189: Connecting The Console Cable
Connecting the Console Cable The SG-6000-X7180 device provides an RS-232C asynchronous serial console (CON) port, the expansion modules of SG-6000-X10800/X9180/X8180 provides an RS-232C asynchronous serial console (CON) port, through which you can configure the appliance. The console cable is an 8-core shielded cable, which has an RJ-45 connector that can be connected to the Console port of the appliance and a DB-9 (female) connector that can be connected to the serial port of a con- sole terminal.
Page 190: Connecting The Ethernet Fiber Cable
Be careful not to connect the Ethernet port to the wrong ports. Read the label above the port carefully. For electrical Ethernet connection, use crossover cable or straight-through cable. Connecting the Ethernet Fiber Cable Follow the guidelines below when connecting cables to the ports: Be careful not to connect the Ethernet port to the wrong ports.
Page 191: Connecting An Ac Power Cable
For XFP ports, QSFP+ ports, SFP+ ports or QSFP28 ports, insert the XFP, QSFP+, SFP+ or QSFP28 optical module into the corresponding port before connecting the MPO-type or LC-type connector to the module. Keep the followings in mind when connecting fiber cables: The curvature radius should be greater than 10cm.
Page 192: Connecting A Dc Power Cable
To power the appliance with DC power source, use DC power cables to connect the appliance and the external DC power source. You will be provided with DC power cables when buying DC power modules from Hillstone. Notes: Before performing the procedure, ensure that the cable is not connected with any power source and make sure the cables will not be powered on during the process.
Page 193: Connecting The Dc Power Cable Of Sg-6000-X8180
To power the appliance with DC power source, use DC power cables to connect the appliance and the external DC power source. You will be provided with DC power cables when buying DC power modules from Hillstone. Notes: Before performing the procedure, ensure that the cable is not connected with any power source and make sure the cables will not be powered on during the process.
Page 194: Connecting The Dc Power Cable Of Sg-6000-X7180
To power the appliance with DC power source, use DC power cables to connect the appliance and the external DC power source. Hillstone does not provide DC power cables. Notes: Before performing the procedure, ensure that the cable is not connected with any power source and make sure the cables will not be powered on during the process.
Page 195: Powering On/Off The Device
4. Use a DC cable to connect the "+" , "RTN" or "V+" terminal of the appliance to the "+" ter- minal of the power source; use another DC cable to connect the "-" ,"-48V" or "V-" terminal to the “-” terminal of the power source. 5.
Page 196: Powering On/Off Sg-6000-X7180
To power off the device, remove the power cables, and the device will be automatically powered off. Notes: The device requires at least four fan trays , one SCM-260/SCM-D1T- 260/SCM-D2T-260 module and one SIOM -P100-260 module to work normally. Powering On/Off SG-6000-X7180 After connecting the power cable with the device, the device will automatically start.
Page 197: Chapter 4 Boot And Configuration
Chapter 4 Boot and Configuration Introduction This chapter describes how to perform initial system boot and basic configuration of the Hillstone SG-6000 X-Series device, using a PC as the console terminal. Establishing a Configuration Environment The SG-6000 X-Series device supports both local and remote configuration. Administrators can use the following configuration methods.
Page 198 If the booting succeeds, the system will display the command line prompt "login". Enter the default administrator name and password "hillstone" at the "login" and "password" prompts, press Enter. And now you are successfully logged in and accessing the CLI.
Page 199: Webui
2. Launch a Web browser of the management PC, enter the URL https://192.168.1.1 in the address bar, and then press Enter. 3. Type the default administrator name (hillstone) and password (hillstone) into the text boxes respectively. 4. At the first sign of address, you need to read and accept the EULA (End User License Agree- ment).
Page 200 work security designs require different topology designs, working modes, security zones, and policy configurations. The basic configurations may include: Create security zones, including the link layer (L2) and network layer (L3). Bind different interfaces to correct security zones respectively. Assign IP addresses to interfaces. Configure the management functions of the interfaces and create the security policy rules.
Page 201: Chapter 5 Hardware Maintenance And Replacement
Chapter 5 Hardware Maintenance and Replacement Overview This chapter provides information on how to maintain and replace power module, expansion mod- ule and fan tray. General Maintenance For optimum performance, use the following routine maintenance procedures: Inspect the installation site for moisture, temperature and cleanness according to the Site Pre- paration.
Page 202: Replacing A Power Module
Replacing a Power Module SG-6000-X10800 supports (3+1) x2 power module redundancy. If you remove one power mod- ule out of the chassis which has four or more power modules, the system can still work. If you remove one power module from the device with only three power modules left, the system will not work normally.
Page 203: Replacing A Dc Power Module
Notes: If you do not want to install a new module, apply a blank plate over the slot to avoid dust falling into the chassis. Replacing an Expansion Module All expansion modules of SG-6000-X series are hot-swappable. Replacing an Expansion Module of SG-6000-X10800 Replacing an SCM/SWM The following takes SCM as an example to introduce how to install an SCM or SWM.
Page 204: Replacing An Ssm/Iom/Siom/Qsm/Bypass
2. Use a cross screwdriver to loosen SCM screws until they pop out. 3. Rotate the lever to outside till the lever head is out of the expansion slot. 4. Hold the module with one hand and pull it straight out of the expansion slot along the guide rail.
Page 205 1. Wear an electrostatic discharge (ESD) strap around your bare wrist and connect the strap to an ESD point on the chassis. See Prevention. 2. Use a cross screwdriver to loosen IOM screws until they pop out. 3. Rotate the lever to outside till the lever head is out of the expansion slot. 4.
Page 206: Replacing An Expansion Module Of Sg-6000-X9180
Replacing an Expansion Module of SG-6000-X9180 Replacing an SCM/SWM The following takes SWM as an example to introduce how to install an SCM or SWM. To replace an SWM, take the following steps: 1. Wear an electrostatic discharge (ESD) strap around your bare wrist and connect the strap to an ESD point on the chassis.
Page 207: Replacing An Ssm/Iom/Siom/Qsm/Bypass
Notes: If you do not want to install a new module, apply a blank plate over the slot to avoid dust falling into the chassis. Replacing an SSM/IOM/SIOM/QSM/Bypass The following takes IOM as an example to introduce how to install an SSM, IOM, SIOM, QSM or Bypass.
Page 208: Replacing An Expansion Module Of Sg-6000-X8180
Notes: If you do not want to install a new module, apply a blank plate over the slot to avoid dust falling into the chassis. Replacing an Expansion Module of SG-6000-X8180 Replacing an SCM To replace an SCM, take the following steps: 1.
Page 209: Replacing An Siom
Replacing an SIOM To replace an SIOM, take the following steps: 1. Wear an electrostatic discharge (ESD) strap around your bare wrist and connect the strap to an ESD point on the chassis. See Prevention. 2. Use a cross screwdriver to loosen SIOM screws until they pop out. 3.
Page 210: Replacing An Expansion Module Of Sg-6000-X7180
Replacing an Expansion Module of SG-6000-X7180 Replacing an SCM To replace an SCM, take the following steps: 1. Wear an electrostatic discharge (ESD) strap around your bare wrist and connect the strap to an ESD point on the chassis. See Prevention.
Page 211: Replacing A Qsm
1. Wear an electrostatic discharge (ESD) strap around your bare wrist and connect the strap to an ESD point on the chassis. See Prevention. 2. Use a cross screwdriver to loosen SCM screws until they pop out. 3. Hold the screws and pull the SSM straight out of the chassis, as shown below. 4.
Page 212: Replacing An Iom
3. Hold the screws and pull the QSM straight out of the chassis, as shown below. 4. Put the removed module into an antistatic bag or on a flat antistatic table. 5. Install a replacement module (see Installing a QSM). Notes: If you do not want to install a new module, apply a blank plate over the slot to avoid dust falling into the chassis.
Page 213: Replacing A Bypass Module
4. Hold the screws and pull the IOM straight out of the chassis, as shown below. 5. Put the removed module into an antistatic bag or on a flat antistatic table. 6. Install a replacement module (see Installing an IOM). Notes: If you do not want to install a new module, apply a blank plate over the slot to avoid dust falling into the chassis.
Page 214: Replacing The Cooling System Components
The cooling system of SG-6000-X8180 series consists of 4 fan trays. and the cooling system of other SG-6000-X series devices consists of 2 fan trays. Each fan tray of SG-6000-X10800 has 5 fans, each fan tray of SG-6000-X9180 has 10 fans, each fan tray of SG-6000-X8180 has 2 fans, and each fan tray of SG-6000-X7180 has 6 fans and 1 air filter.
Page 215: Replacing A Fan Tray
When the fan tray cannot work normally or has been used for a year, you should change the fan tray. You can buy the fan tray alone from Hillstone. To prevent over-heating, you should install a replacement fan tray immediately after you remove the existing one.
Page 216: Replacing A Fan Tray Of Sg-6000-X9180
4. Grasp the replacement fan tray with the correct direction of FAN logo. Make sure that the fan tray is plain with the outside edge of the fan slot. Press the unlocking button and slide the fan tray into the slot till you feel resistant. Notes: To prevent over-heating, you should install the replacement fan tray within one minute after the existing fan tray is removed.
Page 217 3. Hold the front panel, and slide the front panel to the right. Pull it out from the chassis. 4. Use a cross screwdriver to loosen three screws of the fan tray counter-clockwise until they pop out. 5. Hold the handle of the fan tray and pull it out a little to disconnect it to power. Wait till the fans stop spinning.
Page 218: Replacing A Fan Tray On The Back Panel
6. Grasp the replacement fan tray and make sure that the fan tray is plain with the outside edge of the fan slot. Slide the fan tray into the slot till you feel resistant. Use a cross screwdriver clockwise to tighten three screws of the fan tray. 7.
Page 219: Replacing A Fan Tray Of Sg-6000-X8180
5. Grasp the replacement fan tray with the screws on the right side of your palm. Slide the fan tray into the slot until you feel resistant. 6. Use a cross screwdriver clockwise to tighten two screws on the fan tray. Notes: To prevent over-heating, you should install the replacement fan tray within one minute after the existing fan tray is removed.
Page 220: Replacing A Fan Tray Of Sg-6000-X7180
5. Grasp the replacement fan tray with the screws on the bottom of your palm. Slide the fan tray into the slot until you feel resistant. 6. Tighten the screws on the fan tray. Notes: To prevent over-heating, you should install the replacement fan tray within one minute after the existing fan tray is removed.
Page 221: Replacing A Dustproof Net
5. Grasp the replacement fan tray with the screws on the right side of your palm. Slide the fan tray into the slot until you feel resistant. 6. Tighten the screws on the fan tray. Notes: To prevent over-heating, you should install the replacement fan tray within one minute after the existing fan tray is removed.
Page 222 2. Hold the air inlet, and press the blue button on both sides of the air inlet. Then, pull it out from the chassis. Chapter 5 Hardware Maintenance and Replacement...
Page 223 3. Position the air inlet on the workbench so that the dustproof side faces you. Use a cross screwdriver to loosen four screws until they pop out. 4. Take out the dustproof net from the air inlet. Chapter 5 Hardware Maintenance and Replacement...
Page 224: Replacing A Dustproof Net Of Sg-6000-X9180
5. Put the cleaned or new dustproof net into the air inlet. Hold the air inlet, and press the blue button on both sides of the air inlet. Make sure that the air inlet is plain with the outside edge of the slot. Slide the air inlet straight into the slot till it is fully seated in the chassis slot.
Page 225: Replacing A Dustproof Net Of The Fan Tray
5. Put the new dustproof net into the front panel. Use a cross screwdriver to tighten three screws of the dustproof net. 6. Hold the front panel, and make sure that the two panel is plain with the outside edge of the slot.
Page 226: Replacing An Air Filter Of Sg-6000-X7180
Notes: The dustproof net can be bought alone from Hillstone. You are suggested to back up the dustproof nets (including a dustproof net of the plastic panel and a dustproof net of the fan tray). When the dustproof net which is in use need to be replaced, you can replace it by the backup one.
Page 227 7. Take out the air filter, as shown below. 8. Lay the replacement air filter over the outer mesh properly. 9. Cover the air filter with the inner mesh and tighten the screws removed in Step 5 to secure the meshes and the air filter. 10.
Page 228: Chapter 6 Troubleshooting
Chapter 6 Troubleshooting Introduction This chapter provides solutions to some common problems of the Hillstone SG-6000 X-Series device. Losing the Administrator Password If you lose the administrator password, please contact your local sales representative or you can reset the system to restore its factory password.
Page 229: Troubleshooting The Cooling System
Troubleshooting the Cooling System The cooling system consists of fan trays and an anti-dust mesh.A malfunctioning fan/fan tray or dust-full anti-dust mesh can influence the ventilation through the chassis. When the system is over heated, it will shut itself down. When the cooling system malfunctions, take the following steps to troubleshoot: Use the command show environment to view the chassis temperature and fan spinning speed.
Page 230: Appendix: Supported Versions Of Devices
You can find the production date of the device/module according to the SN. There's 16-digit SN on the Hillstone devices/modules. Among it, the 6th and 7th number mean the production week and the 8th and 9th number mean the production year.
Page 231 Whether the updated Whether Device SN Range IOM-2Q8SFP+- IOM- (Update devices 200/SSM- Device 2Q8SFP+- Device Supported Ver- to the supported 200/QSM-200 is Model 200/SSM- sions versions if SN is used(Produced after 200/QSM- within the range) the 20th week of 200 is Used 2018) Before 5.5R1P10 and later P ver-...
Page 232 Whether the updated Whether Device SN Range IOM-2Q8SFP+- IOM- (Update devices 200/SSM- Device 2Q8SFP+- Device Supported Ver- to the supported 200/QSM-200 is Model 200/SSM- sions versions if SN is used(Produced after 200/QSM- within the range) the 20th week of 200 is Used 2018) sions 5.0R4P5.42 and later P...
Page 233 Whether the updated Whether Device SN Range IOM-2Q8SFP+- IOM- (Update devices 200/SSM- Device 2Q8SFP+- Device Supported Ver- to the supported 200/QSM-200 is Model 200/SSM- sions versions if SN is used(Produced after 200/QSM- within the range) the 20th week of 200 is Used 2018) 5.5R6, 5.5R7) Appendix: Supported Versions of Devices...

This manual is also suitable for:

Sg-6000-x10800 Sg-6000-x9180 Sg6000-x8180 Sg-6000-x7180 Sg-6000-x6180 Sg-6000-x6150

Hillstone SG-6000-X Series Hardware Reference Manual

Chapter 1 Product Profile

Chapter 2 Installation Preparations

Chapter 3 Installation

Chapter 4 Boot and Configuration

Chapter 5 Hardware Maintenance and Replacement

Chapter 6 Troubleshooting

Appendix: Supported Versions of Devices

Quick Links

Troubleshooting

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hillstone SG-6000-X Series

Summary of Contents for Hillstone SG-6000-X Series
