To install the pane, insert its entire left-hand side and
press it against the aluminium section.
Bend the pane and push it over the right-hand edge
of the aluminium section. Due to the pane being
bent, it rests in its position.

10.5 Tubes

By regularly cleaning the tubes you can help pre-
serve their performance.
• When installing the tubes, make sure that the
tube inscription is visible. If it is installed in a
different position, there will be no effect.
• After new tubes have been installed, the
operating hours of the tubes must be reset in
the service menu.
Improper maintenance can cause the
device to be damaged or to become
unusable.
When replacing the tubes, you must also replace
the starters. Replace tubes and starters only against
ones of the same type.
Dismantle the acrylic panes as it is described in the
section "Acrylic panes".
Dismantle the tubes by turning each tube a quarter
turn towards the front or towards the back and then
pulling it out.
Make sure that the inscription on the tubes is visible,
for otherwise, there will be no effect.
When installing new tubes, replace the starters first.
The assembly is carried out in reverse order. Reset
the operating hours counter in the service menu.
