Textron EZGO TXT FLEET Service & Parts Manual page 79

When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
1 76418G01
2 10435G1
3 10194G1
4 00532G6
5 10044G01
6 603109
7 74207G03
8 72618G01
9 00560G1
10 11098G5
11
12 70289G02
13 624030
14 652245
15 00665G9
16 11098G5
17
18 14158G1
19 12262G1
1 2 3 4 5
SHOCK ABSORBER.......................................................................................
SHOCK ABSORBER WASHER ......................................................................
RUBBER BUSHING, 1" ..................................................................................
HEX JAM NUT, 3/8" - 24 .................................................................................
VINYL CAP......................................................................................................
REAR LEAF SPRINGS (REPLACE LEFT & RIGHT SPRINGS
SIMULTANEOUSLY) .......................................................................................
HEAVY DUTY LEAF SPRING.........................................................................
'U' BOLT, 3/8" - 16 X 2" X 2 1/2" LG................................................................
FLAT WASHER, 3/8".......................................................................................
LOCK NUT, 3/8" - 16.......................................................................................
SPLIT STEEL SPACER ..................................................................................
FLANGED BUSHING, 21.5MM.......................................................................
SHACKLE PLATE ...........................................................................................
HEX HEAD BOLT (SS), 3/8" - 16 X 3 1/2" LG ................................................
LOCK NUT, 3/8" - 16.......................................................................................
SHOULDER BOLT, 3/8" - 16 X 3 1/4" LG .......................................................
LOCK NUT, 3/8" - 16.......................................................................................
Service Parts Manual
REAR SUSPENSION
DESCRIPTION QTY.
2
8
8
4
4
2
2
4
8
8
4
12
4
4
4
2
2
Page K-2
