Textron EZGO TXT FLEET Service & Parts Manual page 66

FRONT SUSPENSION AND STEERING
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
1 652822
2
3 70942G03
4 70940G02
5 25146G1
6 11750G2
7 70589G01
8 19862G1
9 12093G1
10 00798G8
11 70648G01
12 70749G01
13 51141G1
14 70673G03
15 70742G02
16
17 602979
18 607925
19
20 14390G2
21 664789
22
23 70876G02
24 70897G02
25 70902G01
26 01069G01
27 70902G02
28 01069G02
29 00734G1
30
Page G-3
1 2 3 4 5
FRONT AXLE ..................................................................................................
SPINDLE AND HUB ASSEMBLY, 4 LUG (PASSENGER SIDE)
(INCLUDES ITEMS 4 - 13)..............................................................................
SPINDLE ASSEMBLY (PASSENGER SIDE) ............................................
GREASE SEAL .........................................................................................
ROLLER BEARING...................................................................................
WHEEL HUB.............................................................................................
LUG BOLT, 1/2" - 20 X 1 3/16" LG ............................................................
CASTELLATED NUT, 1" - 14 ....................................................................
COTTER PIN, 5/32" X 1 3/4" LG...............................................................
FLANGED BEARING ................................................................................
BEARING ..................................................................................................
RACE BEARING .......................................................................................
SPINDLE AND HUB ASSEMBLY, 4 LUG (DRIVER SIDE)
(INCLUDES ITEMS 5 - 13, 15)........................................................................
SPINDLE ASSEMBLY (DRIVER SIDE) ....................................................
STEERING WHEEL.........................................................................................
CLIPBOARD....................................................................................................
LOCK NUT, 5/8" - 18 .......................................................................................
WARNING LABEL (STEERING WHEEL)........................................................
TIE ROD ASSEMBLY (INCLUDES ITEMS 24 - 28) ........................................
THREADED ROD, 24" LG ........................................................................
TIE ROD END (LEFT HAND THREADS) .................................................
JAM NUT, M12 X 1.25 (LEFT HAND THREADS) .....................................
TIE ROD END (RIGHT HAND THREADS) ...............................................
JAM NUT, M12 X 1.25 (RIGHT HAND THREADS)...................................
LOCK NUT, 7/16" - 14 .....................................................................................
Service Parts Manual
DESCRIPTION QTY.
1
1
1
1
2
1
4
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
2
