Textron EZGO TXT FLEET Service & Parts Manual page 77

When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
1 73500G01
2 614209
3 614208
4 620348
5 620347
6 15558G1
7 73050G01
8 624110
9 72763G02
10
11 24261G1
12 00797G2
13 00664G7
14 01110G01
1 2 3 4 5
REAR AXLE ASSEMBLY (INCLUDES ITEMS 2 - 7) ......................................
AXLE SHAFT (PASSENGER SIDE).........................................................
AXLE SHAFT (DRIVER SIDE) .................................................................
DIFFERENTIAL COVER ..........................................................................
RUBBER PLUG........................................................................................
FLANGED BOLT, 5/16" - 18 X 3/4" LG .....................................................
VENT ........................................................................................................
PLUG ..............................................................................................................
SCUFF GUARD ..............................................................................................
SPLINE BUMPER (SEE ELECTRIC MOTOR) ...............................................
HEX HEAD BOLT, 1/4" - 20 X 1 1/4" LG .........................................................
LOCK WASHER, 1/4" ....................................................................................
FLAT WASHER 1/4" .......................................................................................
Service Parts Manual
DESCRIPTION
REAR AXLE
QTY.
1
1
1
1
1
10
1
3
1
1
3
3
3
Page J-2
