Textron EZGO TXT FLEET Service & Parts Manual page 68

FRONT SUSPENSION AND STEERING
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
62
63
64
65
66
67
68
69
70 00464G6
71 01068G01
72 70667G02
73 70667G04
74 00532G7
75 00560G2
76 00734G1
77 70997G01
78 71055G01
79 70758G05
80 00565G8
81 01055G01
82 70610G03
83 28569G01
84 01022G01
85 70607G01
86 70580G01
87 70751G01
88 70888G01
89 15112G1
90 70887G01
91 00879G1
92 01006G01
Page G-5
1 2 3 4 5
HEX HEAD BOLT, 7/16" - 14 X 2 3/4" LG........................................................
HEX HEAD BOLT, 7/16" - 14 X 3 1/2" LG........................................................
SPACER, 1.21"................................................................................................
SPACER (SHORT), 0.69"................................................................................
HEX NUT, 7/16" - 14........................................................................................
FLAT WASHER, 7/16" .....................................................................................
LOCK NUT, 7/16" - 14 .....................................................................................
COVER............................................................................................................
RIVET, 3/16" X 1" LG (ALUMINUM) ................................................................
STEERING COLUMN KIT (INCLUDES ITEMS 80 - 90) .................................
LOCK WASHER, 5/16" .............................................................................
HEX HEAD SCREW, M8 X 1.25 LG .........................................................
STEERING COLUMN ...............................................................................
STEERING COLUMN BUSHING..............................................................
SCREW, #6 - 20 X 5/16" LG .....................................................................
STEERING SHAFT ...................................................................................
INTERMEDIATE SHAFT...........................................................................
RETAINING RING (INTERNAL)................................................................
RETAINING RING (EXTERNAL) ..............................................................
BALL BEARING ........................................................................................
WAVE WASHER .......................................................................................
LOCK WASHER, 3/8"......................................................................................
HEX HEAD BOLT, 3/8" - 16 X 1 1/4" LG..........................................................
Service Parts Manual
DESCRIPTION QTY.
2
1
2
1
1
7
3
1
1
1
1
1
1
1
1
1
1
1
1
1
1
4
4
