Textron EZGO TXT FLEET Service & Parts Manual page 45

When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
94 658825
95 00737G8
96 00739G1
97 652355
98 27137G01
99 14390G10
100 10606G8
101 00645G2
102 00559G5
103 00559G3
104 00565G3
105 00525G5
106 13514G1
107 00642G8
108 14628G1
109 24605G1
110 17618G1
111 612558
112 00532G4
113 629486
114 28082G01
115 15121G1
116 17979G1
117 23061G2
118 23463G1
119 652256
120 11098G9
121 612557
1 2 3 4 5
PUSHNUT, 5/16" ......................................................................................
PHILLIPS FLAT HEAD SCREW, #10 - 24 X 1" LG...................................
RUBBER NUT, #10 - 24 ...........................................................................
BRAKE PEDAL SPACER .........................................................................
CONICAL SPRING ...................................................................................
LOCK NUT, #10 - 24.................................................................................
MICRO SWITCH ......................................................................................
PHILLIPS PAN HEAD SCREW, #6 - 32 X 1 1/4" LG................................
FLAT WASHER, #10 ................................................................................
FLAT WASHER, #6 ..................................................................................
LOCK WASHER, #6 .................................................................................
HEX NUT, #6 - 32 .....................................................................................
PHILLIPS PAN HEAD SCREW WITH LOCK WASHER, #6.....................
FLAT WASHER, 5/16" ..............................................................................
FASTON TAB............................................................................................
WIRE HARNESS, BRAKE LIGHT ............................................................
NYLON CLAMP........................................................................................
COMPENSATOR ASSEMBLY (INCLUDES ITEMS 112 - 121) .......................
HEX NUT, 1/4" -20....................................................................................
HEX NUT, 5/16" - 24.................................................................................
EQUALIZER BRACKET ...........................................................................
FLAT WASHER, 5/16" ..............................................................................
ACCELERATOR ROD BUSHING, 2" LG..................................................
TUBE ........................................................................................................
COMPRESSION SPRING........................................................................
BRAKE YOKE ..........................................................................................
HEX LOCK NUT, 5/16" - 24 ......................................................................
COMPENSATOR ROD LINK....................................................................
Service Parts Manual
DESCRIPTION
BRAKES
QTY.
2
4
2
2
2
2
1
2
2
4
2
2
2
2
2
1
2
1
2
1
1
2
1
1
1
1
1
1
Page D-8
