Textron EZGO TXT FLEET Service & Parts Manual page 13

When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
31 25799G03
32 652824
33
34 27512G01
35 16409G1
36
37 17838G1
38 74432G01
39 12064G6
40
41 10386G3
42
43 10387G3
44
45 00715G2
46 70135G01
1 2 3 4 5
ACCELERATOR PEDAL ASSEMBLY (INCLUDES ITEMS 32 - 35).........
ACCELERATOR PEDAL....................................................................
ACCELERATOR PEDAL PAD............................................................
OVAL RIVET, 3/8" X 15/32" LG ..........................................................
NYLON BUSHING ....................................................................................
PEDAL PIVOT PIN, 4.87" LG ...................................................................
PUSH NUT, 9/32" I.D................................................................................
CLEVIS PIN, 5/16" X 13/16" LG ...............................................................
COTTER PIN, 3/32" X 3/4" LG .................................................................
HEX HEAD FLANGE BOLT, 5/16" - 18 X .8" LG.............................................
PEDAL PIVOT COVER ...................................................................................
Service Parts Manual
DESCRIPTION
ACCELERATOR
QTY.
1
1
1
6
3
1
1
1
1
4
1
Page A-4
