Textron EZGO TXT FLEET Service & Parts Manual page 43

When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
32
33
34 70601G01
35 17838G1
36 20835G1
37 00559G8
38 10387G3
39 70098G01
40 10097G6
41 70587G01
42 71215G01
43 14134G4
44
45 70113G01
46 11027G1
47
48 70080G02
49 00414G6
50 14390G4
51
52
53 612211
54 612189
55 612411
56 612412
57 612413
58 612415
59 612414
60 612416
61
62
1 2 3 4 5
KICK-OFF LINK ..............................................................................................
NYLON BUSHING ..........................................................................................
TEFLON WASHER, 3/8" .................................................................................
FLAT WASHER, 5/16".....................................................................................
COTTER PIN, 3/32" X 3/4" LG........................................................................
KICK-OFF CAM PIVOT...................................................................................
FLANGED BEARING ......................................................................................
KICK-OFF CAM, PARK BRAKE......................................................................
SETSCREW, 1/4" - 20 X 1/2" LG ....................................................................
SPACER, 1.25" LG .........................................................................................
ADJUSTABLE BUMPER.................................................................................
LOCK NUT, 5/16" - 18.....................................................................................
CATCH BRACKET ..........................................................................................
HEX HEAD BOLT, 1/4" - 20 X 3/4" LG ............................................................
LOCK NUT (SS), 1/4" - 20 ..............................................................................
BRAKE ASSEMBLY (DRIVER SIDE) (INCLUDES ITEMS 55 - 60, 63) ..........
BRAKE ASSEMBLY (PASSENGER SIDE) (INCLUDES ITEMS 55 - 60, 64) .
BRAKE SHOE, LEADING ........................................................................
BRAKE SHOE, TRAILING........................................................................
DUST COVER ..........................................................................................
BRAKE SPRING, BOTTOM .....................................................................
BRAKE SPRING, TOP .............................................................................
SHOE CLAMP ..........................................................................................
Service Parts Manual
DESCRIPTION
BRAKES
QTY.
1
2
2
2
2
1
2
1
2
1
1
1
1
2
2
1
1
2
2
1
1
1
2
Page D-6
