When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM
PART NO.
1
624105
2
625886
3
626171
4
626172
5
625884
6
73120G03
7
73120G25
8
73120G06
9
73120G07
10
625885
11
73277G01
12
73328G01
13
01037G02
14
620422
15
24261G1
16
624109
1
2
3
4
5
MOTOR 48V (INCLUDES ITEMS 2 - 10)........................................................
COMMUTATOR END HEAD ....................................................................
ARMATURE..............................................................................................
FRAME AND FIELD ASSEMBLY .............................................................
BRUSH BOX ASSEMBLY ........................................................................
BRUSH SPRING ......................................................................................
BRUSH AND TERMINAL SERVICE KIT ..................................................
RETAINING RING ....................................................................................
BEARING .................................................................................................
COVER.....................................................................................................
RETAINING RING, 1.66" .................................................................................
SPEED SENSOR MAGNET ...........................................................................
PAN HEAD TORX SCREW, #10-32 X 1/2" LG ...............................................
SPEED SENSOR HARNESS .........................................................................
BUMPER SPLINE ...........................................................................................
O-RING, 1 1/2" O.D X 1 3/8" I.D......................................................................
Service Parts Manual
DESCRIPTION
MOTOR
QTY.
1
1
1
1
1
4
1
1
1
1
1
1
1
1
1
1
Page H-2
