• Mixed pairs of ECC and non-ECC modules all function as non-ECC.
• Be sure to install a RIMM in socket 1 first (closest to the processor)
before installing modules in the other sockets.
• The system board supports PC600 and PC800 memory modules.
Riser Board Installation
When installing memory modules using the optional memory riser boards,
observe the following guidelines:
• The memory riser boards must be installed in system board memory
sockets 1 and 2. Memory riser board A must be installed in system
board memory socket 1, and riser board B must be installed in system
board socket 2. System board memory sockets 3 and 4 can either be
empty or contain CRIMMs. Sockets 3 and 4 cannot contain RIMMs
with memory riser boards installed in sockets 1 and 2. See
Board Memory Components" to identify the system board sockets.
• Memory sockets on the riser boards must be upgraded in matched
pairs. In other words, two sockets in a pair must contain modules of
identical capacity, number of components, and speed. See
Riser Board Components" to identify pairs of sockets.
• Not all memory sockets on the memory riser boards need to be
populated: if one or more pairs of memory sockets contain RIMMs,
then the next pair must contain CRIMMs, and the remaining pair(s)
can be empty. For example, if the first and second pairs of memory
sockets on the riser boards contain RIMMs, then the third pair must
contain CRIMMs, and the fourth pair can remain empty.
• Mixed pairs of ECC and non-ECC modules all function as non-ECC.
• The optional memory riser boards only support PC800 memory
modules.

Removing a Memory Module

NOTICE: Before disconnecting a device from the computer, wait 10 to 20
seconds after disconnecting the computer from its electrical outlet. Before
removing a component from the system board, verify that the standby power
light on the system board has turned off. To locate this light, see
Components."
