O p e n i n g t h e C o m p u t e r C o v e r
cover release latch
padlock ring

Closing the Computer Cover

Check all cable connections, especially those that might have come
1
loose during your work. Fold cables out of the way so that they do not
obstruct the computer cover.
Ensure that no tools or extra parts (including screws) are left inside the
2
computer.
Close the computer cover by pivoting the cover down toward the back
3
of the chassis and into position (see the following figure).
NOTE:
As you close the cover, hold the release latch to the left, in its open
position, and then slide the release latch to the right to latch the cover to the
chassis.
