- Page 1 Multi-Touch PCAP Chassis Display 7”~43” User Manual Version 1.1 Document Part No.91521110103P Please read this instructions before operating the device and retain them for future reference.
-
Page 2: Table Of Contents
7"~43" Multitouch PCAP Chassis Display User Manual Contents Contents Preface About This User Manual Chapter 1: Introduction 1.1 Overview ........................9 1.2 Product Features ...................... 9 1.3 Package Contents ....................9 1.4 Product Overview ....................10 1.5 Connector Description .................... 11 1.6 OSD Control Panel .................... -
Page 3: Preface
Preface Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer. Trademark Acknowledgement Brand and product names are trademarks or registered trademarks of their respective owners. Disclaimer We reserve the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. - Page 4 7"~43" Multitouch PCAP Chassis Display User Manual Naming Rule W07LXXX-PCXX/ W07LXXX-PTXX Item Description Panel Type Panel Size LXXX Product Size PC/ PT Mechanical Type (PCAP Chassis) Panel Model Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury.
- Page 5 Safety Information Warning! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis. Avertissement! Toujours débrancher le cordon d’alimentation du chassis lorsque vous travaillez sur celui-ci.
- Page 6 7"~43" Multitouch PCAP Chassis Display User Manual Safety Precautions For your safety carefully read all the safety instructions before using the device. Keep this user manual for future reference. • Always disconnect this equipment from any AC outlet before cleaning. Do not use liquid or spray detergents for cleaning.
-
Page 7: About This User Manual
About This User Manual This User Manual provides information about using the Winmate® Multitouch PCAP Chassis Display. The documentation set provides information for specific user needs, and includes: • Multitouch PCAP Chassis Display User Manual – contains detailed description on how to use the display, its components and features. -
Page 8: Chapter 1: Introduction
7"~43" Multitouch PCAP Chassis Display User Manual Chapter 1: Introduction This chapter gives you product overview, describes features and hardware specification. You will find all accessories that come with the display device in the packing list. Mechanical dimensions and drawings included in this chapter. -
Page 9: Overview
P/N: 94E0190190P3 P/N: 9B0000000418 **Notice: Screw bolts provided by Winmate only to be used to screw the display onto a console from the rear side. If you prefer your own bolts, please make sure to use M4 and 30mm in length. -
Page 10: Product Overview
7"~43" Multitouch PCAP Chassis Display User Manual 1.4 Product Overview This section describes physical appearance of the Multitouch PCAP Chassis Display. Note: Notice that standard input terminals include VGA and HDMI. Your device may be equipped with other input terminals based on your order. Note: Notice that input and output connectors vary by product size and specifications. -
Page 11: Connector Description
1.5 Connector Description Display input and output connectors are located on the bottom side. Item Description Power Jack – Connects computer to source of power. USB for Touch - Connects USB for touch capabilities. VGA (RGB) –Transmits video from a PC to a monitor. Example: A notebook PC to a monitor. -
Page 12: Led Indicators
7"~43" Multitouch PCAP Chassis Display User Manual Type B Icon Function Decrease the value / Select up Increase the value / Select down Power switch Exit / Auto adjustment Enter / Call main OSD menu 1.6.2 LED Indicators LED indicators are located on the OSD control panel on the back side of the display. Description Icon Function... -
Page 13: Chapter 2: Installation
Chapter 2: Installation This chapter provides hardware installation instructions and mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages... -
Page 14: Wiring Requirements
7"~43" Multitouch PCAP Chassis Display User Manual 2.1 Wiring Requirements The following common safety precautions should be observed before installing any electronic device: • Strive to use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must cross make sure the wires are perpendicular at the intersection point. -
Page 15: Cable Mounting Considerations
VESA Mount Chassis Display comes with VESA Mount holes for mounting. Winmate provides VESA mounting kit by request. Installation Instruction: 1. Screw VESA bracket to the fixture (ex. swing arm) with four VESA screws. 2. Place the device on VESA bracket. -
Page 16: Connecting Power
7"~43" Multitouch PCAP Chassis Display User Manual 2.4 Connecting Power This section provides information on how to use connectors on the Multitouch PCAP Chassis Display. Be cautious while working with these modules. Please carefully read the content of this chapter in order to avoid any damages. Installation instruction: 1. -
Page 17: Hdmi Connector
2.5.2 HDMI Connector Plug HDMI signal cable to the HDMI connector on the rear side of PC system, and plug the other end to the monitor. Pin assignment and signal names of HDMI connector Pin № Signal Name Pin № Signal Name HDMI_RX2+ HDMI_RX2-... -
Page 18: Chapter 3: Operating The Device
7"~43" Multitouch PCAP Chassis Display User Manual Chapter 3: Operating the Device In this chapter you will find instructions on how to operate the display. -
Page 19: Osd Menu Navigation
3.2 OSD Menu Navigation OSD Icon Sub-menu Settings Note BRIGHTNESS slider bar Default 50 Use to adjust the screen’s brightness. Range 0 to 100 CONTRAST slider bar Default 50 BRICONTRAST Use to adjust the screen’s contrast. Range 0 to 100 H POSITION slider bar Default 50... -
Page 20: Multi-Touch Screen
7"~43" Multitouch PCAP Chassis Display User Manual OSD Icon Sub-menu Settings Note AUTO SCAN Select and execute Default mode Auto detect the input source ANALOG Select and execute CHANNEL Switch the setting of signal input to Analog mode HDMI Select and execute Switch the setting of signal input to HDMI mode Select and execute Recall the factory default setting... -
Page 21: Troubleshooting Guide
3.4 Troubleshooting Guide If your monitor fails to operate correctly, check the following chart for possible solution before calling for repairs: Condition Check Point • Check if the signal cable is firmly seated in the socket. picture does • Check if the Power is ON at the computer appear •... -
Page 22: Appendix
7"~43" Multitouch PCAP Chassis Display User Manual Appendix This chapter contains additional product information, including troubleshooting guide and frequency table... -
Page 23: Appendix A: Frequency Table
Appendix A: Frequency Table The choice of supported modes depends on the monitor native resolution. Refer to the table below for more information about available input signals. Signal name Vertical Frequency (Hz) HDMI 1.4 ✔ ✔ ✔ 640 x 480 ✔... - Page 24 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © Winmate Inc. All rights reserved.
