- Page 1 P-Cap Full IP65 Type-C Display 7~15” Model No.: W07L100-GST1-C W10L100-GSH2-C R10L100-GST2-C R12L100-GSM2-C R15L600-GSC3-C User Manual Version 1.0 Document Part Number: 91521110102P Please read this instructions before operating the device and retain them for future reference.
-
Page 2: Table Of Contents
Full IP65 Type-C Display (7~15") User Manual Contents Preface ........................... 3 About This User Manual ..................... 7 Chapter 1: Introduction ....................8 1.1 About Full IP65 USB Type-C Display ..............9 1.2 Product Features ....................9 1.3 Package Overview ....................9 1.4 Product Overview .................... -
Page 3: Preface
Preface Preface Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer. Trademark Acknowledgement Brand and product names are trademarks or registered trademarks of their respective owners. - Page 4 Full IP65 Type-C Display (7~15") User Manual Naming Rule W07LXXX-GSXX Item Description Panel Type Panel Size LXXX Product Size Mechanical Type(G-WIN Slim, Full IP65) Panel Model Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury.
- Page 5 Preface Safety Information Warning!/ Avertissement! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis.
- Page 6 Full IP65 Type-C Display (7~15") User Manual Safety Precautions For your safety carefully read all the safety instructions before using the device. Keep this user manual for future reference. Always disconnect this equipment from any AC outlet before cleaning. Do not use liquid or spray detergents for cleaning.
-
Page 7: About This User Manual
Preface About This User Manual This User Manual provides information about using the Winmate® Open Frame Display. The documentation set provides information for specific user needs, and includes: Open Frame Display User Manual – contains detailed description on how to use the display, its components and features. -
Page 8: Chapter 1: Introduction
Full IP65 Type-C Display (7~15") User Manual Chapter 1: Introduction This chapter gives you product overview, describes features and hardware specification. You will find all accessories that come with the display device in the packing list. Mechanical dimensions and drawings included in this chapter. -
Page 9: About Full Ip65 Usb Type-C Display
Full IP65 Type C Display features Projected Capacitive Multi-Touch (P-CAP). These models are full IP 65 dustproof and waterproof 1.2 Product Features Winmate® Full IP65 Type C Display features: 7”, 10.1”, 10.4”, 12.1” and 15” LCD Projected Capacitive Multi-Touch (P-CAP) ... -
Page 10: Product Overview
Full IP65 Type-C Display (7~15") User Manual 1.4 Product Overview This section describes physical appearance of the Full IP65 Type C Display. All dimensions shown in mm. W07L100-GST1-C W10L100-GSH2-C... - Page 11 Chapter 1: Introduction R10L100-GST2-C R12L100-GSM2-C...
-
Page 12: External Connectors
Full IP65 Type-C Display (7~15") User Manual R15L600-GSC3-C 1.5 External Connectors Terminal interfaces are located on the bottom side of the display. Item Description USB 3.1 Type C - Connects external devices and provides power to the monitor. -
Page 13: Physical Buttons And Led Indicators
Chapter 1: Introduction 1.5 Physical Buttons and LED Indicators Physical buttons and LED indicators (OSD Control Panel) located on the rear side of the Display. Physical Buttons DOWN-Press to lower down the volume. UP- Press to increase the volume. ESC/ AUTO- Press to exit the menu. OK/ MENU- Press to confirm the action or to call main OSD menu. -
Page 14: Chapter 2: Installation
Full IP65 Type-C Display (7~15") User Manual Chapter 2: Installation This chapter provides hardware installation instructions and mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages... -
Page 15: Wiring Requirements
Chapter 2: Installation 2.1 Wiring Requirements The following common safety precautions should be observed before installing any electronic device: Strive to use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must cross make sure the wires are perpendicular at the intersection point. -
Page 16: Mounting Guide
Full IP65 Type-C Display (7~15") User Manual 2.2 Mounting Guide The Open Frame Display can be applied for several different installation methods, including panel mounting, bracket mounting, VESA mounting. Refer to sub-sections below for more details. Caution/ Attention Follow mounting instructions and use recommended mounting hardware to avoid the risk of injury. -
Page 17: Vesa Mount
1. Use Philips M4x5 screws to fix the desk stand to VESA holes on the back cover of the device. 2. Follow instructions that come with VESA mount kit (Not supplied by Winmate). *The picture is for demonstration purposes only. VESA Mount accessories are not supplied by Winmate. -
Page 18: Connecting Peripherals
Full IP65 Type-C Display (7~15") User Manual 2.2 Connecting Peripherals This Display comes with USB Type-C interface located on the bottom panel. The connector comes with protective cap. To ensure the waterproof function can work properly, make sure that the protective caps and have been securely tightened whenever the connectors are not used. -
Page 19: Usb Type-C Connector Description
Chapter 2: Installation 2.3.1 USB Type-C Connector Description The Display features M12 type USB 3.1 Type-C connector with protective cap and full IP67 rating. USB Type-C connector supports Alt mode and transmits power, video and sound. Pin Assignment and signal names for USB 3.1 Type-C connector Signal Name Signal Name TX1+... -
Page 20: Chapter 3: Operating The Device
Full IP65 Type-C Display (7~15") User Manual Chapter 3: Operating the Device In this chapter you will find instructions on how to operate the display. -
Page 21: Turning On/ Off The System
Chapter 3: Operating the Device 3.1 Turning on/ off the System To turn on the system: 1. Connect USB Type-C cable to the connector of your device. Make sure the cable fits to the connector, then tighten the O-ring (by turning clockwise) to secure the connection. 2. - Page 22 Full IP65 Type-C Display (7~15") User Manual GAMMA OSD Icon Sub-menu Settings Note Default GAMMA 0 Select and execute GAMMA0 Choose the parameter of GAMMA 0 as default setting. GAMMA 1 Select and execute Choose the parameter of GAMMA 1 as default setting. GAMMA 2 Select and execute Choose the parameter of GAMMA 2 as default setting.
-
Page 23: Troubleshooting Guide
Chapter 3: Operating the Device 3.3 Troubleshooting Guide If your monitor fails to operate correctly, check the following chart for possible solution before calling for repairs: Condition Check Point • Check if the signal cable is firmly seated in the socket. •... -
Page 24: Appendix
Full IP65 Type-C Display (7~15") User Manual Appendix This chapter contains additional product information, including troubleshooting guide and frequency table... -
Page 25: Appendix A: Hardware Specifications
Appendix Appendix A: Hardware Specifications Model Name W07L100- W10L100- R10L100- R12L100- R15L600- GST1-C GSH2-C GST2-C GSM2-C GSC3-C Display 10.1” 10.4” 12.1” TFT 15” TFT Size/Type 7" TFT (Wide) TFT(Wide) Resolution 1024 x 600 1280 x 800 1024 x 768 1024 x 768 1024 x 768 Brightness 320 nits... -
Page 26: Appendix B: Frequency Table
For more information about available input signals and OSD navigation, please refer to R6C AD Board Manual included in the package. You can also download R6C AD Board Manual from Winmate Download Center. Appendix D: Cleaning the Monitor Before cleaning: ... - Page 27 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © Winmate Inc. All rights reserved.
