R15L600-GSC3(HB) Quick Start Guide V1.1 For more information on this and other Winmate products, please visit our website at: www.winmate.com Document Part Number: 91521110100Q Please read these instructions carefully before using this product, and save this manual for future use...
Contents 1 INTRODUCTION - 8 - 1.1 Features - 8 - 1.2 Package Contents - 9 - 1.3 Description of Parts - 10 - 1.4 Physical Buttons and LED Indicators - 15 - 2 GETTING STARTED - 17 - 2.1 Turning On Your Device - 17 - 2.2 Turning Off Your Device - 18 -...
Page 3
FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a class "B"...
Page 4
European Union Electromagnetic Compatibility Directive (2014/30/EU) EN55024: 2010/ A1: 2015 o IEC61000-4-2: 2009 o IEC61000-4-3: 2006+A1: 2007+A2: 2010 o IEC61000-4-4: 2012 o IEC61000-4-5: 2014 o IEC61000-4-6: 2014 o IEC61000-4-8: 2010 o IEC61000-4-11: 2004 EN55032: 2012/AC:2013 EN61000-3-2:2014 EN61000-3-3:2013 Low Voltage Directive (2014/35/EU) ...
Page 5
Brand and product names are trademarks or registered trademarks of their respective owners. Disclaimer Winmate Inc. reserve the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. We...
Page 6
Customer Service We provide a service guide for any problem by the following steps: First, visit the website of our distributor to find the update information about the product. Second, contact with your distributor, sales representative, or our customer service center for technical support if you need additional assistance.
Page 7
Safety Information WARNING! / AVERTISSEMENT! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis.
1 INTRODUCTION Congratulations on purchasing Winmate® G-WIN Slim IP65 P-CAP Display. The elegantly designed, yet rugged, industrial grade G-WIN S65 series is designed for usability with brilliant true-flat screens, which offer superior readability and Projected Capacitive Multi-Touch (P-CAP) technology, available in 7”, 10.1”, 10.4”, 12.1” and 15”...
1.2 Package Contents Carefully remove the box and unpack your device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Standard factory shipment list: AC Adapter Quick Start Guide (For 7”...
1.3 Description of Parts W07L100-GSO1 Unit: mm Dimensions: 189.4 x 145.4 x 39.8 № Description № Description USB for Touch (M12 Type) ① 12V DC (M12 Type) ③ *Only for touch ② VGA (M12 Type) ④ OSD Control Panel - 10 -...
Page 11
W10L100-GSH1(HB) Unit: mm Dimensions: 263.28 x 173.6 x 40.2 № Description № Description USB for Touch (M12 Type) ① 12V DC (M12 Type) ③ *Only for touch ② VGA (M12 Type) ④ OSD Control Panel - 11 -...
Page 12
R10L100-GST2 Unit: mm Dimensions: 252.61 x 198 x 36.4 № Description № Description USB for Touch (M12 Type) ① 12V DC (M12 Type) ③ *Only for touch ② VGA (M12 Type) ④ OSD Control Panel - 12 -...
Page 13
R12L100-GSM2(HB) Unit: mm Dimensions: 296.2 x 226.7 x 45.5 № Description № Description USB for Touch (M12 Type) ① 12V DC (M12 Type) ③ *Only for touch ② VGA (M12 Type) ④ OSD Control Panel - 13 -...
Page 14
R15L600-GSC3(HB) Unit: mm Dimensions: 363.4 x 277.86 x 45.2 № Description № Description USB for Touch (M12 Type) ① 12V DC (M12 Type) ③ *Only for touch ② VGA (M12 Type) ④ OSD Control Panel - 14 -...
1.4 Physical Buttons and LED Indicators Physical buttons and LED indicators (OSD Control Panel) located on the rear side of the Display. Physical Buttons Icon Button Description DOWN/ VOLUME Press to lower down the volume DOWN UP/ VOLUME Press to increase the volume ESC/ AUTO Press to exit the menu Press to confirm the action or to...
Page 16
LED Indicators LED Type Status Description Power is on Power is off Storage activity Blinking (Data is being read or written) System is idle - 16 -...
2 GETTING STARTED 2.1 Turning On Your Device 1. Remove the protective cap of the power connector. 2. Connect power cable to the connector of your device. Make sure the cable fits to the connector, then tighten the O-ring (by turning clockwise) to secure the connection.
3 INSTALLATION 3.1 Wiring Requirements The following common safety precautions should be observed before installing any electronic device: Strive to use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must cross make sure the wires are perpendicular at the intersection point.
3.2 Connecting to Other Devices This Display comes with various interfaces located on the bottom panel. All of these connectors have been shipped with protective caps. To ensure the waterproof function can work properly, make sure that the protective caps and have been securely tightened whenever the connectors are not used.
3.3 Connector Description The Display features M12 type connectors with protective cap and has full IP65 rating. 3.3.1 Power Input Connector Display has M12 type 3 pin male power input connector. Use IP65 power cable to connect the Display to the source of power. - 21 -...
100x100 mm Mounting Instruction Use Philips M4x5 screws to fix the desk stand to VESA holes on the back cover of the device. *The picture is for demonstration purposes only. VESA Mounting accessories are not supplied by Winmate. - 25 -...
4.2 Panel Mounting Panel Mount mounting solutions is suitable for many applications where Display should be embedded. With this mounting solution flat surface leave no bezel in the front. Size Wall Cutout, mm Screw Hole Diameter, mm 7” 174.4 x 130.4 M4x4 10.1”...
5 SPECIFICATIONS Hardware Specifications Model Name W07L100- W10L100- R10L100- R12L100- R15L600- GSO1 GSH1(HB) GST2 GSM2(HB) GSC3(HB) Display 10.1” TFT 7" TFT 10.4” 12.1” TFT 15” TFT Size/Type (Wide) (Wide) Resolution 1024 x 600 1024 x 600 1024 x 768 1024 x 768 1024 x 768 420 nits 350 nits...
Page 28
Power VESA DPMS Compliant Management Plug & Play Mechanical Specifications Mounting VESA Mount, Panel Mount Environment Considerations Operating -15°C to +55°C Temperature Operating 30% to 90% (non-condensing) Humidity IP Rating Full IP65 Shock 30g for 18 ms, 300 Operating Vibration 1.60/1.96/2.18 g rms for XYZ/ 5-500Hz Operating Standards and Certification...
APPENDIX Appendix A: Cleaning the Monitor Before cleaning: Make sure the device is turned off. Disconnect the power cable from any AC outlet. When cleaning: Never spray or pour any liquid directly on the screen or case. ...
1920 x 1200 For more information about available input signals and OSD navigation, please refer to R-Series AD Board Manual included in the package. You can also download R - Series AD Board Manual from Winmate Download Center. Click here to download R - Series AD Board Manual.
