Page 1
Transflective Open Frame Display 8.4”~32” User Manual Version 1.2 Document Part Number: 91521110103G Please read this instructions before operating the device and retain them for future reference.
Preface Preface Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer. Trademark Acknowledgement Brand and product names are trademarks or registered trademarks of their respective owners.
Page 4
8.4"~32" Transflective Open Frame Display User Manual Naming Rule R10LXXX-OFXXTR Item Description Panel Type Panel Size LXXX Product Size Mechanical Type(Open Frame) Panel Model Transflective Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury.
Page 5
Preface Safety Information Warning! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis.
Page 6
8.4"~32" Transflective Open Frame Display User Manual Safety Precautions For your safety carefully read all the safety instructions before using the device. Keep this user manual for future reference. • Always disconnect this equipment from any AC outlet before cleaning. Do not use liquid or spray detergents for cleaning.
About This User Manual About This User Manual This User Manual provides information about using the Winmate® Transflective Open Frame Display. The documentation set provides information for specific user needs, and includes: • Transflective Open Frame Display User Manual – contains detailed description on how to use the display, its components and features.
8.4"~32" Transflective Open Frame Display User Manual Chapter 1: Introduction This chapter gives you product overview, describes features and hardware specification. You will find all accessories that come with the display device in the packing list. Mechanical dimensions and drawings included in this chapter.
P/N: 94E0190190P3 P/N: 9B0000000418 *Notice: Screw bolts provided by Winmate only to be used to screw the display onto a console from the rear side. If you prefer your own bolts, please make sure to use M4 and 30mm in length.
8.4"~32" Transflective Open Frame Display User Manual 1.4 Product Overview This section describes physical appearance of the Transflective Open Frame Display. Note: Notice that standard input terminals include VGA and HDMI. Your device may be equipped with other input terminal based on your order. Note: Notice that input and output connectors vary by product size and specifications.
0BChapter 1: Introduction Connectors Display input and output connectors are located on the bottom side. Item Description Power Jack – Connects computer to source of power. USB for Touch - Connects USB for touch capabilities. VGA (RGB) –Transmits video from a PC to a monitor. Example: A notebook PC to a monitor.
8.4"~32" Transflective Open Frame Display User Manual Type B Icon Function Decrease the value / Select up Increase the value / Select down Power switch Exit / Auto adjustment Enter / Call main OSD menu 1.5.2 LED Indicators LED indicators are located on the OSD control panel the rear side of the display. Description Icon Function...
1BChapter 2: Installation Chapter 2: Installation This chapter provides hardware installation instructions and mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages...
8.4"~32" Transflective Open Frame Display User Manual 2.1 Wiring Requirements The following common safety precautions should be observed before installing any electronic device: • Strive to use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must cross make sure the wires are perpendicular at the intersection point.
The Open Frame Display comes with clamp mounts that enable you to install the unit onto a wall (where space has been cut out to accommodate the rest of the hardware). Winmate provides VESA and wall mount kits by request.
The Open Frame Display comes with VESA mount holes for mounting. Installation Instruction: 1. Screw VESA bracket to the fixture (ex. swing arm) with four VESA screws. 2. Place the device on VESA bracket. Notice that VESA stand and mounting kit are not provided by Winmate.
1BChapter 2: Installation 2.3 Cable Mounting Considerations For a nice look and safe installation, make sure cables are neatly hidden behind the device. Caution Observe all local installation requirements for connection cable type and protection level. Attention Suivre tous les règlements locaux d’installations, de câblage et niveaux de protection.
8.4"~32" Transflective Open Frame Display User Manual 2.5 Connecting Peripherals The panel control port is designed for monitors that work with a variety of compatible video sources. Due to the possible deviations between these signal sources, you may have to make adjustments to the monitor settings from the OSD menu when switching between these sources.
8.4"~32" Transflective Open Frame Display User Manual 3.1 Turning on the System To turn on the system: 1. Connect the power adapter cable to the DC IN of the display. 2. Connect the power cord to the power adapter. 3. Connect the power cord to a power outlet. 4.
2BChapter 3: Operating the Device 3.2 OSD Menu Navigation OSD Icon Sub-menu Settings Note BRIGHTNESS slider bar Default 50 Use to adjust the screen’s brightness. Range 0 to 100 CONTRAST slider bar Default 50 BRICONTRAST Use to adjust the screen’s contrast. Range 0 to 100 H POSITION slider bar Default 50...
Page 22
8.4"~32" Transflective Open Frame Display User Manual OSD Icon Sub-menu Settings Note AUTO SCAN Select and execute Default mode Auto detect the input source ANALOG Select and execute Switch the setting of signal input to Analog mode CHANNEL HDMI Select and execute Switch the setting of signal input to HDMI mode Select and execute Recall the factory default setting...
2BChapter 3: Operating the Device 3.4 Troubleshooting Guide If your monitor fails to operate correctly, check the following chart for possible solution before calling for repairs: Condition Check Point • Check if the signal cable is firmly seated in the socket. The picture does not •...
8.4"~32" Transflective Open Frame Display User Manual Appendix This chapter contains additional product information, including troubleshooting guide and frequency table...
3BAppendix Appendix A: Frequency Table The choice of supported modes depends on the monitor native resolution. Refer to the table below for more information about available input signals. Vertical Frequency Signal name HDMI 1.4 (Hz) ✔ ✔ ✔ 640 x 480 ✔...
