DEMO MANUAL DC2461A

pArts list

ITEM QTY REFERENCE
Required Circuit Components
1 2 C1, C3
2 2 C2, C4
3 1 C5
4 4 E1 TO E4
5 3 J1 TO J3
6 1 T1
7 1 U1
4
PART DESCRIPTION
CAP , 0.15pF, 100V, ±0.01pF, 0402
CAP , 22pF, C0G, 50V, 5%, 0402
CAP , 1µF, X7R, 10V, 10%, 0603
TEST POINT, TURRET, 0.061" MTG HOLE
CONN, SMA 50Ω EDGE-LAUNCH
TRANS, MINI-CIRCUITS 4.5MHz TO 3000MHz
IC LTC5548IUDB, QFN 12 PIN, 3mm × 2mm
MANUFACTURER/PART NUMBER
AVX, 04021JR15ZBS
AVX, 04025A220JAT2A
AVX, 0603ZD105KAT2A
MILL-MAX, 2308-2-00-80-00-00-07-0
E F JOHNSON, 142-0701-851
MINI-CIRCUITS TC1-1-13M+
LINEAR TECHNOLOGY CORPORATION, LTC5548IUDB#PBF
dc2461af
