Zcom SP230 Series User Manual page 48

SP230/SP230-S5
The following parameters are available in this section:
Parameter
Status
Protocol support is not
installed
Local/Peer IPv6 address
Tunnel address
IPv4 netmask
The following parameters are available in this section:
Parameter
Bring up on boot
Use MTU on tunnel
2x2 PtP/PtMP 802.11ac Wave 2 Outdoor Access Point
Description
Displays basic status information of the interface.
• Port - Displays the interface name. For example, "eth0.2".
• RX - Displays the RX (receiving) data rate through the interface.
• TX - Displays the TX (transmitting) data rate through the
interface.
Click the Install package button to install the package needed for this
protocol.
Enter the local/peer IPv6 address here.
Enter the IPv4 tunnel address for DS-Lite here.
Select the IPv4 netmask for DS-Lite here. Select the custom option to
manually enter the IPv4 netmask.
Description
Select this option to bring up this interface when the device
rebooted.
Enter the MTU value for the tunnel interface here.
User Manual
Page 48
