Kingsford TG2002101-KF Owners Manual Assembly And Operating Instructions

17 inch rectangle grill
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Tools required for assembly (Not Included): Pliers, Philips & Flathead Screwdrivers and Adjustable Wrench.
This instruction manual contains important information necessary for the proper assembly and
safe use of the appliance.
Read and follow all warnings and instructions before assembling and using the appliance.
Follow all warnings and instructions when using the appliance.
Keep this manual for future reference.
Never use grill indoors. Carbon Monoxide poisoning that can lead to death.
TG2002101-KF English
17 INCH RECTANGLE GRILL
Owner's Manual
Assembly and Operating Instructions
Model # TG2002101-KF
WARNING
OUTDOOR USE ONLY!
1
191111Ver1

Advertisement

Table of Contents
loading

Related Manuals for Kingsford TG2002101-KF

Summary of Contents for Kingsford TG2002101-KF

  • Page 1 17 INCH RECTANGLE GRILL Owner’s Manual Assembly and Operating Instructions Model # TG2002101-KF Tools required for assembly (Not Included): Pliers, Philips & Flathead Screwdrivers and Adjustable Wrench.  This instruction manual contains important information necessary for the proper assembly and safe use of the appliance.
  • Page 2 DO NOT wear loose clothing or allow hair to come in contact with grill.  Grill is hot when in use. To avoid burns:  DO NOT attempt to move the grill.  Wear protective gloves or oven mitts.  DO NOT touch any hot grill surfaces. TG2002101-KF English 191111Ver1...

  • Page 3: California Proposition 65 Warning

    WARNING: This product can expose you to chemicals including soot, which is known to the State of California to cause cancer, and carbon monoxide, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov. TG2002101-KF English 191111Ver1...

  • Page 4: Product Diagram

    THANK YOU FOR PURCHASING THIS KINGSFORD 17 INCH ® RECTANGLE GRILL Read all safety warnings & assembly instructions carefully before assembling or operating your grill. STOP! DO NOT RETURN TO RETAILER. For assembly assistance, missing or damaged parts, please call RANKAM customer service at 1–888–837–1380, 8:00 am to 5:00 pm, Pacific Standard Time, Monday –...

  • Page 5: Components List

    Components List 1. Handle 2. Lid 3. Lid Bracket 3pcs 2pcs 4. Cooking Grate 5. Charcoal Grid 6. Grill Body 7. Air Vent 8. Wire Leg 2sets 2pcs TG2002101-KF English 191111Ver1...
  • Page 6 Hardwares List Bolt (M6 x 15) 6pcs Bolt (M4 x 10) 8pcs Nut (M4) 8pcs Washer (M6 x 19mm Dia.) 4pcs Insulating Washer (M6 x 15mm Dia.) 6pcs Washer (M6 x 12mm Dia.) 6pcs TG2002101-KF English 191111Ver1...

  • Page 7: Assembly Instruction

    2. Attach Lid Bracket (3) to Lid (2) by inserting 4pcs bolts (B) and nuts (C). Step 2: Attach each Handle (1) to Grill Body (6) using 2pcs bolts (A), washers (F) and insulating washers (E). Attach each Air Vent (7) to Grill Body (6) using 2pcs bolts (B) and nuts (C). TG2002101-KF English 191111Ver1...
  • Page 8 Step 3: Attach Wire Leg (8) to the hole of Grill Body with 4pcs washers (D). TG2002101-KF English 191111Ver1...
  • Page 9 Step 4: Place Charcoal Grid (5) and Cooking Grate (4) into the Grill Body. TG2002101-KF English 191111Ver1...
  • Page 10 Step 5: 1. Tighten all Hardwares. 2. Finished! Always unfold the legs during cooking and lighting! TG2002101-KF English 191111Ver1...
  • Page 11 Lid, otherwise the Lid won't fully close. Lid Opening: When operating the Grill, the Lid can be used as a wind shield as shown in the picture below. Make sure the Lid Bracket is secured to the edge of the Grill Body. TG2002101-KF English 191111Ver1...
  • Page 12 Folding Legs for Transportation: Please fold the Legs as shown in the picture below, make sure the Legs are secured to the tab on the Lid. TG2002101-KF English 191111Ver1...

  • Page 13: Preparation For Use & Lighting Instructions

    Pick up by handle and pour lit charcoal on to charcoal grid. Start with 1.5 – 2 pounds (0.7 – 0.9 kg) of charcoal. This should be enough charcoal to cook with, once the curing process has been completed. TG2002101-KF English 191111Ver1...
  • Page 14 Pick up by handle and pour lit charcoal on to charcoal grid. Start with 1.5 – 2 pounds (0.7 – 0.9 kg) of charcoal. TG2002101-KF English 191111Ver1...
  • Page 15 Place food on cooking grate and close grill lid. Always use a meat thermometer to ensure food is fully cooked before removing from grill. Step 7 Allow grill to cool completely, and then follow instructions in the “After-Use Safety” and “Proper Care & Maintenance” sections of this manual. TG2002101-KF English 191111Ver1...

  • Page 16: Flavoring Wood

    If necessary, use your Charcoal Chimney Starter to light additional charcoal and / or wood and add to existing fire. WARNING Never add charcoal lighting fluid to hot or even warm coals as flashback may occur causing severe burns. TG2002101-KF English 191111Ver1...

  • Page 17: After-Use Safety

    Touch-up with a good quality high-temperature resistant paint.  Never apply paint to the interior surface. Rust spots on the interior surface can be buffed, cleaned, and then lightly coated with vegetable oil or vegetable oil spray to minimize rusting. TG2002101-KF English 191111Ver1...

  • Page 18: Limited Warranty

    1380 customerservice@rankam.com 8:00am to 5:00pm, Pacific Standard Time, Monday to Friday KINGSFORD AND THE KINGSFORD LOGO ARE REGISTERED TRADEMARKS OF THE KINGSFORD ® ® ® PRODUCTS COMPANY, LLC AND ARE USED UNDER LICENCE BY RANKAM. ALL RIGHTS RESERVED. TG2002101-KF English...
