Table Of Contents; Standard And Industrial Versions: Installation; Testing The Sensor - DAVIS Solar Radiation Sensor Install Manual

C :
ONTENTS
Standard and Industrial Versions: Installation.............................. 3
Testing the Sensor.......................................................................... 3
Installing the Sensor....................................................................... 4
Typical Standard Installation......................................................... 4
Typical Industrial Installation........................................................ 5
Mounting on the Sensor Mounting Arm......................................... 6
Mounting on the Sensor Tilting Bracket........................................ 7
Mounting on a Wood Surface.......................................................... 10
Routing Sensor Cable..................................................................... 11
Vantage Pro Version: Installation on the Sensor Mounting Shelf.. 12
Testing the Sensor.......................................................................... 12
Accessing the SIM........................................................................... 12
Securing the Sensor on the Shelf.................................................... 13
Routing Sensor Cable..................................................................... 14
If You Are Going to Install the Solar Radiation Sensor................. 15
Maintaining the Sensor.................................................................. 15
Technical Support.......................................................................... 16
S
PECIFICATIONS ARE
For detailed technical information on the solar radiation sensor, call Technical
Support (510) 732-7814 to request a specification sheet, or download it from our
website:
http://www.davisnet.com/support/weather/
S
TANDARD AND

Testing the Sensor

1. Attach the sensor cable to the connector S5 on the sensor interface module, or "SIM".
Consult the System Installation manual for instructions
2. Press the appropriate key to make sure you are getting a solar radiation reading on
the console.
Consult the station manual for instructions on displaying solar radiation.
3. Shade the sensor and make sure the reading changes.
