DAVIS Solar Power Kit Install Manual

The Solar Power Kit (#6610) provides power to a Wireless Vantage Pro console
when mounted in a remote location or in a field station. The kit consists of
three key elements – a solar panel, a 6-Volt battery, and a regulator circuit –
mounted in a protective housing:
Note: Use Solar Power Kit #7707 with Cabled Vantage Pro consoles.
Components
The Solar Power Kit includes the following components and hardware:
1/4" x 1-1/2" Lag Screws
1/4" Flat Washers
1/4" Lock Washers
1/4" Hex Nuts
8" Cable Ties
Tools for Setup
Adjustable wrench or 7/16" wrench
Drill and 3/16" (5 mm) drill bit (if mounting on a vertical surface)
Location Tips
The following tips should help you find the best possible location and position
for your Solar Power Kit.
The panel should be mounted facing South in the Northern Hemisphere
and North in the Southern Hemisphere.
Position the solar panel to have maximum exposure to the sun
panel works best when the surface of the panel receives full sunlight.
Mount the panel away from fences, buildings, trees or other equipment
or obstructions that may cast a shadow over the panel.
S P
O L A R O W E R
F O R
W V
I R E L E S S A N T A G E
I M
N S T A L L A T I O N A N U A L
U-Bolts
4" Cable Tie
K
I T
P
R O
Shelter
Power Cable
The solar
.
Product # 6610
