DAVIS Solar Radiation Sensor Install Manual page 2

M H
OUNTING ARDWARE
Please make sure you have all components listed below before continuing.
Shield
Body with cable attached
Mounting hardware
Enables installation and
leveling of the sensor.
Three #6-32 x 1-1/2"
(38 mm) machine screws
Three springs
Three #6 flat washers
Three #6 screw retainers
Three #4 screw retainers
Three wood screws
One #8-32 x 3/4" (19 mm)
machine screw
One #8-32 hex nut
One #8 flat washer
One 3/16" (5 mm) cable
clamp
T M
OOLS AND ATERIALS
You may need some of the following tools and materials in order to complete
your installation. Please be sure you have everything you need before beginning.
Medium Phillips screwdriver
Scissors
Center punch or nail (if mounting on wood surface)
Drill with 7/8" (22 mm) and #36 (2.7 mm) drill bits (if mounting on wood surface)
Wire cutters and stripper (industrial version only)
