T
M
OOLS AND
In addition to the components listed above, you may need the following tools
and materials. Please be sure you have everything you need before beginning
the installation.
Rev. D (or later) WeatherLink Data Logger
All GroWeatherLinks, Health WeatherLinks, and Energy WeatherLinks
use the Rev. D (or later) WeatherLink data logger. If you intend to attach
the SR Modem to Davis' Perception
Wizard II-S
Rev. D (or later) WeatherLink. Check the manufacturing code on the
underside of the WeatherLink; if it begins with the letter(s) L, LB, or LC,
contact Davis for information on swapping your WeatherLink for the lat-
est version.
2-Twisted-Pair Cable
You will need a length of 2-twisted-pair cable to run between the
SR Modems. Consult the table below to determine the maximum cable
run for either 22 or 19 AWG cables.
AWG M
22
19
Small Screwdriver
Wire Cutter
Wire Stripper or Knife
L
Y
ABELLING
Before beginning the installation, consult your WeatherLink user's guide for
instructions on labeling the WeatherLink cables.
Page 2
N
ATERIALS
EEDED FOR
®
or Weather Monitor II
C
AXIMUM
ABLE
4 Miles (6.4 km)
7 Miles (11 km)
C
OUR
ABLES
I
NSTALLATION
®
, Weather Wizard III
®
, you need to be sure that you have a
R
UN
®
, Weather
Short-Range Modem Pair
