Adjusting the Camera angle
Panning
Rotation 360°
Tilting
FOCUS
ZOOM
Focus: Far
Zoom: Wide
Warning:
- Do not rotate more than 360 ˚
- Do not twist the camera's bracket too
many times.
360°
Adjusting the camera angle
Adjust the camera angle while the camera is
fixed on the ceiling. Pan is used to rotate the
camera's body to left and right, and Tilt is
used to adjust the tilt. Rotating the lens by
its axis is called Rotation.
- Panning: 360°
- Rotation: 360°
90°
- Tilting: 90°
Adjusting the camera lens
1. Remove the camera's dome by using the
2. Unlock the zoom and focus levers by
3. Adjust the zoom and focus by moving the
Near
Tele
4. After adjustment, tighten the zoom or
16
torque wrench included.
rotating them counter-clockwise.
lever. Please refer to the diagram below.
focus levers back into lock position.
