Specifications
VIDEO
Image sensor
Active pixels
Scanning system
Fr eguency
Signal technology
Synchronization
Resolution
Minimum scene illumination
Video output
LENS
Focal length and lens type
IR distance
OPERATIONAL
Alarm output
Shutter speed
Backlight
Star-Light™
Wide Dynamic Range(WDR)
1/2.8" CMOS sensor
2608(H) x 1960(V)
Progressive scan
60Hz / 50Hz
Max 5MP Universal
Internal
2592x1944 (1944p(20fps), (CVI Max
1440p)/ 1440p30fps/ 1080p30fps/
720p30fps)
F1.4 (30IRE): 0.08 lux (color)
F1.4 (30IRE): 0 lux (B&W)
BNC/UTP
(Universal: HD-A/HD-TVI/HD-CVI/CVBS)
2.7~13.5mm, p-iris vari-focal
100ft
1 alarm output
1/30(25) - 1/30,000
OFF/HME/BLC/WDR
OFF, x2 - x32
LOW/MIDDLE/HIGH
