OSD Menu_Exposure

Lens
1
Manual: Manual mode supports the fixed board lens or the manual iris lens.
Auto: AUTO mode sets the camera's iris automatically.
EXPOSURE
EXPO
1 LENS
EDGE DET
BRIGHTNESS
SHUTTER
BACK-LIGHT
STARLIGHT
AGC
3D DNR
RETURN
Under the lens sub-menu, you can adjust the following settings:
Level
Change the camera's iris value manually. If auto is selected, this option is disabled.
Edge DET
Adjust the camera's focus according to the camera's view.
- Level:
- Color:
Brightness
0 ~ 20: The higher the number, the brighter the image will appear.
Shutter
Set the shutter speed to auto, manual or flicker mode.
- Auto: If selected, adjust the following options :
- Normal: Set when the camera is installed in an indoor environment.
- De-blur: Set when the camera is installed in an outdoor environment.
- Flicker: Select when the camera is experiencing flickering in the image. The shutter
speed will be set automatically to 1/100.
- Manual: If selected, set the shutter speed from the options: 1/30 ~ 1/30000.
AUTO
LEVEL
ON
RETURN
10
AUTO
OFF
X4
10
HIGH
Set the focus range.
Set the color to be displayed in the focus range from: yellow, cyan,
green, magenta, red, blue, black or white.
19
LENS EDGE DET
20
LEVEL
COLOR
RETURN
5
YEL
