WS 8356
IMPORTANT!!
PLEASE READ BEFORE BEGINNING ASSEMBLY!!
Please make sure all lumber, hardware and accessory parts are accounted for.
If you are missing anything, please DO NOT RETURN to the store where purchased.
Please call our Customer Service Department at the number below.
ASSEMBLY INSTRUCTIONS
LDR 2-25-2018

Advertisement

loading
Need help?

Need help?

Do you have a question about the WS 8356 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Swing-N-Slide WS 8356

Summary of Contents for Swing-N-Slide WS 8356

  • Page 1 WS 8356 IMPORTANT!! PLEASE READ BEFORE BEGINNING ASSEMBLY!! Please make sure all lumber, hardware and accessory parts are accounted for. If you are missing anything, please DO NOT RETURN to the store where purchased. Please call our Customer Service Department at the number below.
  • Page 4 6 ft. 6 ft. Denotes Use Zone with Protective Surfacing L+6 ft. 6 ft. Denotes Use Zone with Protective Surfacing 6 ft. 6 ft. 6 ft. Use Zone for Single-Axis Swings Use Zone for Multi-Axis Swings...
  • Page 5 PLAYSET SAFETY ZONE 16'-4 1/8" 6'-0" 14'-0" 6'-0" 28'-0" 6'-0" 28'-7 3/16" 16'-5 15/16" 14'-0" 6'-0" 6'-0" 27'-1" MINIMUM USE ZONE FOR PLAY EQUIPMENT SHALL EXTEND NO LESS THAN 72” FROM ALL SIDES OF THE PLAY STRUCTURE. SWING USE ZONE EXTENDS NO LESS THAN 168”. SWINGS MUST HAVE A MINIMUM CLEARANCE OF 8”...

  • Page 6: Tools Required

    REMEMBER- If you are missing anything, please DO NOT RETURN to the store where purchased. Contact our Customer Service Department at 1-800-888-1232 or email us at: service@swing-n-slide.com For ease in inventorying your wooden playset parts all have been marked with a part number. Look for the part number typically located on the end of the part.

  • Page 7: Tower Components

    (4) [PF 6062] 1’’ x 3-3/8’’ x 42-1/2’’ ROOF A-FRAME TOWER COMPONENTS (7) [PF 6008] 3/4’’ x 5-3/8’’ x 42’’ WS 8356 (2) [PF 6013] 5/8’’ x 5-3/8’’ x 22-3/4’’ ROCKWALL BOARD (10) [PF 6000] 5/8’’ x 5-3/8’’ x 33-3/4’’...
  • Page 8 TOWER MODULE SA 6081 /SA6022 COMPONENTS CONT. Coolwave Slide (x1) HD Ring-Trap (x1) Alpine Slide (x1) HD Swing Seat (x2) Climbing Rock (x6) Safety Handle (x2) Quick Link (x6) HD Swing Hanger (x6) Anchor It (x4) (x1) Anchor It Strap (x4) Square Bit 5/16’’...
  • Page 9 TOWER MODULE SA 6081 /SA6022 HARDWARE 5/16-18 T-Nut (x28) Small 1/4’’ Loc Washer (x12) 5/16” Washer (x36) 1/4’’ Washer (x16) 5/16’’ Loc Washer (x12) 1/4’’ T-Nut (x12) #8 x 1/2” Pan Screw (x2) #12 x 3/4” Pan Screw (x14) 3/4” Flat Head Screw (x20) 30mm Deck Screw (x162) 1-5/8”...
  • Page 10 TERRACE MODULE SA 6031 BOARD LIST (1) [PF 6061] 1-1/2’’ x 1-1/2’’ x 40’’ (2) [PF 6028] 1-3/8’’ x 3’’ x 79’’ (2) [PF 6026] 1’’ x 3-3/8’’ x 42’’ (3) [PF 6005] 3/4’’ x 3-3/8’’ x 42’’ (4) [PF 6025] 3/4’’ x 3-3/8’’ x 29-1/4’’ (3) [PF 6024] 3/4’’...

  • Page 11: Board List

    PICNIC TABLE MODULE WOOD ROOF SA6035 SA6037 BOARD LIST BOARD LIST (18) [PF 6055] 1/2’’ x 5’’ x 47-1/2’’ SHINGLE (1) [PF 6040] 1’’ x 5-3/8’’ x 41-1/2’’ BENCH (2) [PF 6061] 1-1/2’’ x 1-1/2’’ x 40’’ (2) [PF 6133] 3/4’’ x 3-3/8’’ x 41-1/2’’ TABLE (2) [PF 6038] 3/4’’...
  • Page 12 MONKEY BAR SA6036 BOARD LIST (1) [PF 6041] 1-3/8’’ x 3-3/8’’ x 29-1/4’’ (2) [PF 6042] 1-3/8’’ x 3-3/8’’ x 32’’ (2) [PF 6043] 1-3/8’’ x 3-3/8’’ x 60’’ (2) [PF 6045] 1-3/8’’ x 3-3/8’’ x 79-7/8’’ (1) [PF 6044] 1’’ x 3-3/8’’ x 58’’ MONKEY BAR HARDWARE 2-1/2”...
  • Page 13 FORT ENCLOSURE SA6036 BOARD LIST (7) [PF 6407] 5/8’’ x 5-3/8’’ x 29-5/8’’ (1) [PF 6408] 3/4’’ x 5-3/8’’ x 41-1/2’’ (1) [PF 6410] 3/4’’ x 5-3/8’’ x 41-1/2’’ ARCHED (1) [PF 6409] 3/4’’ x 3-3/8’’ x 41-1/2’’ (2) [PF 6414] 5/8’’ x 3-3/8’’ x 29-5/8’’ (2) [PF 6415] 1-3/8’’...
  • Page 14 STEP 1 6’’ 47-1/2’’ 2-1/2’’ Screws Flush 6’’ 2-1/2’’ Screws T-Nut Small 2-1/2’’ Screws 5/16-18 X 4’’ Hex Head Bolt 5/16’’ Washer 5/16’’Loc-Washer 59-1/4’’ FRAME A 2-1/2’’ Screws 1-1/2’’ Hint!! Use parts from your Tower Box. BOTH SIDES 2-1/2” Deck Screw (x14) 1.
  • Page 15 STEP 2 6’’ 47-1/2’’ 2-1/2’’ Screws Flush 6’’ 2-1/2’’ Screws T-Nut Small 2-1/2’’ Screws 5/16-18 X 4’’ Hex Head Bolt 5/16’’ Washer 5/16’’Loc-Washer 59-1/4’’ 2-1/2’’ Screws 2-1/2’’ Screws FRAME B 2-1/2’’ Screws 1-1/2’’ BOTH SIDES 2-1/2” Deck Screw (x14) 1. Assemble Frame B as shown above. Note: Tap each T-Nut into its pre-drilled hole until the metal tangs sink fully into the wood.
  • Page 16 STEP 3 2-1/2’’ Screws Check to make sure struc- ture is square Flush 2-1/2’’ Screws 2-1/2’’ Screws Flush 2-1/2’’ Screws 2-1/2’’ Screws 59-1/4’’ FRAME A 2-1/2” Deck Screw (x13) 1. Attach support boards to Frame A as shown.
  • Page 17 STEP 4 Check to make sure struc- ture is square 2-1/2’’ Screws 2-1/2’’ Screws 2-1/2’’ Screws 2-1/2’’ Screws FRAME B 2-1/2’’ Screws FRAME A 2-1/2” Deck Screw (x13) 1. Attach Frame A to Frame B as shown.
  • Page 18 STEP 5 PF 6003 3/4’’ x 3-3/8’’ x 35-7/8’’ 1-3/4’’ Screws 2-1/2’’ Screws 1-3/4’’ Screws PF 6003 3/4’’ x 3-3/8’’ x 35-7/8’’ 2-1/2’’ Screws PF 6011 1’’ x 3-3/8’’ x 47-1/2’’ 16-1/2’’ PF 6011 1’’ x 3-3/8’’ x 47-1/2’’ 16-1/2’’ 1-3/4”...
  • Page 19 STEP 6 PF 6008 3/4’’ x 5-3/8’’ x 42’’ 1-3/4’’ Screws per board 1-3/4” Deck Screw (x42) 1. Install Deck Boards as shown. NOTE: Standard gap between deck boards is 3/8’’.
  • Page 20 STEP 7 Flush 1-3/4’’ Screw per joint (4) 3’’ Screw NOTE: PRE-DRILLED HOLES PF 6149 1-3/8’’ x 3-3/8’’ x 15-1/2’’ Flush DECK SUPPORT NOTE: Insert Hardware From Outside 2-1/2’’ Screws 31’’ 2-1/2’’ Screws 1-3/4” Deck Screw (x6) 2-1/2” Deck Screw (x6) 3”...
  • Page 21 STEP 8 Check to make sure struc- ture is square 2-1/2’’ Screws 5/16-18 X 4’’ Hex Head Bolt 5/16’’Loc-Washer 5/16’’ Washer T-Nut Small 47-1/4’’ Flush Hint!! Use parts from your Terrace Box. 2-1/2” Deck Screw (x4) 1. Install Deck Support Board as shown.
  • Page 22 STEP 9 Check to make sure struc- ture is square 2’’ Screws Flush 2’’ Screws 2’’ Screws Flush 2’’ Screws FRAME C 2” Deck Screw (x12) 1. Assemble Frame C as shown.
  • Page 23 STEP 10 Check to make sure struc- ture is square 5/16-18 X 2’’ Hex Head Bolt 47-1/4’’ 5/16’’Loc-Washer 5/16’’ Washer 2’’ Screws T-Nut Small 2” Deck Screw (x4) 1. Install Deck Support Board as shown.
  • Page 24 STEP 11 Flush 2-1/2’’ Screws Flush Check to make sure struc- ture is square 2-1/2’’ Screws Flush 2-1/2’’ Screws Flush FRAME C 2-1/2’’ Screws Hint!! Use parts from your Monkey Bars Box. 2-1/2” Deck Screw (x8) 1. Install Frame Support Boards as shown.
  • Page 25 STEP 12 Check to make sure struc- ture is square 2-1/2’’ Screws 2-1/2’’ Screws 79’’ 2-1/2’’ Screws 2-1/2’’ Screws FRAME C 2-1/2” Deck Screw (x10) 1. Attach Frame C to Tower as shown.
  • Page 26 STEP 13 1-3/4’’ Screws 1-3/4’’ Screws PF 6150 3/4’’ x 3-3/8’’ x 24-3/4’’ 1-3/4’’ Screws 1-3/4’’ Screws PF 6150 3/4’’ x 3-3/8’’ x 24-3/4’’ PF 6061 1-1/2’’ x 1-1/2’’ x 40’’ 1-3/4’’ Screws 1-3/4’’ Screws PF 6150 3/4’’ x 3-3/8’’ x 24-3/4’’ 10-5/8’’...
  • Page 27 STEP 14 All Boards PF 6135 3/4’’ x 5-3/8’’ x 26-1/4’’ Flush 1-3/4’’ Screws per board Note: Holes 1-7/8’’ From Edge on This Side 1-3/4” Deck Screw (x36) 1. Install Deck Boards as shown. NOTE: Standard gap between deck boards is 7/16’’.
  • Page 28 STEP 15 PF 6005 3/4’’ x 3-3/8’’ x 42’’ 2-1/2’’ Screws 53-7/8’’ 2-1/2” Deck Screw (x6) 1. Attach Gap Filler Boards as shown.
  • Page 29 STEP 16 PF 6022 3/4’’ x 3-3/8’’ x 19-1/2’’ 2’’ Screws PF 6023 3/4’’ x 3-3/8’’ x 22-1/2’’ 2’’ Screws 50-5/8’’ 2” Deck Screw (x6) 1. Install Barrier Support Boards as shown.
  • Page 30 STEP 17 (6) PF 6021 5/8’’ x 5-3/8’’ x 30-3/4’’ 30mm Screws per board 1-7/8’’ Panel Bracket #12 x 3/4” Pan Screw (x8) 3/4’’ Pan Screws INSIDE VIEW 30mm Deck Screw (x24) 1. Install Barrier Boards as shown. No gaps between boards.
  • Page 31 STEP 18 PF 6002 3/4’’ x 3-3/8’’ x 22-1/2’’ 2-1/2’’ Screws Flush 2-1/2’’ Screws PF 6005 3/4’’ x 3-3/8’’ x 42’’ PF 6002 2-1/2’’ Screws 3/4’’ x 3-3/8’’ x 22-1/2’’ 2-1/2’’ Screws Flush 2-1/2’’ Screws 62-5/8’’ 2-1/2” Deck Screw (x10) 2-1/2”...
  • Page 32 STEP 19 1’’ 1’’ 3-1/8’’ 3-1/8’’ 1-5/8’’ PF 6172 5/8’’ x 3-3/8’’ x 11-1/2’’ PF 6001 5/8’’ x 5-3/8’’ x 9-1/4’’ PRE-DRILL (4) 1/8’’ 1/2’’ GAP 1/2’’ GAP HOLES PF 6172 5/8’’ x 3-3/8’’ x 11-1/2’’ 30mm Screws 17-3/8’’ per board PF 6172 5/8’’...
  • Page 33 STEP 20 30mm Screws per board 1’’ 30mm Screws per board 30mm Screws per board 30mm Screws per board Panel Bracket 3/4’’ Pan Screws 30mm Deck Screw (x24) #12 x 3/4” Pan Screw (x8) Install Window Panels.
  • Page 34 STEP 21 PF 6020 3’’ x 3’’ x 47-1/2’’ SWING BEAM SUPPORT TOP OF BEAM SUPPORT 84’’ FROM BOTTOM OF POST Loc Nut 5/16’’ Washer Wood Loc-Washer 5/16-18 X 6’’ Carriage Bolt 1. Install Swing beam support as shown.
  • Page 35 STEP 22 CENTER PF 6019 TOWER 2-11/16’’x5-3/8’’x93’’ THIS SIDE Swing Beam MARK HOLE LOCATION = DRILL HERE (6 PLACES) 30mm Deck Screw (4 per Clamp) 5/16”-18 x 6-1/2” Carriage Bolt 5/16” Clamp, Beam HD Swing Hanger 5/16” Washer A-FRAME 5/16” THIS SIDE Loc Nut 1.
  • Page 36 STEP 23 PF 6018 2-11/16’’x3’’x62’’ A-Frame SB Support 5/16”-18 x 7” Hex Head Bolt 3’’ Screws 3’’ Screws 5/16” Washer 5/16” Washer 5/16” Loc Nut (2) PF 6017 1-3/8’’x3-3/8’’x83’’ A-Frame 5/16”-18 x 2-1/2” Hex Head Bolt 5/16” Loc Washer 5/16” Washer 5/16”...
  • Page 37 STEP 24 (2) Swing Beam Bracket 5/16”-18 x 3-1/2” Hex Head Bolt 5/16” Washer 5/16” Loc Nut 5/16”-18 x 3-1/2” 5/16” Washer Hex Head Bolt 5/16” Washer 5/16” Washer 5/16” Loc Nut 1. Attach Swing Beam Bracket to A-Frame & Swing Beam as shown.
  • Page 38 STEP 25 Beam Brace 5/16”-18 x 3 1/4” Hex Head Bolt 5/16” Loc Washer 5/16” Washer 5/16-18 T-Nut Small 1. Install Swing Beam Brace as shown.
  • Page 39 STEP 26 5/16”-18 x 6” 5/16”-18 x 8-1/2” Carriage Bolt Hex Head Bolt 5/16” Loc Washer 5/16” Washer 5/16” Wood Loc Washer 5/16-18 T-Nut Small 5/16” Washer 5/16” Loc Nut 1. Install Swing Beam as shown.
  • Page 40 STEP 27 (4) 30mm Screws per board PF 6000 5/8’’ x 5-3/8’’ x 33-3/4’’ 30mm Deck Screw (x24) 1. Install Barrier Boards as shown. NOTE: Standard gap between deck boards is 1/2’’.
  • Page 41 STEP 28 (1) 3’’ Deck Screws 1-5/8’’ 1-5/8’’ 13-1/2’’ Check to make sure struc- ture is square PF 6058 5/8’’ x 3-3/8’’ x 30’’ (4) 30mm Deck Screws 3/4’’ CENTERED PF 6060 5/8’’ x 5-3/8’’ x 13’’ SUN (2) 30mm Screws 3”...
  • Page 42 STEP 29 (4) 30mm (6) 30mm Screws Screws (1) PF 6056 5/8’’ x 2’’ x 10’’ (2) PF 6059 5/8’’ x 2’’ x 7’’ Note: Place screws through A-Frame and CENTERED Note: PF 6053 into end of PF 6053 Rests on Top of 2-1/2’’...
  • Page 43 (5) PF 6055 1/2’’ x 5’’ x 47-1/2’’ SHINGLE STEP 30 Per Side 1’’ OVERHANG BOTH SIDES (4) 1-5/8’’ Deck Screws per board (1) 1-5/8’’ Deck Screw per board (2) PF 6061 1-1/2’’ x 1-1/2’’ x 40’’ (4) PF 6055 1/2’’ x 5’’ x 47-1/2’’ SHINGLE Per Side (2) PF 6061 1-1/2’’...
  • Page 44 STEP 31 3/4’’ Offset 1-5/8’’ Screws Each Side Side View 1-5/8’’ Screws 1-5/8’’ Screws 1-5/8’’ Screws NOTE: Secure Roof from the INSIDE 1-5/8” Deck Screw (x12) 1. Attach Roof Frame to Tower as shown. NOTE: Secure roof from inside the tower.
  • Page 45 STEP 32 2’’ Screws 2’’ Screws 2” Deck Screw (x8) 1. Attach Roof Side Support Boards as shown.
  • Page 46 STEP 33 ALIGN SCREWS WITH PRE DRILLS (1) PF 6013 5/8’’ x 5-3/8’’ x 22-3/4’’ ROCKWALL BOARD (6) PF 6389 5/8’’ x 5-3/8’’ x 22-3/4’’ ROCKWALL BOARDS (4) 2’’ Deck Screws per board (1) PF 6013 5/8’’ x 5-3/8’’ x 22-3/4’’ ROCKWALL BOARD 2”...
  • Page 47 STEP 34 Panel Bracket 3/4’’ Pan Screw 2-1/2’’ Screws Under Deck View 2-1/2” Deck Screw (x6) 1. Attach Rock Wall as shown.
  • Page 48 STEP 35 (2) 1/4’’ T-Nuts (2) 1-1/4’’ Hex Head Bolts (2) 1/4’’ Flat Washer Per Rock (2) 1/4’’ Loc-Washer Per Rock 1. Attach Climbing Rocks as shown.
  • Page 49 STEP 36 Flush ‘L’ Brackets 1-1/4’’ Pan Head Screws per L Bracket 49-1/4’’ Short Monkey 38-1/4’’ Bar Rungs 2-1/2’’ Pan Head Screws 27-1/4’’ per rung 16-1/4’’ 5-1/4’’ 19’’ T-Nut 5/16’’ Washer Small 5/16’’Loc-Washer 5/16-18 X 1-1/2’’ Hex Head Bolt Triangle Brackets 2-1/2”...
  • Page 50 STEP 37 Monkey Bar 36-1/4’’ Rungs 2-1/2’’ Pan Head Screws per rung 24-1/2’’ 12-3/4’’ Flush 22’’ 2-1/2’’ Screws PF 6044 1’’ x 3-3/8’’ x 58’’ T-Nut Small (2) PF 6042 1-3/8’’ x 3-3/8’’ x 32’’ 5/16’’ Washer 5/16’’Loc-Washer 5/16-18 X 3-1/2’’ Hex Head Bolt 5/16’’...
  • Page 51 STEP 38 5/16-18 X 3’’ Hex Head Bolt 5/16’’Loc-Washer 5/16’’ Washer T-Nut Small 5/16-18 X 1-1/2’’ Hex Head Bolt 5/16’’Loc-Washer 5/16’’ Washer T-Nut Small Flush 1-1/4’’ Pan Head Screws per L Bracket 1-1/4” Pan Head Screw (x6) 1. Assemble and attach Monkey Bar Assembly as shown.
  • Page 52 STEP 39 (2) PF 6039 3/4’’ x 3-3/8’’ x 9-3/4’’ (2) PF 6133 3/4’’ x 3-3/8’’ x 41-1/2’’ TABLE 2’’ Screws TABLE SUPPORT 2-3/4’’ OUTSIDE (2) PF 6037 3/4’’ x 3-3/8’’ x 15-3/4’’ 3’’ 3’’ FACE TO BENCH SUPPORT OUTSIDE FACE, 2’’...
  • Page 53 STEP 40 1-5/8’’ Screws per board PF 6410 3/4’’ x 5-3/8’’ x 41-1/2’’ ARCHED PF 6024 3/4’’ x 3-3/8’’ x 27-3/4’’ Flush Flush 2-1/2’’ Screws PF 6408 3/4’’ x 5-3/8’’ x 41-1/2’’ Flush 31’’ Flush PF 6409 3/4’’ x 3-3/8’’ x 41-1/2’’ 1-3/4’’...
  • Page 54 STEP 41 Flush Flush 30mm Screws 30mm Screws per board per board 1-3/4’’ GAP TO UPRIGHT 1’’ GAP 1’’ GAP SIDES BOTH (5) PF 6407 5/8’’ x 5-3/8’’ x 29-5/8’’ (4) PF 6021 5/8’’ x 5-3/8’’ x 30-3/4’’ (2) PF 6414 5/8’’ x 3-3/8’’ x 29-5/8’’ NO GAPS BETWEEN BOARDS NO GAPS BETWEEN BOARDS Under Deck View...
  • Page 55 STEP 42 (2) PF 6180 5/8’’ x 3-3/8’’ x 10-1/2’’ (6) 30mm Deck Screws Underdeck View Grade (2) 30mm Deck 2” Screws PF 6009 1-3/8’’x3-3/8’’x17-1/4’’ Slide Stake 30mm Deck Screw (x8) 1” Truss Screw (x3) Attach Slide Support Boards and Slide as shown.
  • Page 56 STEP 43 1-3/4’’ Screws From Behind Deck Support Flush to Support Flush to Upright Underdeck View (2) 30mm Deck Screws Grade 2” PF 5999 1-3/8’’x3-3/8’’x17-1/4’’ Slide Stake 1-3/4” Deck Screw (x4) 30mm Deck Screw (x2) 1” Truss Screw (x4) Attach Slide Support Boards and Slide as shown.
  • Page 57 STEP 44 1/4” Washer 1/4’’ x 1-3/4” Pan Screw 11” 1/2” Pan Screw (x2) 1-3/4” Pan Screw (x2) 1. Attach Safety Handle and I.D. Tag as shown.
  • Page 58 STEP 45 FIG. A HD Ring-Trap Combo Assembly 1. Attach Ring-Trap Chain to Swing Hanger as shown in (Fig. A). 2. Tighten Quick Link to secure chains to Swing Hangers as shown in (Fig. A).
  • Page 59 STEP 46 FIG. A 8" Minimum HD Swing Seats 1. Attach Chain to Swing Hanger as shown in (Fig. A). 2. Tighten Quick Link to secure chains to Swing Hangers as shown in (Fig. A). NOTE: Once installed, there must be a minimum 8’’ clearance between the bottom of the swings and the surfacing.
  • Page 60 STEP 47 5/16” Washer Fold up Anchor-It Strap 1-1/2” Lag Screw Anchor-It 5/16’’ x 1-1/2” Lag Screw (x4) 2. Twist the Anchor-It into the ground until only the loop is exposed. 3. Place Anchor-It Strap thru loop, fold the ends together and attach to the unit as shown. Note: Keep as little play as possible using any of the holes in the strap that work best.

  • Page 61: Warranty Registration

    Swing-N-Slide® will repair, or at its discretion, replace any part within the stated warranty period which is defective in workmanship or chase, including the date of purchase. This warranty is valid only if the product is used for the purpose for which it was designed and installed at a residential, single family dwelling.
  • Page 63 PRODUCT WARRANTY & REGISTRATION Please register online to properly initiate your product warranty & registration Quick & simple from home or mobile Record your purchase in our system Initiate product warranty Improved customer support Register your product online at www.OnlineWarranty.net...
  • Page 64 Call our Customer Support Representatives 1-800-888-1232 Available Monday - Friday, 7am - 5pm (CST) Weekend support available April through July Technical support from experienced Swing-N-Slide customer service representatives who have actually built a swing set themselves. © Swing-N-Slide Inc. 2018 Printed in USA...
