WS 8356
IMPORTANT!!
PLEASE READ BEFORE BEGINNING ASSEMBLY!!
Please make sure all lumber, hardware and accessory parts are accounted for.
If you are missing anything, please DO NOT RETURN to the store where purchased.
Please call our Customer Service Department at the number below.
ASSEMBLY INSTRUCTIONS
Swing•N•Slide • 166 Etowah Industrial Ct. • Canton, GA 30114
Email us at: playsupport@backyardproducts.com or call us at 1-800-882-0272
© Swing-N-Slide Inc.
Printed in USA
LDR 03-01-2022
LA 8403

Advertisement

loading
Need help?

Need help?

Do you have a question about the WS 8356 and is the answer not in the manual?

Questions and answers

Related Manuals for Swing-N-Slide WS 8356

Summary of Contents for Swing-N-Slide WS 8356

  • Page 1 WS 8356 IMPORTANT!! PLEASE READ BEFORE BEGINNING ASSEMBLY!! Please make sure all lumber, hardware and accessory parts are accounted for. If you are missing anything, please DO NOT RETURN to the store where purchased. Please call our Customer Service Department at the number below.
  • Page 2 Safety Checklist for Swing-N-Slide Play Sets and Accessories Observing the following statements and warnings reduces the likelihood of serious or fatal injury  This playset has been designed for use by a maximum of twelve (13) occupants at one time having a combined weight of 1,365 pounds.  This playset is intended for use by children from (2) to (10) years of age.  On-site adult supervision for children of all ages is recommended.  Instruct children not to walk close to, in front of, behind, or between moving items.  Instruct children not to twist swing chains or ropes or loop them over the top support bar since this may reduce the strength of the chain or rope.  Instruct children to avoid swinging empty seats.  Teach children to sit in the center of the swings with their full weight on the seats.  Instruct children not to use the equipment in a manner other than intended.
  • Page 3 PLAYSET MAINTENANCE Cosmetic defects that do not affect the structural integrity of the product, or natural defects of wood such as warping, splitting, checking, twisting, shrinkage, swelling or any other physical properties of wood that do not present a safety hazard, are not covered by our warranty. To help minimize these natural defects we recommend applying a sealer or stain every two or three years, or more often as the climate dictates. Power washing, sanding or other preparatory methods should be used prior to sealing or staining. Periodic maintenance is required to ensure safe enjoyment of your playset and accessories. Read and follow the Playset Checklist below to reduce the likelihood of serious or fatal injury. Use the checklists as a guide for proper playset care and maintenance. PLAYSET CHECKLIST At the beginning of each play season: Tighten all hardware. Lubricate all metallic moving parts per manufacturer's instructions. Check all protective coverings on bolts, pipes, edges, and corners. Replace if they are loose, cracked, or missing. Check all moving parts including swing seats, ropes, cables, and chains for wear, rust, or other deterioration. Replace as needed. Check metal parts for rust. If found, sand and repaint using a nonleaded-based paint meeting the requirements of 16 CFR 1303. Check all wood members for deterioration and splinters. Sand down splinters and replace deteriorating wood members. Reinstall any plastic parts, such as swing seats or any other items that were removed for the cold season. Rake and check depth of loose fill protective surfacing materials to prevent compaction and to maintain appropriate depth. Replace as necessary. Twice a month during play season: Tighten all hardware. Check all protective coverings on bolts, pipes, edges, and corners. Replace if they are loose, cracked, or missing. Rake and check depth of loose fill protective surfacing materials to prevent compaction and to maintain appropriate depth. Replace as necessary. Once a month during play season: Lubricate all metallic moving parts per manufacturer's instructions.
  • Page 4 PLAYGROUND SURFACING MATERIALS SECTION 4 OF THE CONSUMER PRODUCT SAFETY COMMISSION'S OUTDOOR HOME PLAYGROUND SAFETY HANDBOOK Select Protective Surfacing One of the most important things you can do to reduce the likelihood of serious head injuries is to install shock-absorbing protective surfacing under and around your play equipment. The protective surfacing should be applied to a depth that is suitable for the equipment height in accordance with ASTM Specification F 1292. There are different types of surfacing to choose from; whichever product you select, follow these guidelines: NOTE: Do not install home playground equipment over concrete, asphalt, or any other hard surface. A fall onto a hard surface can result in serious injury to the equipment user. Grass and dirt are not considered protective surfacing because wear and environmental factors can reduce their shock absorbing effectiveness. Carpeting and thin mats are generally not adequate protective surfacing. Ground level equipment - such as a sandbox, activity wall, playhouse or other equipment that has no elevated play surface - does not need any protective surfacing. Maximum fall height for this playset is 83''. Loose-Fill Materials:  Maintain a minimum depth of 9 inches of loose- fill materials such as wood mulch/chips, engineered wood fiber (EWF), or shredded/recycled rubber mulch for equipment up to 8 feet high; and 9 inches of sand or pea gravel for equipment up to 5 feet high. NOTE: An initial fill level of 12 inches will compress to about a 9- inch depth of surfacing over time. The surfacing will also compact, displace, and settle, and should be periodically refilled to maintain at least a 9- inch depth.
  • Page 5 PLAYSET SAFETY ZONE 16'-4 1/8" 6'-0" 14'-0" 6'-0" 28'-0" 6'-0" 28'-7 3/16" 16'-5 15/16" 14'-0" 6'-0" 6'-0" 27'-1" MINIMUM USE ZONE FOR PLAY EQUIPMENT SHALL EXTEND NO LESS THAN 72” FROM ALL SIDES OF THE PLAY STRUCTURE. SWING USE ZONE EXTENDS NO LESS THAN 168”. SWINGS MUST HAVE A MINIMUM CLEARANCE OF 8”...

  • Page 6: Tools Required

    TOOLS REQUIRED DRILL 1/2” & 7/16’’ SOCKETS & HAMMER ADJUSTABLE TAPE MEASURE WRENCH WRENCH SCREWDRIVER PHILLIPS BIT CARPENTER SAFETY GLASSES 1/8” DRILL BIT SQUARE HELPFUL ASSEMBLY INFORMATION Your playset consists of several boxes or modules. It is important to ensure all lumber, accessories and hardware is accounted for.

  • Page 7: Board List

    (2) [PF 6010] 1’’ x 3-3/8’’ x 47-1/2’’ TOWER MODULE SA 6022 / 6051 (1) [PF 6011] 1’’ x 3-3/8’’ x 47-1/2’’ BOARD LIST (4) [PF 6062] 1’’ x 3-3/8’’ x 42-1/2’’ ROOF A-FRAME TOWER MODULE: SA6042 (4) [PF 6164] 3’’ x 3’’ x 94’’ (7) [PF 6008] 3/4’’...
  • Page 8 Please call our Customer Service Department at the number below. ASSEMBLY INSTRUCTIONS Swing•N•Slide • 1212 Barberry Drive • Janesville, Wisconsin 53545 Visit our web site at: www.swing-n-slide.com or call us at 1-800-888-1232 © Swing-N-Slide Inc. Printed in USA LDR 2-6-2018...
  • Page 9 TOWER MODULE SA 6081 HARDWARE FS2831 FS2830 2-1/2 FS2829 5/16” Loc Nut (x9) FS2828 FS2831 1-3/4 5/16-18 T-Nut (x12) FS2827 Small FS2830 1-5/8 5/16” Washer (x24) 2-1/2 FS2826 FS2829 1-1/4 FS2831 FS2826 5/16” Wood Loc FS2828 FS2830 5/16’’ Loc Washer (x12) Washer (x3) 3/4”...
  • Page 10 (10) [PF 6000] 5/8’’ x 5-3/8’’ x 33-3/4’’ /16’’ x 3’’ x 62’’ A-FRAME SUPPORT TERRACE MODULE SA 6031 (2) [PF 6060] 5/8’’ x 5-3/8’’ x 13’’ SUN ’’ x 3-3/8’’ x 83’’ A-FRAME LEGS BOARD LIST (4) [PF 6001] 5/8’’ x 5-3/8’’ x 9-1/4’’ ’’...
  • Page 11 (10) [PF 6021] 5/8’’ x 5-3/8’’ x 30-3/4’’ (2) [PF 6050] 3/4’’ x 3-3/8’’ x 43-1/2’’ (2) [PF 6004] 3/4’’ x 3-3/8’’ x 42’’ (6) [PF 6135] 3/4’’ x 5-3/8’’ x 26-1/4’’ PICNIC TABLE MODULE WOOD ROOF LADDER MODULE: SA6005 (5) [PF 6005] 3/4’’...
  • Page 12 MONKEY BAR SA6036 BOARD LIST MONKEY BARS MODULE: SA6006 / SA6022 (1) [PF 6041] 1-3/8’’ x 3-3/8’’ x 29-1/4’’ (2) [PF 6042] 1-3/8’’ x 3-3/8’’ x 32’’ (2) [PF 6043] 1-3/8’’ x 3-3/8’’ x 60’’ (2) [PF 6045] 1-3/8’’ x 3-3/8’’ x 79-7/8’’ 2 ’...
  • Page 13 FORT ENCLOSURE BOARD LIST (SA 6036) (7) [PF 6407] 5/8’’ x 5-3/8’’ x 29-5/8’’ (1) [PF 6408] 3/4’’ x 5-3/8’’ x 41-1/2’’ (1) [PF 6410] 3/4’’ x 5-3/8’’ x 41-1/2’’ ARCHED (1) [PF 6409] 3/4’’ x 3-3/8’’ x 41-1/2’’ (2) [PF 6414] 5/8’’ x 3-3/8’’ x 29-5/8’’ (2) [PF 6415] 1-3/8’’...
  • Page 14 STEP 1 6’’ 47-1/2’’ 2-1/2’’ Screws Flush 6’’ 2-1/2’’ Screws T-Nut Small 2-1/2’’ Screws 5/16-18 X 4’’ Hex Head Bolt 5/16’’ Washer 5/16’’Loc-Washer 59-1/4’’ FRAME A 2-1/2’’ Screws 1-1/2’’ Hint!! Use parts from your Tower Box. BOTH SIDES 2-1/2” Deck Screw (x14) 1.
  • Page 15 STEP 2 6’’ 47-1/2’’ 2-1/2’’ Screws Flush 6’’ 2-1/2’’ Screws T-Nut Small 2-1/2’’ Screws 5/16-18 X 4’’ Hex Head Bolt 5/16’’ Washer 5/16’’Loc-Washer 59-1/4’’ 2-1/2’’ Screws 2-1/2’’ Screws FRAME B 2-1/2’’ Screws 1-1/2’’ BOTH SIDES 2-1/2” Deck Screw (x14) 1. Assemble Frame B as shown above. Note: Tap each T-Nut into its pre-drilled hole until the metal tangs sink fully into the wood.
  • Page 16 STEP 3 Check to make sure 2-1/2’’ Screws structure is square. Flush 2-1/2’’ Screws 2-1/2’’ Screws Flush 2-1/2’’ Screws 2-1/2’’ Screws 59-1/4’’ FRAME A 2-1/2” Deck Screw (x13) 1. Attach support boards to Frame A as shown.
  • Page 17 STEP 4 Check to make sure structure is square. 2-1/2’’ Screws 2-1/2’’ Screws 2-1/2’’ Screws 2-1/2’’ Screws FRAME B 2-1/2’’ Screws FRAME A 2-1/2” Deck Screw (x13) 1. Attach Frame A to Frame B as shown.

  • Page 18: Top View

    STEP 5 PF 6003 3/4’’ x 3-3/8’’ x 35-7/8’’ 1-3/4’’ Screws 2-1/2’’ Screws 1-3/4’’ Screws PF 6003 3/4’’ x 3-3/8’’ x 35-7/8’’ 2-1/2’’ Screws PF 6011 1’’ x 3-3/8’’ x 47-1/2’’ 16-1/2’’ FS2831 PF 6011 1’’ x 3-3/8’’ x 47-1/2’’ FS2830 2-1/2 16-1/2’’...
  • Page 19 STEP 6 PF 6008 3/4’’ x 5-3/8’’ x 42’’ 1-3/4’’ Screws per board 1-3/4” Deck Screw (x42) 1. Install Deck Boards as shown. NOTE: Standard gap between deck boards is 3/8’’.
  • Page 20 STEP 7 Flush 1-3/4’’ Screw per joint (4) 3’’ Screw NOTE: PRE-DRILLED HOLES PF 6149 1-3/8’’ x 3-3/8’’ x 15-1/2’’ Flush DECK SUPPORT NOTE: Insert Hardware From Outside 2-1/2’’ Screws 31’’ 2-1/2’’ Screws 1-3/4” Deck Screw (x6) 2-1/2” Deck Screw (x6) 3”...
  • Page 21 STEP 8 Check to make sure structure is square. 2-1/2’’ Screws 5/16-18 X 4’’ Hex Head Bolt 5/16’’Loc-Washer 5/16’’ Washer T-Nut Small 47-1/4’’ Flush Hint!! Use parts from your Terrace Box. 2-1/2” Deck Screw (x4) 1. Install Deck Support Board as shown.
  • Page 22 STEP 9 Check to make sure structure is square. 2’’ Screws Flush 2’’ Screws 2’’ Screws Flush 2’’ Screws FRAME C 2” Deck Screw (x12) 1. Assemble Frame C as shown.
  • Page 23 STEP 10 Check to make sure structure is square. 5/16-18 X 2’’ Hex Head Bolt 47-1/4’’ 5/16’’Loc-Washer 5/16’’ Washer 2’’ Screws T-Nut Small 2” Deck Screw (x4) 1. Install Deck Support Board as shown.
  • Page 24 STEP 11 Flush 2-1/2’’ Screws In Monkey Bar Box. Check to make sure structure is square. Flush 2-1/2’’ Screws Flush 2-1/2’’ Screws Flush FRAME C 2-1/2’’ Screws 2-1/2” Deck Screw (x8) 1. Install Frame Support Boards as shown.
  • Page 25 STEP 12 Check to make sure structure is square. 2-1/2’’ Screws 2-1/2’’ Screws 79’’ 2-1/2’’ Screws FS2831 FRAME C 2-1/2’’ Screws FS2830 2-1/2” Deck Screw (x10) 2-1/2 FS2829 1. Attach Frame C to Tower as shown. FS2828...
  • Page 26 STEP 13 1-3/4’’ Screws 1-3/4’’ Screws PF 6150 3/4’’ x 3-3/8’’ x 24-3/4’’ 1-3/4’’ Screws 1-3/4’’ Screws PF 6150 3/4’’ x 3-3/8’’ x 24-3/4’’ PF 6061 1-1/2’’ x 1-1/2’’ x 40’’ 1-3/4’’ Screws 1-3/4’’ Screws PF 6150 3/4’’ x 3-3/8’’ x 24-3/4’’ 10-5/8’’...
  • Page 27 STEP 14 All Boards PF 6135 3/4’’ x 5-3/8’’ x 26-1/4’’ Flush 1-3/4’’ Screws per board Note: Holes 1-7/8’’ From Edge on This Side FS2831 FS2830 2-1/2 FS2829 FS2828 1-3/4” Deck Screw (x36) 1-3/4 FS2827 1. Install Deck Boards as shown. 1-5/8 NOTE: Standard gap between deck boards is 7/16’’.
  • Page 28 STEP 15 PF 6005 3/4’’ x 3-3/8’’ x 42’’ 2-1/2’’ Screws 53-7/8’’ 2-1/2” Deck Screw (x6) 1. Attach Gap Filler Boards as shown.
  • Page 29 STEP 16 PF 6022 3/4’’ x 3-3/8’’ x 19-1/2’’ 2’’ Screws PF 6023 3/4’’ x 3-3/8’’ x 22-1/2’’ 2’’ Screws 50-5/8’’ 2” Deck Screw (x6) 1. Install Barrier Support Boards as shown.

  • Page 30: Inside View

    STEP 17 (6) PF 6021 5/8’’ x 5-3/8’’ x 30-3/4’’ 1-7/8’’ 1-1/4” Screws per board FS2831 FS2830 2-1/2 FS2829 FS2828 Panel 1-3/4 Bracket FS2827 #12 x 3/4” Pan Screw (x8) 3/4’’ Pan 1-5/8 Screws FS2826 INSIDE VIEW 1-1/4 1-1/4” Deck Screw (x24) FS2826 1.
  • Page 31 STEP 18 PF 6002 3/4’’ x 3-3/8’’ x 22-1/2’’ 2-1/2’’ Screws Flush 2-1/2’’ Screws PF 6005 3/4’’ x 3-3/8’’ x 42’’ PF 6002 2-1/2’’ Screws 3/4’’ x 3-3/8’’ x 22-1/2’’ 2-1/2’’ Screws Flush 2-1/2’’ Screws 62-5/8’’ FS2831 FS2831 FS2830 FS2830 2-1/2”...
  • Page 32 STEP 19 1’’ 1’’ 3-1/8’’ 3-1/8’’ 1-5/8’’ PF 6172 5/8’’ x 3-3/8’’ x 11-1/2’’ PF 6001 5/8’’ x 5-3/8’’ x 9-1/4’’ PRE-DRILL (4) 1/8’’ 1/2’’ GAP 1/2’’ GAP HOLES PF 6172 5/8’’ x 3-3/8’’ x 11-1/2’’ 1-1/4” 17-3/8’’ Screws per board FS2831 FS2830 PF 6172...
  • Page 33 STEP 20 1-3/16” (30 mm) Deck Screws per board 1’’ 1-3/16” (30 mm) Deck Screws per board 1-3/16” (30 mm) Deck Screws per board 1-3/16” (30 mm) Deck Screws per board Panel Bracket 3/4’’ Pan Screws 1-3/16” (30 mm) Deck Screw (x24) #12 x 3/4”...
  • Page 34 STEP 21 PF 6020 3’’ x 3’’ x 47-1/2’’ SWING BEAM SUPPORT TOP OF BEAM SUPPORT 84’’ FROM BOTTOM OF POST Loc Nut 5/16’’ Washer Wood Loc-Washer 5/16-18 X 6’’ Carriage Bolt 1. Install Swing beam support as shown.
  • Page 35 STEP 22 CENTER PF 6019 TOWER 2-11/16’’x5-3/8’’x93’’ THIS SIDE Swing Beam 1-1/4” (30mm) Deck Screw (4 per Clamp) 5/16”-18 x 6-1/2” Carriage Bolt 5/16” Clamp, Beam HD Swing Hanger 5/16” Washer 5/16” Loc Nut NOTE: All hardware included with swing hangers. A-FRAME THIS SIDE 1.
  • Page 36 STEP 23 PF 6018 2-11/16’’x3’’x62’’ A-Frame SB Support 5/16”-18 x 7” Hex Head Bolt 3’’ Screws 3’’ Screws 5/16” Washer 5/16” Washer 5/16” Loc Nut (2) PF 6017 1-3/8’’x3-3/8’’x83’’ A-Frame 5/16”-18 x 2-1/2” Hex Head Bolt 5/16” Loc Washer 5/16” Washer 5/16”...
  • Page 37 STEP 24 (2) Swing Beam Bracket 5/16”-18 x 3-1/2” Hex Head Bolt 5/16” Washer 5/16” Loc Nut 5/16”-18 x 3-1/2” 5/16” Washer Hex Head Bolt 5/16” Washer 5/16” Washer 5/16” Loc Nut 1. Attach Swing Beam Bracket to A-Frame & Swing Beam as shown.
  • Page 38 STEP 25 Beam Brace 5/16”-18 x 3 1/4” Hex Head Bolt 5/16” Loc Washer 5/16” Washer 5/16-18 T-Nut Small 1. Install Swing Beam Brace as shown.
  • Page 39 STEP 26 5/16”-18 x 6” 5/16”-18 x 8-1/2” Carriage Bolt Hex Head Bolt 5/16” Loc Washer 5/16” Washer 5/16” Wood Loc Washer 5/16-18 T-Nut Small 5/16” Washer 5/16” Loc Nut 1. Install Swing Beam as shown.
  • Page 40 STEP 27 (4) 1-3/16” (30mm) Screws per board PF 6000 5/8’’ x 5-3/8’’ x 33-3/4’’ BARRIER BOARD SPACING: Outer boards will be fl ush against 3’’ x 3’’ Uprights. All boards inbetween will have a 3/4’’ gap. 1-3/16” (30 mm) Deck Screw (x24) 1.
  • Page 41 STEP 28 (1) 3’’ Deck Screws 1-5/8’’ 1-5/8’’ 13-1/2’’ Check to make sure structure is square. PF 6058 5/8’’ x 3-3/8’’ x 30’’ (4) 1-3/16” (30 mm) Deck Screws 3/4’’ CENTERED PF 6060 5/8’’ x 5-3/8’’ x 13’’ SUN (2) 1-3/16” (30 mm) Deck Screws 3”...

  • Page 42: Side View

    STEP 29 (4) 1-3/16” (30 mm) Deck Screws (4) 1-3/16” (30 mm) Deck Screws (1) PF 6056 5/8’’ x 2’’ x 10’’ (2) PF 6059 5/8’’ x 2’’ x 7’’ Note: Place screws through A-Frame and CENTERED Note: PF 6053 into end of PF 6053 Rests on Top of 2-1/2’’...

  • Page 43: Underside View

    (5) PF 6055 1/2’’ x 5’’ x 47-1/2’’ SHINGLE STEP 30 Per Side 1’’ OVERHANG BOTH SIDES (4) 1-5/8’’ Deck Screws per board (1) 1-5/8’’ Deck Screw per board (2) PF 6061 1-1/2’’ x 1-1/2’’ x 40’’ (4) PF 6055 1/2’’ x 5’’ x 47-1/2’’ SHINGLE Per Side (2) PF 6061 1-1/2’’...
  • Page 44 STEP 31 3/4’’ Offset 1-5/8’’ Screws Each Side Side View 1-5/8’’ Screws 1-5/8’’ Screws 1-5/8’’ Screws NOTE: Secure Roof from the INSIDE 1-5/8” Deck Screw (x12) 1. Attach Roof Frame to Tower as shown. NOTE: Secure roof from inside the tower.
  • Page 45 STEP 32 2’’ Screws 2’’ Screws FS2831 FS2830 2-1/2 FS2829 2” Deck Screw (x8) FS2828 1. Attach Roof Side Support Boards as shown. 1-3/4 FS2827 1-5/8...
  • Page 46 STEP 33 ALIGN SCREWS WITH PRE DRILLS (1) PF 6013 5/8’’ x 5-3/8’’ x 22-3/4’’ ROCKWALL BOARD (6) PF 6389 5/8’’ x 5-3/8’’ x 22-3/4’’ ROCKWALL BOARDS (4) 2’’ Deck Screws per board (1) PF 6013 5/8’’ x 5-3/8’’ x 22-3/4’’ ROCKWALL BOARD 2”...
  • Page 47 STEP 34 Panel Bracket 3/4’’ Pan Screw 2-1/2’’ Screws Under Deck View 2-1/2” Deck Screw (x6) 1. Attach Rock Wall as shown.
  • Page 48 STEP 35 (2) 1/4’’ T-Nuts (2) 1-1/4’’ Hex Head Bolts (2) 1/4’’ Flat Washer Per Rock (2) 1/4’’ Loc-Washer Per Rock NOTE: Hardware packaged with rocks in bag. 1. Attach Climbing Rocks as shown.
  • Page 49 STEP 36 Flush ‘L’ Brackets 1-1/4’’ Pan Head Screws per L Bracket 49-1/4’’ Short Monkey 38-1/4’’ Bar Rungs 2-1/2’’ Pan Head Screws 27-1/4’’ per rung 16-1/4’’ 5-1/4’’ 19’’ T-Nut 5/16’’ Washer Small 5/16’’Loc-Washer 5/16-18 X 1-1/2’’ Hex Head Bolt Triangle Brackets 2-1/2”...
  • Page 50 STEP 37 Monkey Bar 36-1/4’’ Rungs 2-1/2’’ Pan Head Screws per rung 24-1/2’’ 12-3/4’’ Flush 22’’ PF 6044 1’’ x 3-3/8’’ x 58’’ 2-1/2’’ Screws T-Nut Small (2) PF 6042 1-3/8’’ x 3-3/8’’ x 32’’ 5/16’’ Washer 5/16’’Loc-Washer 5/16-18 X 3-1/2’’ Hex Head Bolt 5/16’’...
  • Page 51 STEP 38 5/16-18 X 3’’ Hex Head Bolt 5/16’’Loc-Washer 5/16’’ Washer T-Nut Small 5/16-18 X 1-1/2’’ Hex Head Bolt 5/16’’Loc-Washer 5/16’’ Washer T-Nut Small Flush 1-1/4’’ Pan Head Screws per L Bracket 1-1/4” Pan Head Screw (x6) 1. Assemble and attach Monkey Bar Assembly as shown.
  • Page 52 STEP 39 (2) PF 6039 3/4’’ x 3-3/8’’ x 9-3/4’’ (2) PF 6133 3/4’’ x 3-3/8’’ x 41-1/2’’ TABLE 2’’ Screws TABLE SUPPORT 2-3/4’’ OUTSIDE (2) PF 6037 3/4’’ x 3-3/8’’ x 15-3/4’’ 3’’ 3’’ FACE TO BENCH SUPPORT OUTSIDE FACE, 2’’...
  • Page 53 STEP 40 1-5/8’’ Screws per board PF 6410 3/4’’ x 5-3/8’’ x 41-1/2’’ ARCHED PF 6024 3/4’’ x 3-3/8’’ x 27-3/4’’ Flush Flush 2-1/2’’ Screws PF 6408 3/4’’ x 5-3/8’’ x 41-1/2’’ Flush 31’’ Flush PF 6409 3/4’’ x 3-3/8’’ x 41-1/2’’ 1-3/4’’...
  • Page 54 STEP 41 Flush Flush 1-3/16” (30 mm) 1-3/16” (30 mm) Deck Screws Deck Screws per board per board 1-3/4’’ GAP TO UPRIGHT 1’’ GAP 1’’ GAP SIDES BOTH (5) PF 6407 5/8’’ x 5-3/8’’ x 29-5/8’’ (4) PF 6021 5/8’’ x 5-3/8’’ x 30-3/4’’ (2) PF 6414 5/8’’...
  • Page 55 STEP 42 (2) PF 6180 5/8’’ x 3-3/8’’ x 10-1/2’’ (6) 1-3/16” (30 mm) Deck Screws Underdeck View 1” Truss Screws (x3) Grade 2” (2) 1-3/16” (30 mm) Deck Screws PF 6009 1-3/8’’x3-3/8’’x17-1/4’’ Slide Stake 1-3/16” (30 mm) Deck Screw (x8) 1”...
  • Page 56 STEP 43 1-3/4’’ Screws From Behind Deck Support (4) #14 x 1-1/4” Pan Screws Flush to Support Flush to Upright Underdeck View (2) 1-3/16” (30 mm) Deck Screws Grade 2” FS2831 PF 5999 1-3/8’’x3-3/8’’x17-1/4’’ Slide Stake FS2830 2-1/2 FS2829 FS2828 1-3/4 1-3/16”...
  • Page 57 STEP 44 1/4” Washer 1/4’’ x 1-1/4” Pan Screw 11” NOTE: Hardware packaged with accessories. ID Tag - SA 1699 Safety Warning Plate SA 4294 1/4’’ Washer (x4) 1/4’’ x 1-1/4” Pan Screw (x4) #8 x 1/2” Pan Screw (x2) 3/4”...
  • Page 58 STEP 45 FIG. A HD Ring-Trap Combo Assembly 1. Attach Ring-Trap Chain to Swing Hanger as shown in (Fig. A). 2. Tighten Quick Link to secure chains to Swing Hangers as shown in (Fig. A).
  • Page 59 STEP 46 FIG. A 83" 8" Minimum HD Swing Seats 1. Attach Chain to Swing Hanger as shown in (Fig. A). 2. Tighten Quick Link to secure chains to Swing Hangers as shown in (Fig. A). NOTE: Once installed, there must be a minimum 8’’ clearance between the bottom of the swings and the surfacing.
  • Page 60 STEP 47 5/16” Washer Fold up Anchor-It Strap 1-1/2” Lag Screw Anchor-It NOTE: Hardware packaged with accessory. 5/16’’ x 1-1/2” Lag Screw (x4) 5/16” Washer (x4) 1. Place swing set in fi nal location and mount Anchor-It(s) at locations circled above. 2.
  • Page 61 Swing-N-Slide® will repair, or at its discretion, replace any part within the stated warranty period which is defective in workmanship or materials. This decision is subject to verification of the defect upon delivery of the defective part to Swing-N-Slide® at 166 Etowah Industrial Ct.
  • Page 62 Got Questions? We’ve got answers! Call our Customer Support Representatives 1-800-882-0272 Available Monday - Friday, 8am - 5pm Technical support from experienced Swing-N-Slide customer service representatives who have actually built a swing set themselves. © Swing-N-Slide Inc. 2021 Printed in USA...
