WS 8348
IMPORTANT!!
PLEASE READ BEFORE BEGINNING ASSEMBLY!!
Please make sure all lumber, hardware and accessory parts are accounted for.
If you are missing anything, please DO NOT RETURN to the store where purchased.
Please call our Customer Service Department at the number below.
ASSEMBLY INSTRUCTIONS
LDR 2-22-2018

Advertisement

loading
Need help?

Need help?

Do you have a question about the WS 8348 and is the answer not in the manual?

Questions and answers

Related Manuals for Swing-N-Slide WS 8348

Summary of Contents for Swing-N-Slide WS 8348

  • Page 1 WS 8348 IMPORTANT!! PLEASE READ BEFORE BEGINNING ASSEMBLY!! Please make sure all lumber, hardware and accessory parts are accounted for. If you are missing anything, please DO NOT RETURN to the store where purchased. Please call our Customer Service Department at the number below.
  • Page 4 6 ft. 6 ft. Denotes Use Zone with Protective Surfacing L+6 ft. 6 ft. Denotes Use Zone with Protective Surfacing 6 ft. 6 ft. 6 ft. Use Zone for Single-Axis Swings Use Zone for Multi-Axis Swings...
  • Page 5 PLAYEST SAFETY ZONE 14’-0’’ 6’ 16’-3’’ 6’ 28’-0’’ 14’-0’’ 6’ 28’-3’’ MINIMUM USE ZONE FOR PLAY EQUIPMENT SHALL EXTEND NO LESS THAN 72” FROM ALL SIDES OF THE PLAY STRUCTURE. SWING USE ZONE EXTENDS NO LESS THAN 168”. SWINGS MUST HAVE A MINIMUM CLEARANCE OF 8” ABOVE THE PROTECTIVE SURFACING. 10 3 83 to Swing Hanger Pivot...

  • Page 6: Tools Required

    REMEMBER- If you are missing anything, please DO NOT RETURN to the store where purchased. Contact our Customer Service Department at 1-800-888-1232 or email us at: service@swing-n-slide.com For ease in inventorying your wooden playset parts all have been marked with a part number. Look for the part number typically located on the end of the part.

  • Page 7: Board List

    (4) [PF 6062] 1’’ x 3-3/8’’ x 42-1/2’’ ROOF A-FRAME TOWER COMPONENTS (7) [PF 6008] 3/4’’ x 5-3/8’’ x 42’’ WS 8348 (2) [PF 6013] 5/8’’ x 5-3/8’’ x 22-3/4’’ ROCKWALL BOARD (10) [PF 6000] 5/8’’ x 5-3/8’’ x 33-3/4’’...
  • Page 8 TOWER MODULE SA6051 / SA6022 COMPONENTS CONT. 5/16’’ x 5-1/2’’ Swing Hanger (x6) Window Pane (x2) Play Handle (x2) Alpine Slide (x1) STD Swing Seat (x2) Wind Rider Handle (x1) Wind Rider Seat (x1) Quick Link (x8) 58” Dipped Chain (x4) 51”...
  • Page 9 TOWER MODULE SA6051 / SA6022 HARDWARE 1/4’’ Washer (x16) 5/16” Washer (x24) 5/16’’ Loc Washer (x12) 5/16” Loc Nut (x9) 1/4’’ Loc Washer (x12) #12 x 3/4” Truss Screw (x14) 5/16” Wood Loc 1/4’’ x 1-3/4” Pan Screw (x4) Washer (x3) 3/16”...
  • Page 10 TERRACE MODULE SA6001 BOARD LIST (1) [PF 6061] 1-1/2’’ x 1-1/2’’ x 40’’ (2) [PF 6028] 1-3/8’’ x 3’’ x 79’’ (2) [PF 6026] 1’’ x 3-3/8’’ x 42’’ (3) [PF 6005] 3/4’’ x 3-3/8’’ x 42’’ (4) [PF 6025] 3/4’’ x 3-3/8’’ x 29-1/4’’ (3) [PF 6024] 3/4’’...
  • Page 11 LADDER MODULE SA6005 PICNIC TABLE MODULE SA6018 BOARD LIST BOARD LIST (1) [PF 6034] 1-3/8’’ x 3-3/8’’ x 66-1/4’’ LADDER SUPPORT-L (1) [PF 6040] 1’’ x 5-3/8’’ x 41-1/2’’ BENCH (1) [PF 6035] 1-3/8’’ x 3-3/8’’ x 66-1/4’’ LADDER SUPPORT-R (2) [PF 6133] 3/4’’...
  • Page 12 FORT ENCLOSURE WOOD ROOF BOARD LIST BOARD LIST (7) [PF 6407] 5/8’’ x 5-3/8’’ x 29-5/8’’ (1) [PF 6408] 3/4’’ x 5-3/8’’ x 41-1/2’’ (18) [PF 6055] 1/2’’ x 5’’ x 47-1/2’’ SHINGLE (1) [PF 6410] 3/4’’ x 5-3/8’’ x 41-1/2’’ ARCHED (2) [PF 6061] 1-1/2’’...
  • Page 13 STEP 1 6’’ 47-1/2’’ 2-1/2’’ Screws Flush 6’’ 2-1/2’’ Screws T-Nut Small 2-1/2’’ Screws 5/16-18 X 4’’ Hex Head Bolt 5/16’’ Washer 5/16’’Loc-Washer 59-1/4’’ 57-9/16’’ FRAME A 2-1/2’’ Screws 1-1/2’’ Hint!! Use parts from your Tower Box. BOTH SIDES 2-1/2” Deck Screw (x14) 1.
  • Page 14 STEP 2 6’’ 47-1/2’’ 2-1/2’’ Screws Flush 6’’ 2-1/2’’ Screws T-Nut Small 2-1/2’’ Screws 5/16-18 X 4’’ Hex Head Bolt 5/16’’ Washer 5/16’’Loc-Washer 2-1/2’’ Screws 57-9/16’’ 2-1/2’’ Screws 59-1/4’’ 31’’ FRAME B 2-1/2’’ Screws 1-1/2’’ JOINTS 2-1/2” Deck Screw (x18) 1.
  • Page 15 STEP 3 Check to make sure struc- 2-1/2’’ Screws 2-1/2’’ Screws ture is square Flush 2-1/2’’ Screws 59-1/4’’ Flush 2-1/2’’ Screws 2-1/2’’ Screws FRAME A 2-1/2” Deck Screw (x11) 1. Attach support boards to Frame A as shown.
  • Page 16 STEP 4 2-1/2’’ Screws Check to make sure struc- ture is square 2-1/2’’ Screws 2-1/2’’ Screws FRAME B 2-1/2’’ Screws FRAME A 2-1/2” Deck Screw (x11) 1. Attach Frame A to Frame B as shown.
  • Page 17 STEP 5 2-1/2’’ Screws PF 6149 1-3/8’’ x 3-3/8’’ x 15-1/2’’ DECK SUPPORT Flush Flush 1-3/4’’ Screw per joint (4) 3’’ Screw 1-3/4” Deck Screw (x6) 3” Deck Screw (x4) 1. Install Deck Supports as shown.
  • Page 18 STEP 6 PF 6003 3/4’’ x 3-3/8’’ x 35-7/8’’ 1-3/4’’ Screws 1-3/4’’ Screws PF 6003 3/4’’ x 3-3/8’’ x 35-7/8’’ 2-1/2’’ Screws PF 6011 1’’ x 3/8’’ x 47-1/2’’ 16-1/2’’ PF 6011 1’’ x 3/8’’ x 47-1/2’’ 16-1/2’’ 1-3/4” Deck Screw (x12) TOP VIEW 2-1/2”...
  • Page 19 STEP 7 PF 6008 3/4’’ x 5-3/8’’ x 42’’ 1-3/4’’ Screws per deck board All Boards Flush With 3’’ x 3’’s 1-3/4” Deck Screw (x42) 1. Install Deck Boards as shown. NOTE: Standard gap between deck boards is 3/8’’.
  • Page 20 STEP 8 Flush PF 6002 3/4’’ x 3-3/8’’ x 22-1/2’’ Flush With 2-1/2’’ Screws 3’’ x 3’’s PF 6002 3/4’’ x 3-3/8’’ x 22-1/2’’ 2-1/2’’ Screws 2-1/2’’ Screws Flush With (2) PF 6005 3/4’’ x 3-3/8’’ x 42’’ Bottom of 62-5/8’’...
  • Page 21 STEP 9 Check to make sure struc- ture is square 47-1/4’’ 2-1/2’’ Screws FRAME A 5/16-18 X 4’’ Hex Head Bolt 5/16’’Loc-Washer 5/16’’ Washer Hint!! Use parts from your Terrace Box. T-Nut Small 2-1/2” Deck Screw (x4) 1. Install Deck Support Board as shown.
  • Page 22 STEP 10 Check to make sure struc- ture is square 2’’ Screws COUNTERBORE THIS SIDE Flush 2’’ Screws COUNTERBORE THIS SIDE 45-9/16’’ 2’’ Screws Flush 2’’ Screws FRAME C 2” Deck Screw (x12) 1. Assemble Frame C as shown.
  • Page 23 STEP 11 Check to make sure struc- ture is square 5/16-18 X 2’’ 47-1/4’’ Hex Head Bolt 5/16’’Loc-Washer 5/16’’ Washer 2’’ Screws T-Nut Small 2” Deck Screw (x4) 1. Install Deck Support Board as shown.
  • Page 24 STEP 12 Flush With Outside Face of 1-3/8’’ x 3’’ 2-1/2’’ Screws Check to make sure struc- ture is square Flush With Flush With Outside Top of Flush With Face of Frame Top of 1-3/8’’ x 3’’ Frame 2-1/2’’ Screws 2-1/2’’...
  • Page 25 STEP 13 Check to make sure struc- ture is square 2-1/2’’ Screws 79’’ 2-1/2’’ Screws 2-1/2’’ Screws 2-1/2’’ Screws 2-1/2’’ Screws FRAME C 2-1/2” Deck Screw (x13) 1. Attach Frame C to Tower as shown.
  • Page 26 STEP 14 1-3/4’’ Screws 1-3/4’’ Screws PF 6150 3/4’’ x 3-3/8’’ x 24-3/4’’ PF 6150 3/4’’ x 3-3/8’’ x 24-3/4’’ 1-3/4’’ Screws 1-3/4’’ Screws PF 6150 3/4’’ x 3-3/8’’ x 24-3/4’’ 1-3/4’’ Screws PF 6061 1-1/2’’ x 1-1/2’’ x 40’’ 1-3/4’’...
  • Page 27 STEP 15 All Boards PF 6135 3/4’’ x 5-3/8’’ x 26-1/4’’ Flush 1-3/4’’ Screws per board Note: Holes 1-7/8’’ From Edge on This Side 1-3/4” Deck Screw (x36) 1. Install Deck Boards as shown. NOTE: Standard gap between deck boards is 7/16’’.
  • Page 28 STEP 16 PF 6023 3/4’’ x 3-3/8’’ x 22-1/2’’ 2’’ Screws PF 6022 3/4’’ x 3-3/8’’ x 19-1/2’’ 2’’ Screws 50-5/8’’ 2” Deck Screw (x6) 1. Install Barrier Support Boards as shown.
  • Page 29 STEP 17 PF 6004 3/4’’ x 3-3/8’’ x 42’’ 2-1/2’’ Screws PF 6005 3/4’’ x 3-3/8’’ x 42’’ 2-1/2’’ Screws 5-3/8’’ 53-7/8’’ 2-1/2” Deck Screw (x12) 1. Attach Gap Filler Boards as shown.

  • Page 30: Inside View

    STEP 18 2-7/8’’ (4) PF 6021 5/8’’ x 5-3/8’’ x 30-3/4’’ 30mm per board Panel Bracket #12 x 3/4” Pan Screw (x8) 3/4’’ Pan Screws INSIDE VIEW 30mm Deck Screw (x16) 1. Install Barrier Boards as shown.
  • Page 31 STEP 19 (3) PF 6021 5/8’’ x 5-3/8’’ x 30-3/4’’ 2-1/8’’ 2-1/8’’ 30mm Screws 2-1/8’’ per board 30mm Deck Screw (x12) 1. Attach Barrier Boards as shown.
  • Page 32 STEP 20 1’’ 1’’ 3-1/8’’ 3-1/8’’ 1-5/8’’ PF 6172 5/8’’ x 3-3/8’’ x 11-1/2’’ PF 6001 5/8’’ x 5-3/8’’ x 9-1/4’’ PRE-DRILL (4) 1/8’’ 1/2’’ GAP 1/2’’ GAP HOLES PF 6172 5/8’’ x 3-3/8’’ x 11-1/2’’ 30mm Screws 17-3/8’’ per board PF 6172 5/8’’...
  • Page 33 STEP 21 1’’ 30mm Screws per board 30mm Screws per board 30mm’ Screws per board 30mm Screws per board Panel Bracket 3/4’’ Pan Screws 30mm Deck Screw (x24) #12 x 3/4” Pan Screw (x8) Install Window Panels.
  • Page 34 STEP 22 PF 6020 3’’ x 3’’ x 47-1/2’’ SWING BEAM SUPPORT TOP OF BEAM SUPPORT 84’’ FROM BOTTOM OF POST Loc Nut 5/16’’ Washer Wood Loc-Washer 5/16-18 X 6’’ Carriage Bolt 1. Install Swing beam support as shown.
  • Page 35 STEP 23 PF 6019 2-11/16’’x5-3/8’’x93’’ Swing Beam 5/16’’ T-Nut 5-1/2’’ Swing Large Hanger Beam Clamp (4) 30mm Deck Screws Correct Orientation 30mm Deck Screw (x24) 1. Attach Swing Hanger(s) to swing beam as shown. NOTE: Make certain hanger and plate are snug against the bottom of the swing beam, (Fig 5), before installing screws.
  • Page 36 STEP 24 PF 6018 2-11/16’’x3’’x62’’ A-Frame SB Support 5/16”-18 x 7” Hex Head Bolt 3’’ Screws 3’’ Screws 5/16” Washer 5/16” Washer 5/16” Loc Nut (2) PF 6017 1-3/8’’x3-3/8’’x83’’ A-Frame 5/16”-18 x 2-1/2” Hex Head Bolt 5/16” Loc Washer 5/16” Washer 5/16”...
  • Page 37 STEP 25 (2) Swing Beam Bracket 5/16”-18 x 3-1/2” Hex Head Bolt 5/16” Washer 5/16” Loc Nut 5/16”-18 x 3-1/2” 5/16” Washer Hex Head Bolt 5/16” Washer 5/16” Washer 5/16” Loc Nut 1. Attach Swing Beam Bracket to A-Frame & Swing Beam as shown.
  • Page 38 STEP 26 Beam Brace 5/16”-18 x 3 1/4” Hex Head Bolt 5/16” Loc Washer 5/16” Washer 5/16-18 T-Nut Small 1. Install Swing Beam Brace as shown.
  • Page 39 STEP 27 5/16”-18 x 6” 5/16”-18 x 8-1/2” Carriage Bolt Hex Head Bolt 5/16” Loc Washer 5/16” Washer 5/16” Wood Loc Washer 5/16-18 T-Nut Small 5/16” Washer 5/16” Loc Nut 1. Install Swing Beam as shown.
  • Page 40 STEP 28 BARRIER BOARD SPACING: (4) 30mm Screws PF 6000 5/8’’ x 5-3/8’’ x 33-3/4’’ against 3’’ x 3’’ Uprights. per board All boards inbetween will have a 3/4’’ gap. 30mm Deck Screw (x24) 1. Install Barrier Boards as shown.
  • Page 41 STEP 29 (1) 3’’ Deck Screws 1-5/8’’ 1-5/8’’ 13-1/2’’ Check to make sure struc- ture is square PF 6058 5/8’’ x 3-3/8’’ x 30’’ (4) 30mm Deck Screws 3/4’’ CENTERED PF 6060 5/8’’ x 5-3/8’’ x 13’’ SUN (4) 30mm Screws 3”...
  • Page 42 STEP 30 (4) 30mm (6) 30mm Screws Screws (1) PF 6056 5/8’’ x 2’’ x 10’’ (2) PF 6059 5/8’’ x 2’’ x 7’’ Note: Place screws through A-Frame and CENTERED Note: PF 6053 into end of PF 6053 Rests on Top of 2-1/2’’...
  • Page 43 (5) PF 6055 1/2’’ x 5’’ x 47-1/2’’ SHINGLE STEP 31 Per Side 1’’ OVERHANG BOTH SIDES (4) 1-5/8’’ Deck Screws per board (1) 1-5/8’’ Deck Screw per board (2) PF 6061 1-1/2’’ x 1-1/2’’ x 40’’ (4) PF 6055 1/2’’ x 5’’ x 47-1/2’’ SHINGLE Per Side (2) PF 6061 1-1/2’’...
  • Page 44 STEP 32 3/4’’ Offset Each Side 1-5/8’’ Screws Side View 1-5/8’’ Screws 1-5/8’’ Screws 1-5/8’’ Screws NOTE: Secure Roof from the INSIDE 1-5/8” Deck Screw (x12) 1. Attach Roof Frame to Tower as shown. NOTE: Secure roof from inside the tower.
  • Page 45 STEP 33 2’’ Screws 2’’ Screws 2” Deck Screw (x8) 1. Attach Roof Side Support Boards as shown.
  • Page 46 STEP 34 2-1/2’’ Screws per Rung 2-1/2’’ Screws per Rung (5) PF 6032 1’’ x 3-3/8’’ x 18-1/2’’ PF 6029 5/8’’ x 3-3/8’’ x 20-1/2‘’ 2-1/2’’ Screws 2’’ Hint!! Use parts from your Ladder Box. 2-1/2” Deck Screw (x24) 1. Assembly Ladder as shown.
  • Page 47 STEP 35 2-1/2’’ Screws Panel Bracket 3/4’’ Pan Screw 2-1/2” Deck Screw (x3) #12 x 3/4” Pan Screw (x4) 1. Attach Ladder to Tower as shown.
  • Page 48 STEP 36 PF 6415 & PF 6416 Flush to Support Top View 1-3/4’’ Screws From Behind 2-1/2’’ Screws Deck Support per block 53-7/8’’ Flush to Support Flush to Upright 31’’ Underdeck View 3-3/8’’ Flush to Top of Board 2-1/2’’ Screws per block 1-3/4”...
  • Page 49 STEP 37 1-5/8’’ Screws per side PF 6410 3/4’’ x 5-3/8’’ x 41-1/2’’ ARCHED Flush 2-1/2’’ Screws per side Flush PF 6024 3/4’’ x 3-3/8’’ x 27-3/4’’ Flush PF 6408 3/4’’ x 5-3/8’’ x 41-1/2’’ 1-3/4’’ Screws 31’’ per side Flush PF 6409 3/4’’...
  • Page 50 STEP 38 ALIGN SCREWS WITH PRE DRILLS (1) PF 6013 5/8’’ x 5-3/8’’ x 22-3/4’’ ROCKWALL BOARD (6) PF 6389 5/8’’ x 5-3/8’’ x 22-3/4’’ ROCKWALL BOARDS (4) 2’’ Deck Screws per board (1) PF 6013 5/8’’ x 5-3/8’’ x 22-3/4’’ ROCKWALL BOARD 2”...
  • Page 51 STEP 39 2-1/2’’ Screws per side Under Deck View 2-1/2” Deck Screw (x6) 1. Attach Rock Wall as shown.
  • Page 52 STEP 40 (2) 1/4’’ T-Nuts (2) 1-1/4’’ Hex Head Bolts (2) 1/4’’ Flat Washer Per Rock (2) 1/4’’ Loc-Washer Per Rock 1. Attach Climbing Rocks as shown.
  • Page 53 STEP 41 (2) PF 6039 3/4’’ x 3-3/8’’ x 9-3/4’’ (2) PF 6133 3/4’’ x 3-3/8’’ x 41-1/2’’ TABLE 2’’ Screws TABLE SUPPORT 2-3/4’’ OUTSIDE (2) PF 6037 3/4’’ x 3-3/8’’ x 15-3/4’’ 3’’ 3’’ FACE TO BENCH SUPPORT OUTSIDE FACE, 2’’...
  • Page 54 STEP 42 Slide 3’’ 1-1/4” Truss Screws 1-1/4” Truss Side View Screws 2” Grade (2) 30mm Deck Screws PF 6009 1-3/8’’x3-3/8’’x17-1/4’’ Slide Stake 30mm Deck Screw (x2) 1-1/4” Truss Screw (x4) Attach slide as shown.
  • Page 55 STEP 43 Back View Front View (2) 1/4” Washer (2) 1/4’’ x 1-3/4” Pan Screw 11” 1/2” Pan Screw (x2) 1-3/4” Pan Screw (x4) 1. Attach Safety Handle and I.D. Tag as shown.
  • Page 56 STEP 44 Wind Rider 51” Un-Coated chain Loc-Nut 5/16’’ Flat Washer QuickLink 5/16’’ Flat Washer 5/16”-18 x 6-1/2” Hex Bolt QuickLink Wind-Rider Wind Rider Assembly 1. Insert Seat into Handle as shown in (Step1). Secure in place with hardware shown. Note: Make certain no more than two bolt threads protrude from the Loc-Nut once fully tightened.
  • Page 57 STEP 45 PLASTIC COATED END Swing Seat Assembly 1. Take one length of chain and place the outermost link of coated chain through the Quick Link as shown. 2. Place the Quick Link through the Grommet of the swing seat as shown. 3.
  • Page 58 STEP 46 5/16” Washer Fold up Anchor-It Strap 1-1/2” Lag Screw Anchor-It 5/16’’ x 1-1/2” Lag Screw (x4) 2. Twist the Anchor-It into the ground until only the loop is exposed. 3. Place Anchor-It Strap thru loop, fold the ends together and attach to the unit as shown. Note: Keep as little play as possible using any of the holes in the strap that work best.
  • Page 59 Plastic Components, Chains, Hardware and Fasteners – 5 years. These items to be free from defects in workmanship and materials, under Swing-N-Slide® will repair, or at its discretion, replace any part within the stated warranty period which is defective in workmanship or Janesville, Wisconsin, 53545.
  • Page 60 Call our Customer Support Representatives 1-800-888-1232 Available Monday - Friday, 7am - 5pm (CST) Weekend support available April through July Technical support from experienced Swing-N-Slide customer service representatives who have actually built a swing set themselves. © Swing-N-Slide Inc. 2018 Printed in USA...
