WS 8351
IMPORTANT!!
PLEASE READ BEFORE BEGINNING ASSEMBLY!!
Please make sure all lumber, hardware and accessory parts are accounted for.
If you are missing anything, please DO NOT RETURN to the store where purchased.
Please call our Customer Service Department at the number below.
ASSEMBLY INSTRUCTIONS
Swing•N•Slide • 1212 Barberry Drive • Janesville, Wisconsin 53545
Visit our web site at: www.swing-n-slide.com or call us at 1-800-888-1232
LDR 01-17-2018
© Swing-N-Slide Inc.
Printed in USA
LA 9370

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WS 8351 and is the answer not in the manual?

Questions and answers

Summary of Contents for Swing-N-Slide WS 8351

  • Page 1 Please call our Customer Service Department at the number below. ASSEMBLY INSTRUCTIONS Swing•N•Slide • 1212 Barberry Drive • Janesville, Wisconsin 53545 Visit our web site at: www.swing-n-slide.com or call us at 1-800-888-1232 LDR 01-17-2018 © Swing-N-Slide Inc. Printed in USA...
  • Page 2 Safety Checklist for Swing-N-Slide Play Sets and Accessories Observing the following statesments and warnings reduces the likelihood of serious or fatal inury  This playset has been designed for use by a maximum of eleven (13) occupants at one time having a combined weight of 1,365 pounds.
  • Page 3 PLAYSET MAINTENANCE Cosmetic defects that do not affect the structural integrity of the product, or natural defects of wood such as warping, splitting, checking, twisting, shrinkage, swelling or any other physical properties of wood that do not present a safety hazard, are not covered by our warranty.
  • Page 4 PLAYGROUND SURFACING MATERIALS SECTION 4 OF THE CONSUMER PRODUCT SAFETY COMMISSION'S OUTDOOR HOME PLAYGROUND SAFETY HANDBOOK Select Protective Surfacing One of the most important things you can do to reduce the likelihood of serious head injuries is to install shock-absorbing protective surfacing under and around your play equipment.
  • Page 5 PLAYEST SAFETY ZONE 14’-0’’ 6’ 16’-3’’ 6’ 28’-0’’ 14’-0’’ 6’ 28’-3’’ MINIMUM USE ZONE FOR PLAY EQUIPMENT SHALL EXTEND NO LESS THAN 72” FROM ALL SIDES OF THE PLAY STRUCTURE. SWING USE ZONE EXTENDS NO LESS THAN 168”. SWINGS MUST HAVE A MINIMUM CLEARANCE OF 8” ABOVE THE PROTECTIVE SURFACING. 10 3 83 to Swing Hanger Pivot...
  • Page 6 REMEMBER- If you are missing anything, please DO NOT RETURN to the store where purchased. Contact our Customer Service Department at 1-800-888-1232 or email us at: service@swing-n-slide.com For ease in inventorying your wooden playset parts all have been marked with a part number. Look for the part number typically located on the end of the part.
  • Page 7 ASSEMBLY INSTRUCTIONS TERRACE MODULE: SA6001 Swing•N•Slide • 1212 Barberry Drive • Janesville, Wisconsin 53545 (2) [PF 6002] 3/4’’ x 3-3/8’’ x 22-1/2’’ Visit our web site at: www.swing-n-slide.com or call us at 1-800-888-1232 © Swing-N-Slide Inc. Printed in USA LDR 12-28-2017 LA 9370 (1) [PF 6029] 5/8’’...
  • Page 8 TOWER MODULE SA6051 / SA6022 COMPONENTS CONT. 5/16’’ x 5-1/2’’ Swing Hanger (x6) Window Pane (x2) Play Handle (x2) Alpine Slide (x1) STD Swing Seat (x2) Wind Rider Handle (x1) Wind Rider Seat (x1) Quick Link (x8) 58” Dipped Chain (x4) 51”...
  • Page 9 TOWER MODULE SA6051 / SA6022 HARDWARE 1/4’’ Washer (x16) 5/16” Washer (x24) 5/16’’ Loc Washer (x12) 5/16” Loc Nut (x9) 1/4’’ Loc Washer (x12) #12 x 3/4” Truss Screw (x14) 5/16” Wood Loc 1/4’’ x 1-3/4” Pan Screw (x4) Washer (x3) FS2831 FS2831 FS2831...
  • Page 10 /16’’ x 3’’ x 62’’ A-FRAME SUPPORT (2) [PF 6060] 5/8’’ x 5-3/8’’ x 13’’ SUN TERRACE MODULE SA6001 ’’ x 3-3/8’’ x 83’’ A-FRAME LEGS BOARD LIST (4) [PF 6001] 5/8’’ x 5-3/8’’ x 9-1/4’’ TERRACE MODULE: SA6001 ’’ x 3-3/8’’ x 60’’ ROCKWALL SUPPORT (1) [PF 6061] 1-1/2’’...
  • Page 11 MONKEY BAR SA6006 BOARD LIST MONKEY BARS MODULE: SA6006 / SA6022 (1) [PF 6041] 1-3/8’’ x 3-3/8’’ x 29-1/4’’ (2) [PF 6042] 1-3/8’’ x 3-3/8’’ x 32’’ (2) [PF 6043] 1-3/8’’ x 3-3/8’’ x 60’’ (2) [PF 6045] 1-3/8’’ x 3-3/8’’ x 79-7/8’’ (1) [PF 6044] 1’’...
  • Page 12 (5) [PF 6005] 3/4’’ x 3-3/8’’ x 42’’ (1) [PF 6034] 1-3/8’’ x 3-3/8’’ x 66-1/4’’ LADDER SUPPORT-L (1) [PF 6022] 3/4’’ x 3-3/8’’ x 19-1/2’’ (2) [PF 6003] 3/4’’ x 3-3/8’’ x 35-7/8’’ (1) [PF 6035] 1-3/8’’ x 3-3/8’’ x 66-1/4’’ LADDER SUPPORT-R LADDER MODULE SA6005 (2) [PF 6002] 3/4’’...
  • Page 13 FORT ENCLOSURE BOARD LIST (7) [PF 6407] 5/8’’ x 5-3/8’’ x 29-5/8’’ (1) [PF 6408] 3/4’’ x 5-3/8’’ x 41-1/2’’ (1) [PF 6410] 3/4’’ x 5-3/8’’ x 41-1/2’’ ARCHED (1) [PF 6409] 3/4’’ x 3-3/8’’ x 41-1/2’’ (2) [PF 6415] 1-3/8’’ x 1-3/8’’ x 3-3/8’’ (4) [PF 6416] 1-3/8’’...
  • Page 14 STEP 1 6’’ 47-1/2’’ 2-1/2’’ Screws Flush 6’’ 2-1/2’’ Screws T-Nut Small 2-1/2’’ Screws 5/16-18 X 4’’ Hex Head Bolt 5/16’’ Washer 5/16’’Loc-Washer 59-1/4’’ 57-9/16’’ FRAME A 2-1/2’’ Screws 1-1/2’’ Hint!! Use parts from your Tower Box. BOTH SIDES 2-1/2” Deck Screw (x14) 1.
  • Page 15 STEP 2 6’’ 47-1/2’’ 2-1/2’’ Screws Flush 6’’ 2-1/2’’ Screws T-Nut Small 2-1/2’’ Screws 5/16-18 X 4’’ Hex Head Bolt 5/16’’ Washer 5/16’’Loc-Washer 2-1/2’’ Screws 57-9/16’’ 2-1/2’’ Screws 59-1/4’’ 31’’ FRAME B 2-1/2’’ Screws 1-1/2’’ JOINTS 2-1/2” Deck Screw (x18) 1.
  • Page 16 STEP 3 Check to make sure 2-1/2’’ Screws 2-1/2’’ Screws structure is square Flush 2-1/2’’ Screws 59-1/4’’ Flush 2-1/2’’ Screws 2-1/2’’ Screws FRAME A 2-1/2” Deck Screw (x11) 1. Attach support boards to Frame A as shown.
  • Page 17 STEP 4 2-1/2’’ Screws Check to make sure structure is square 2-1/2’’ Screws 2-1/2’’ Screws FRAME B FRAME A 2-1/2’’ Screws 2-1/2” Deck Screw (x11) 1. Attach Frame A to Frame B as shown.
  • Page 18 STEP 5 2-1/2’’ Screws PF 6149 1-3/8’’ x 3-3/8’’ x 15-1/2’’ DECK SUPPORT Flush Flush 1-3/4’’ Screw per joint (4) 3’’ Screw 1-3/4” Deck Screw (x6) 3” Deck Screw (x4) 1. Install Deck Supports as shown.
  • Page 19 STEP 6 PF 6003 3/4’’ x 3-3/8’’ x 35-7/8’’ 1-3/4’’ Screws 1-3/4’’ Screws PF 6003 3/4’’ x 3-3/8’’ x 35-7/8’’ 2-1/2’’ Screws PF 6011 1’’ x 3/8’’ x 47-1/2’’ 16-1/2’’ FS2831 PF 6011 1’’ x 3/8’’ x 47-1/2’’ FS2830 2-1/2 16-1/2’’...
  • Page 20 STEP 7 PF 6008 3/4’’ x 5-3/8’’ x 42’’ 1-3/4’’ Screws per deck board All Boards Flush With 3’’ x 3’’s 1-3/4” Deck Screw (x42) 1. Install Deck Boards as shown. NOTE: Standard gap between deck boards is 3/8’’.
  • Page 21 STEP 8 Flush PF 6002 3/4’’ x 3-3/8’’ x 22-1/2’’ Flush With 2-1/2’’ Screws 3’’ x 3’’s PF 6002 3/4’’ x 3-3/8’’ x 22-1/2’’ 2-1/2’’ Screws 2-1/2’’ Screws Flush With (2) PF 6005 3/4’’ x 3-3/8’’ x 42’’ Bottom of 62-5/8’’...
  • Page 22 STEP 9 Check to make sure structure is square 47-1/4’’ 2-1/2’’ Screws FRAME A 5/16-18 X 4’’ Hex Head Bolt 5/16’’Loc-Washer 5/16’’ Washer Hint!! Use parts from your Terrace Box. T-Nut Small 2-1/2” Deck Screw (x4) 1. Install Deck Support Board as shown.
  • Page 23 STEP 10 Check to make sure structure is square 2’’ Screws COUNTERBORE THIS SIDE Flush 2’’ Screws COUNTERBORE THIS SIDE 45-9/16’’ 2’’ Screws Flush FS2831 2’’ Screws FRAME C FS2830 2-1/2 FS2829 2” Deck Screw (x12) FS2828 1. Assemble Frame C as shown. 1-3/4 FS2827 1-5/8...
  • Page 24 STEP 11 Check to make sure structure is square 5/16-18 X 2’’ 47-1/4’’ Hex Head Bolt 5/16’’Loc-Washer 5/16’’ Washer 2’’ Screws T-Nut Small 2” Deck Screw (x4) 1. Install Deck Support Board as shown.
  • Page 25 STEP 12 Flush With Outside Face of 1-3/8” x 3’’ 2-1/2’’ Screws Check to make sure structure is square Flush With Flush With Top of Outside Flush With Frame Face of Top of 1-3/8” x 3’’ Frame HINT: Use part from Monkey Bar box (PF 6041) 2-1/2’’...
  • Page 26 STEP 13 Check to make sure structure is square 2-1/2’’ Screws 79’’ 2-1/2’’ Screws 2-1/2’’ Screws 2-1/2’’ Screws 2-1/2’’ Screws FRAME C 2-1/2” Deck Screw (x13) 1. Attach Frame C to Tower as shown.
  • Page 27 STEP 14 1-3/4’’ Screws 1-3/4’’ Screws PF 6150 3/4’’ x 3-3/8’’ x 24-3/4’’ PF 6150 3/4’’ x 3-3/8’’ x 24-3/4’’ 1-3/4’’ Screws 1-3/4’’ Screws PF 6150 3/4’’ x 3-3/8’’ x 24-3/4’’ 1-3/4’’ Screws PF 6061 1-1/2’’ x 1-1/2’’ x 40’’ 1-3/4’’...
  • Page 28 STEP 15 All Boards PF 6135 3/4’’ x 5-3/8’’ x 26-1/4’’ Flush 1-3/4’’ Screws per board Note: Holes 1-7/8’’ From Edge on This Side 1-3/4” Deck Screw (x36) 1. Install Deck Boards as shown. NOTE: Standard gap between deck boards is 7/16’’.
  • Page 29 STEP 16 PF 6023 3/4’’ x 3-3/8’’ x 22-1/2’’ 2’’ Screws PF 6022 3/4’’ x 3-3/8’’ x 19-1/2’’ 2’’ Screws 50-5/8’’ 2” Deck Screw (x6) 1. Install Barrier Support Boards as shown.
  • Page 30 STEP 17 PF 6004 3/4’’ x 3-3/8’’ x 42’’ 2-1/2’’ Screws PF 6005 3/4’’ x 3-3/8’’ x 42’’ 2-1/2’’ Screws 5-3/8’’ 53-7/8’’ 2-1/2” Deck Screw (x12) 1. Attach Gap Filler Boards as shown.
  • Page 31 STEP 18 1-7/8’’ (6) PF 6021 5/8’’ x 5-3/8’’ x 30-3/4’’ 1-1/4’’ Screws per board Panel Bracket #12 x 3/4” Pan Screw (x8) 3/4’’ Pan Screws INSIDE VIEW 1-1/4” Deck Screw (x24) 1. Install Barrier Boards as shown. No gaps between boards.
  • Page 32 STEP 19 1’’ 1’’ 3-1/8’’ 3-1/8’’ 1-5/8’’ PF 6172 5/8’’ x 3-3/8’’ x 11-1/2’’ PF 6001 5/8’’ x 5-3/8’’ x 9-1/4’’ PRE-DRILL (4) 1/8’’ 1/2’’ GAP 1/2’’ GAP HOLES PF 6172 5/8’’ x 3-3/8’’ x 11-1/2’’ 30mm Screws 17-3/8’’ per board FS2831 FS2830 PF 6172...
  • Page 33 STEP 20 1’’ 1-1/4’’ Screws per board 1-1/4’’ Screws per board 1-1/4’’ Screws per board 1-1/4’’ Screws per board FS2831 Panel Bracket FS2830 2-1/2 FS2829 3/4’’ Pan Screws FS2828 1-3/4 FS2827 1-5/8 FS2826 1-1/4 1-1/4” Deck Screw (x24) #12 x 3/4” Pan Screw (x8) FS2826 Install Window Panels.
  • Page 34 STEP 21 PF 6020 3’’ x 3’’ x 47-1/2’’ SWING BEAM SUPPORT TOP OF BEAM SUPPORT 84’’ FROM BOTTOM OF POST Loc Nut 5/16’’ Washer Wood Loc-Washer 5/16-18 X 6’’ Carriage Bolt 1. Install Swing Beam Support as shown.
  • Page 35 STEP 22 PF 6019 2-11/16’’x5-3/8’’x93’’ Swing Beam 5/16’’ T-Nut 5-1/2’’ Swing Large Hanger Beam Clamp FS2831 FS2830 2-1/2 FS2829 FS2828 1-3/4 FS2827 1-5/8 (4) 1-1/4’’ Deck Screws FS2826 Correct Orientation 1-1/4 1-1/4” Deck Screw (x24) FS2826 1. Attach Swing Hanger(s) to swing beam as shown. NOTE: Make certain hanger and plate are snug against the bottom of the swing beam, (Fig 5), before installing screws.
  • Page 36 STEP 23 PF 6018 2-11/16’’x3’’x62’’ A-Frame SB Support 5/16”-18 x 7” Hex Head Bolt 3’’ Screws 3’’ Screws 5/16” Washer 5/16” Washer 5/16” Loc Nut (2) PF 6017 1-3/8’’x3-3/8’’x83’’ A-Frame 5/16”-18 x 2-1/2” Hex Head Bolt 5/16” Loc Washer 5/16” Washer 5/16”...
  • Page 37 STEP 24 (2) Swing Beam Bracket 5/16”-18 x 3-1/2” Hex Head Bolt 5/16” Washer 5/16” Loc Nut 5/16”-18 x 3-1/2” 5/16” Washer Hex Head Bolt 5/16” Washer 5/16” Washer 5/16” Loc Nut 1. Attach Swing Beam Bracket to A-Frame & Swing Beam as shown.
  • Page 38 STEP 25 Beam Brace 5/16”-18 x 3 1/4” Hex Head Bolt 5/16” Loc Washer 5/16” Washer 5/16-18 T-Nut Small 1. Install Swing Beam Brace as shown.
  • Page 39 STEP 26 5/16”-18 x 6” 5/16”-18 x 8-1/2” Carriage Bolt Hex Head Bolt 5/16” Loc Washer 5/16” Washer 5/16” Wood Loc Washer 5/16-18 T-Nut Small 5/16” Washer 5/16” Loc Nut 1. Install Swing Beam as shown.
  • Page 40 STEP 27 BARRIER BOARD SPACING: (4) 30mm Outer boards will be fl ush Screws PF 6000 5/8’’ x 5-3/8’’ x 33-3/4’’ against 3’’ x 3’’ Uprights. per board All boards inbetween will have a 3/4’’ gap. 30mm Deck Screw (x24) 1.
  • Page 41 STEP 28 (1) 3’’ Deck Screws 1-5/8’’ 1-5/8’’ 13-1/2’’ Check to make sure structure is square PF 6058 5/8’’ x 3-3/8’’ x 30’’ (4) 1-1/4’’ Deck Screws 3/4’’ FS2831 FS2830 2-1/2 CENTERED PF 6060 5/8’’ x 5-3/8’’ x 13’’ SUN FS2829 30mm FS2828...
  • Page 42 STEP 29 (4) 30mm (6) 1-1/4’’ Screws Screws (1) PF 6056 5/8’’ x 2’’ x 10’’ (2) PF 6059 5/8’’ x 2’’ x 7’’ Note: Place screws through A-Frame and CENTERED Note: PF 6053 into end of PF 6053 Rests on Top of PF 6056 2-1/2’’...
  • Page 43 STEP 30 Flush Flush 2’’ Screws 2’’ Screws 2” Deck Screw (x8) 1. Attach Roof Side Support Boards as shown.
  • Page 44 STEP 31 Flush At Ends 1-5/8’’ Screws 1-5/8’’ Screws 1-5/8’’ Screws 1-5/8’’ Screws 1-5/8” Deck Screw (x12) Attach Roof Frame to Tower as shown.
  • Page 45 STEP 32 3/4’’ Screws 3/16’’ Tarp Washer 3/4” Pan Head Screw (x6) 3/16” Tarp Washer (x6) 1. Attach Tarp as shown. Note: Wrap Tarp around each end board and secure from inside of roof, as shown.
  • Page 46 STEP 33 2-1/2’’ Screws per Rung 2-1/2’’ Screws per Rung (5) PF 6032 1’’ x 3-3/8’’ x 18-1/2’’ PF 6029 5/8’’ x 3-3/8’’ x 20-1/2‘’ 2-1/2’’ Screws 2’’ Hint!! Use parts from your Ladder Box. 2-1/2” Deck Screw (x24) 1. Assembly Ladder as shown.
  • Page 47 STEP 34 2-1/2’’ Screws 2-1/2’’ Screws Panel Bracket 3/4’’ Pan Screw FS2831 FS2830 2-1/2” Deck Screw (x3) 2-1/2 #12 x 3/4” Pan Screw (x4) FS2829 1. Attach Ladder to Tower as shown. FS2828...
  • Page 48 STEP 35 Under Deck View PF 6452 1-3/8’’ x 3-3/8’’ x 22’’ Flush to PF 6452 1-3/8’’ x 3-3/8’’ x 22’’ Support 2-1/2’’ Screws per block 1-3/4’’ Screws 53-7/8’’ 1/8’’ Gap Between PF 6416 and PF 6452 31’’ Flush to 3x3” Upright 3-3/8’’...
  • Page 49 STEP 36 30mm Screws per side PF 6410 3/4’’ x 5-3/8’’ x 41-1/2’’ ARCHED Flush 2-1/2’’ Screws per side Flush Under Deck View PF 6024 3/4’’ x 3-3/8’’ x 27-3/4’’ PF 6408 3/4’’ x 5-3/8’’ x 41-1/2’’ Flush 30mm Screws 31’’...
  • Page 50 STEP 37 ALIGN SCREWS WITH PRE DRILLS (1) PF 6013 5/8’’ x 5-3/8’’ x 22-3/4’’ ROCK WALL BOARD (6) PF 6389 5/8’’ x 5-3/8’’ x 22-3/4’’ ROCK WALL BOARDS (4) 2’’ Deck Screws per board (1) PF 6013 5/8’’ x 5-3/8’’ x 22-3/4’’ ROCK WALL BOARD 2”...
  • Page 51 STEP 38 2-1/2’’ Screws per side Under Deck View 2-1/2” Deck Screw (x6) 1. Attach Rock Wall as shown.
  • Page 52 STEP 39 (2) 1/4’’ T-Nuts (2) 1-1/4’’ Hex Head Bolts (2) 1/4’’ Flat Washer Per Rock (2) 1/4’’ Loc-Washer Per Rock 1. Attach Climbing Rocks as shown.
  • Page 53 STEP 40 (2) PF 6039 3/4’’ x 3-3/8’’ x 9-3/4’’ (2) PF 6133 3/4’’ x 3-3/8’’ x 41-1/2’’ TABLE 2’’ Screws TABLE SUPPORT 2-3/4’’ OUTSIDE (2) PF 6037 3/4’’ x 3-3/8’’ x 15-3/4’’ 3’’ 3’’ FACE TO BENCH SUPPORT OUTSIDE FACE, 2’’...
  • Page 54 STEP 41 Slide 3’’ 1-1/4” Truss Screws Side View 1-1/4” Truss Screws 2” Grade (2) 30mm Deck Screws PF 6009 1-3/8’’x3-3/8’’x17-1/4’’ Slide Stake 1-1/4” Truss Screw (x4) 30mm Deck Screw (x2) 1. Attach slide as shown.
  • Page 55 STEP 42 Flush ‘L’ Brackets 1-1/4’’ Pan Head Screws per L Bracket 49-1/4’’ Short Monkey 38-1/4’’ Bar Rungs 2-1/2’’ Pan Head Screws 27-1/4’’ per rung 16-1/4’’ 5-1/4’’ 19’’ T-Nut 5/16’’ Washer Small 5/16’’Loc-Washer 5/16-18 X 1-1/2’’ Hex Head Bolt Triangle Brackets 2-1/2”...
  • Page 56 STEP 43 Monkey Bar 36-1/4’’ Rungs 2-1/2’’ Pan Head Screws per rung 24-1/2’’ 12-3/4’’ Flush 22’’ 2-1/2’’ Screws PF 6044 1’’ x 3-3/8’’ x 58’’ T-Nut Small (2) PF 6042 1-3/8’’ x 3-3/8’’ x 32’’ 5/16’’ Washer 5/16’’Loc-Washer 5/16-18 X 3-1/2’’ Hex Head Bolt 5/16’’...
  • Page 57 STEP 44 5/16-18 X 3’’ Hex Head Bolt 5/16’’Loc-Washer 5/16’’ Washer T-Nut Small 5/16-18 X 1-1/2’’ Hex Head Bolt 5/16’’Loc-Washer 5/16’’ Washer T-Nut Small Flush 1-1/4’’ Pan Head Screws per L Bracket 1-1/4” Pan Head Screw (x6) 1” Truss Screw (x4) 1.
  • Page 58 STEP 45 Back View Front View (2) 1/4” Washer (2) 1/4’’ x 1-3/4” Pan Screw 11” 1/2” Pan Screw (x2) 1-3/4” Pan Screw (x4) 1. Attach Safety Handle and I.D. Tag as shown.
  • Page 59 STEP 46 Wind Rider 51” Un-Coated chain Loc-Nut 5/16’’ Flat Washer QuickLink 5/16’’ Flat Washer 5/16”-18 x 6-1/2” Hex Bolt QuickLink Wind-Rider Wind Rider Assembly 1. Insert Seat into Handle as shown in (Step1). Secure in place with hardware shown. Note: Make certain no more than two bolt threads protrude from the Loc-Nut once fully tightened.
  • Page 60 STEP 47 PLASTIC COATED END Swing Seat Assembly 1. Take one length of chain and place the outermost link of coated chain through the Quick Link as shown. 2. Place the Quick Link through the Grommet of the swing seat as shown. 3.
  • Page 61 STEP 48 5/16” Washer Fold up Anchor-It Strap 1-1/2” Lag Screw Anchor-It 5/16’’ x 1-1/2” Lag Screw (x6) 1. Place swing set in fi nal location and mount Anchor-It(s) at locations circled above. 2. Twist the Anchor-It into the ground until only the loop is exposed. 3.
  • Page 62 Swing-N-Slide® will repair, or at its discretion, replace any part within the stated warranty period which is defective in workmanship or materials. This decision is subject to verification of the defect upon delivery of the defective part to Swing-N-Slide® at 1212 Barberry Drive, Janesville, Wisconsin, 53545.
  • Page 63 & registration ■ Quick & simple from home or mobile ■ Record your purchase in our system ■ Initiate product warranty ■ Improved customer support ■ Register your product online at www.OnlineWarranty.net © Swing-N-Slide Inc. 2018 Printed in USA...
  • Page 64 Call our Customer Support Representatives 1-800-888-1232 Available Monday - Friday, 7am - 5pm (CST) Weekend support available April through July Technical support from experienced Swing-N-Slide customer service representatives who have actually built a swing set themselves. © Swing-N-Slide Inc. 2018 Printed in USA...
