WS 8357
IMPORTANT!!
PLEASE READ BEFORE BEGINNING ASSEMBLY!!
Please make sure all lumber, hardware and accessory parts are accounted for.
If you are missing anything, please DO NOT RETURN to the store where purchased.
Please call our Customer Service Department at the number below.
ASSEMBLY INSTRUCTIONS
LDR 2-22-2018

Advertisement

loading
Need help?

Need help?

Do you have a question about the WS 8357 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Swing-N-Slide WS 8357

Summary of Contents for Swing-N-Slide WS 8357

  • Page 1 WS 8357 IMPORTANT!! PLEASE READ BEFORE BEGINNING ASSEMBLY!! Please make sure all lumber, hardware and accessory parts are accounted for. If you are missing anything, please DO NOT RETURN to the store where purchased. Please call our Customer Service Department at the number below.
  • Page 4 6 ft. 6 ft. Denotes Use Zone with Protective Surfacing L+6 ft. 6 ft. Denotes Use Zone with Protective Surfacing 6 ft. 6 ft. 6 ft. Use Zone for Single-Axis Swings Use Zone for Multi-Axis Swings...
  • Page 5 PLAYSET SAFETY ZONE 15'-1" 14'-0" 6'-0" 6'-0" 6'-0" 28'-0 7/16" 28'-0" 11'-11 7/8" 6'-0" 14'-0" 6'-0" 27'-0 15/16" MINIMUM USE ZONE FOR PLAY EQUIPMENT SHALL EXTEND NO LESS THAN 72” FROM ALL SIDES OF THE PLAY STRUCTURE. SWING USE ZONE EXTENDS NO LESS THAN 168”. SWINGS MUST HAVE A MINIMUM CLEARANCE OF 8”...

  • Page 6: Tools Required

    REMEMBER- If you are missing anything, please DO NOT RETURN to the store where purchased. Contact our Customer Service Department at 1-800-888-1232 or email us at: service@swing-n-slide.com For ease in inventorying your wooden playset parts all have been marked with a part number. Look for the part number typically located on the end of the part.

  • Page 7: Board List

    (4) [PF 6062] 1’’ x 3-3/8’’ x 42-1/2’’ ROOF A-FRAME TOWER COMPONENTS (7) [PF 6008] 3/4’’ x 5-3/8’’ x 42’’ WS 8357 (2) [PF 6013] 5/8’’ x 5-3/8’’ x 22-3/4’’ ROCKWALL BOARD (10) [PF 6000] 5/8’’ x 5-3/8’’ x 33-3/4’’...
  • Page 8 TOWER MODULE SA 6081 /SA6022 COMPONENTS CONT. Coolwave Slide (x1) HD Ring-Trap (x1) HD Swing Seat (x2) HD Swing Hanger (x6) Climbing Rock (x6) Safety Handle (x2) Tarp (x1) Quick Link (x6) Anchor It (x4) Anchor It Strap (x4) (x1) Square Bit 5/16’’...
  • Page 9 TOWER MODULE SA 6081 /SA6022 HARDWARE 5/16-18 T-Nut (x28) Small 1/4’’ Loc Washer (x12) 5/16” Washer (x36) 1/4’’ Washer (x16) 5/16’’ Loc Washer (x12) 1/4’’ T-Nut (x12) #8 x 1/2” Pan Screw (x2) #12 x 3/4” Pan Screw (x14) 3/4” Flat Head Screw (x20) 30mm Deck Screw (x162) 1-5/8”...
  • Page 10 TERRACE MODULE SA 6031 BOARD LIST (1) [PF 6061] 1-1/2’’ x 1-1/2’’ x 40’’ (2) [PF 6028] 1-3/8’’ x 3’’ x 79’’ (2) [PF 6026] 1’’ x 3-3/8’’ x 42’’ (3) [PF 6005] 3/4’’ x 3-3/8’’ x 42’’ (4) [PF 6025] 3/4’’ x 3-3/8’’ x 29-1/4’’ (3) [PF 6024] 3/4’’...
  • Page 11 LADDER MODULE SA6005 PICNIC TABLE MODULE SA6018 BOARD LIST BOARD LIST (1) [PF 6034] 1-3/8’’ x 3-3/8’’ x 66-1/4’’ LADDER SUPPORT-L (1) [PF 6040] 1’’ x 5-3/8’’ x 41-1/2’’ BENCH (1) [PF 6035] 1-3/8’’ x 3-3/8’’ x 66-1/4’’ LADDER SUPPORT-R (2) [PF 6133] 3/4’’...
  • Page 12 FORT ENCLOSURE SA6036 BOARD LIST (7) [PF 6407] 5/8’’ x 5-3/8’’ x 29-5/8’’ (1) [PF 6408] 3/4’’ x 5-3/8’’ x 41-1/2’’ (1) [PF 6410] 3/4’’ x 5-3/8’’ x 41-1/2’’ ARCHED (1) [PF 6409] 3/4’’ x 3-3/8’’ x 41-1/2’’ (2) [PF 6414] 5/8’’ x 3-3/8’’ x 29-5/8’’ (2) [PF 6415] 1-3/8’’...
  • Page 13 STEP 1 6’’ 47-1/2’’ 2-1/2’’ Screws Flush 6’’ 2-1/2’’ Screws T-Nut Small 2-1/2’’ Screws 5/16-18 X 4’’ Hex Head Bolt 5/16’’ Washer 5/16’’Loc-Washer 59-1/4’’ FRAME A 2-1/2’’ Screws 1-1/2’’ Hint!! Use parts from your Tower Box. BOTH SIDES 2-1/2” Deck Screw (x14) 1.
  • Page 14 STEP 2 6’’ 47-1/2’’ 2-1/2’’ Screws Flush 6’’ 2-1/2’’ Screws T-Nut Small 2-1/2’’ Screws 5/16-18 X 4’’ Hex Head Bolt 5/16’’ Washer 5/16’’Loc-Washer 59-1/4’’ 2-1/2’’ Screws 2-1/2’’ Screws FRAME B 2-1/2’’ Screws 1-1/2’’ JOINTS 2-1/2” Deck Screw (x14) 1. Assemble Frame B as shown above. Note: Tap each T-Nut into its pre-drilled hole until the metal tangs sink fully into the wood.
  • Page 15 STEP 3 2-1/2’’ Screws Check to make sure struc- ture is square Flush 2-1/2’’ Screws 2-1/2’’ Screws Flush 2-1/2’’ Screws 2-1/2’’ Screws 59-1/4’’ FRAME A 2-1/2” Deck Screw (x13) 1. Attach support boards to Frame A as shown.
  • Page 16 STEP 4 Check to make sure struc- ture is square 2-1/2’’ Screws 2-1/2’’ Screws 2-1/2’’ Screws 2-1/2’’ Screws FRAME B 2-1/2’’ Screws FRAME A 2-1/2” Deck Screw (x13) 1. Attach Frame A to Frame B as shown.
  • Page 17 STEP 5 PF 6003 3/4’’ x 3-3/8’’ x 35-7/8’’ 1-3/4’’ Screws 2-1/2’’ Screws 1-3/4’’ Screws PF 6003 3/4’’ x 3-3/8’’ x 35-7/8’’ 2-1/2’’ Screws PF 6011 1’’ x 3-3/8’’ x 47-1/2’’ 16-1/2’’ PF 6011 1’’ x 3-3/8’’ x 47-1/2’’ 16-1/2’’ 1-3/4”...
  • Page 18 STEP 6 PF 6008 3/4’’ x 5-3/8’’ x 42’’ 1-3/4’’ Screws per board 1-3/4” Deck Screw (x42) 1. Install Deck Boards as shown. NOTE: Standard gap between deck boards is 3/8’’.
  • Page 19 STEP 7 Flush 1-3/4’’ Screw per joint (4) 3’’ Screw NOTE: PRE-DRILLED HOLES PF 6149 1-3/8’’ x 3-3/8’’ x 15-1/2’’ Flush DECK SUPPORT NOTE: Insert Hardware From Outside 2-1/2’’ Screws 31’’ 2-1/2’’ Screws 1-3/4” Deck Screw (x6) 2-1/2” Deck Screw (x6) 3”...
  • Page 20 STEP 8 Check to make sure struc- ture is square 2-1/2’’ Screws 5/16-18 X 4’’ Hex Head Bolt 5/16’’Loc-Washer 5/16’’ Washer T-Nut Small 47-1/4’’ Flush Hint!! Use parts from your Terrace Box. 2-1/2” Deck Screw (x4) 1. Install Deck Support Board as shown.
  • Page 21 STEP 9 Check to make sure struc- ture is square 2’’ Screws Flush 2’’ Screws 2’’ Screws Flush 2’’ Screws FRAME C 2” Deck Screw (x12) 1. Assemble Frame C as shown.
  • Page 22 STEP 10 Check to make sure struc- ture is square 5/16-18 X 2’’ Hex Head Bolt 47-1/4’’ 5/16’’Loc-Washer 5/16’’ Washer 2’’ Screws T-Nut Small 2” Deck Screw (x4) 1. Install Deck Support Board as shown.
  • Page 23 STEP 11 Flush With Outside Face of 2-1/2’’ Screws 1-3/8’’ x 3’’ Check to make sure structure is square Flush With Top of Flush With Frame Flush With Top of Outside Frame Face of 1-3/8’’ x 3’’ 2-1/2’’ Screws 2-1/2’’ Screws Flush With Outside Face of...
  • Page 24 STEP 12 Check to make sure struc- ture is square 2-1/2’’ Screws 2-1/2’’ Screws 2-1/2’’ Screws 79’’ 2-1/2’’ Screws 2-1/2’’ Screws FRAME C 2-1/2” Deck Screw (x12) 1. Attach Frame C to Tower as shown.
  • Page 25 STEP 13 1-3/4’’ Screws 1-3/4’’ Screws PF 6150 3/4’’ x 3-3/8’’ x 24-3/4’’ 1-3/4’’ Screws 1-3/4’’ Screws PF 6150 3/4’’ x 3-3/8’’ x 24-3/4’’ PF 6061 1-1/2’’ x 1-1/2’’ x 40’’ 1-3/4’’ Screws 1-3/4’’ Screws PF 6150 3/4’’ x 3-3/8’’ x 24-3/4’’ 10-5/8’’...
  • Page 26 STEP 14 All Boards PF 6135 3/4’’ x 5-3/8’’ x 26-1/4’’ Flush 1-3/4’’ Screws per board Note: Holes 1-7/8’’ From Edge on This Side 1-3/4” Deck Screw (x36) 1. Install Deck Boards as shown. NOTE: Standard gap between deck boards is 7/16’’.
  • Page 27 STEP 15 PF 6022 3/4’’ x 3-3/8’’ x 19-1/2’’ 2’’ Screws PF 6023 3/4’’ x 3-3/8’’ x 22-1/2’’ 2’’ Screws 50-5/8’’ 2” Deck Screw (x6) 1. Install Barrier Support Boards as shown.
  • Page 28 STEP 16 PF 6005 3/4’’ x 3-3/8’’ x 42’’ 2-1/2’’ Screws 53-7/8’’ 2-1/2” Deck Screw (x6) 1. Attach Gap Filler Boards as shown.
  • Page 29 STEP 17 (4) PF 6021 5/8’’ x 5-3/8’’ x 30-3/4’’ 30mm Screws 2-7/8’’ per board 2-7/8’’ 2-7/8’’ 2-7/8’’ 2-7/8’’ Panel Bracket #12 x 3/4” Pan Screw (x8) 3/4’’ Pan Screws INSIDE VIEW 30mm Deck Screw (x16) 1. Install Barrier Boards as shown.
  • Page 30 STEP 18 (3) PF 6021 5/8’’ x 5-3/8’’ x 30-3/4’’ 2-1/8’’ 2-1/8’’ 30mm Screws 2-1/8’’ per board 30mm Deck Screw (x12) 1. Attach Barrier Boards as shown.
  • Page 31 STEP 19 PF 6002 3/4’’ x 3-3/8’’ x 22-1/2’’ 2-1/2’’ Screws Flush 2-1/2’’ Screws PF 6005 3/4’’ x 3-3/8’’ x 42’’ PF 6002 2-1/2’’ Screws 3/4’’ x 3-3/8’’ x 22-1/2’’ 2-1/2’’ Screws Flush 2-1/2’’ Screws 62-5/8’’ 2-1/2” Deck Screw (x10) 1.
  • Page 32 STEP 20 1’’ 1’’ 3-1/8’’ 3-1/8’’ 1-5/8’’ PF 6172 5/8’’ x 3-3/8’’ x 11-1/2’’ PF 6001 5/8’’ x 5-3/8’’ x 9-1/4’’ PRE-DRILL (4) 1/8’’ 1/2’’ GAP 1/2’’ GAP HOLES PF 6172 5/8’’ x 3-3/8’’ x 11-1/2’’ 30mm Screws 17-3/8’’ per board PF 6172 5/8’’...
  • Page 33 STEP 21 1’’ 30mm Screws per board 30mm Screws per board Panel Bracket 3/4’’ Pan Screws #12 x 3/4” Pan Screw (x8) 30mm Deck Screw (x24) Install Window Panels.
  • Page 34 STEP 22 PF 6020 3’’ x 3’’ x 47-1/2’’ SWING BEAM SUPPORT TOP OF BEAM SUPPORT 84’’ FROM BOTTOM OF POST Loc Nut 5/16’’ Washer Wood Loc-Washer 5/16-18 X 6’’ Carriage Bolt 1. Install Swing beam support as shown.
  • Page 35 STEP 23 CENTER PF 6019 TOWER 2-11/16’’x5-3/8’’x93’’ THIS SIDE Swing Beam MARK HOLE LOCATION = DRILL HERE (6 PLACES) 30mm Deck Screw (4 per Clamp) 5/16”-18 x 6-1/2” Carriage Bolt 5/16” Clamp, Beam HD Swing Hanger 5/16” Washer A-FRAME 5/16” THIS SIDE Loc Nut 1.
  • Page 36 STEP 24 PF 6018 2-11/16’’x3’’x62’’ A-Frame SB Support 5/16”-18 x 7” Hex Head Bolt 3’’ Screws 3’’ Screws 5/16” Washer 5/16” Washer 5/16” Loc Nut (2) PF 6017 1-3/8’’x3-3/8’’x83’’ A-Frame 5/16”-18 x 2-1/2” Hex Head Bolt 5/16” Loc Washer 5/16” Washer 5/16”...
  • Page 37 STEP 25 (2) Swing Beam Bracket 5/16”-18 x 3-1/2” Hex Head Bolt 5/16” Washer 5/16” Loc Nut 5/16”-18 x 3-1/2” 5/16” Washer Hex Head Bolt 5/16” Washer 5/16” Washer 5/16” Loc Nut 1. Attach Swing Beam Bracket to A-Frame & Swing Beam as shown.
  • Page 38 STEP 26 Beam Brace 5/16”-18 x 3 1/4” Hex Head Bolt 5/16” Loc Washer 5/16” Washer 5/16-18 T-Nut Small 1. Install Swing Beam Brace as shown.
  • Page 39 STEP 27 5/16”-18 x 6” 5/16”-18 x 8-1/2” Carriage Bolt Hex Head Bolt 5/16” Loc Washer 5/16” Washer 5/16” Wood Loc Washer 5/16-18 T-Nut Small 5/16” Washer 5/16” Loc Nut 1. Install Swing Beam as shown.
  • Page 40 STEP 28 (4) 30mm Screws per board PF 6000 5/8’’ x 5-3/8’’ x 33-3/4’’ BARRIER BOARD SPACING: against 3’’ x 3’’ Uprights. All boards inbetween will have a 3/4’’ gap. 30mm Deck Screw (x24) 1. Install Barrier Boards as shown.
  • Page 41 STEP 29 (1) 3’’ Deck Screws 1-5/8’’ 1-5/8’’ 13-1/2’’ Check to make sure struc- ture is square PF 6058 5/8’’ x 3-3/8’’ x 30’’ (4) 30mm Deck Screws 3/4’’ CENTERED PF 6060 5/8’’ x 5-3/8’’ x 13’’ SUN (4) 30mm Screws 3”...
  • Page 42 STEP 30 (4) 30mm (6) 30mm Screws Screws (1) PF 6056 5/8’’ x 2’’ x 10’’ (2) PF 6059 5/8’’ x 2’’ x 7’’ Note: Place screws through A-Frame and CENTERED Note: PF 6053 into end of PF 6053 Rests on Top of 2-1/2’’...
  • Page 43 STEP 31 3/4’’ Offset 1-5/8’’ Screws Each Side Side View 1-5/8’’ Screws 1-5/8’’ Screws 1-5/8’’ Screws 1-5/8” Deck Screw (x12) Attach Roof Frame to Tower as shown.
  • Page 44 STEP 32 2’’ Screws 2’’ Screws 2” Deck Screw (x8) 1. Attach Roof Side Support Boards as shown.
  • Page 45 STEP 33 3/4’’ Screws 3/16’’ Tarp Washer 3/4” Pan Head Screw (x6) 3/16” Tarp Washer (x6) 1. Attach Tarp as shown.
  • Page 46 STEP 34 2-1/2’’ Screws per Rung 2-1/2’’ Screws per Rung (5) PF 6032 1’’ x 3-3/8’’ x 18-1/2’’ PF 6029 5/8’’ x 3-3/8’’ x 20-1/2‘’ 2-1/2’’ Screws 2’’ Hint!! Use parts from your Ladder Box. 2-1/2” Deck Screw (x24) 1. Assembly Ladder as shown.
  • Page 47 STEP 35 Panel Bracket 2-1/2’’ Screws 3/4’’ Pan Screw Underdeck View 2-1/2” Deck Screw (x3) #12 x 3/4” Pan Screw (x4) 1. Attach Ladder to Tower as shown.
  • Page 48 STEP 36 (2) PF 6039 3/4’’ x 3-3/8’’ x 9-3/4’’ (2) PF 6133 3/4’’ x 3-3/8’’ x 41-1/2’’ TABLE 2’’ Screws TABLE SUPPORT 2-3/4’’ OUTSIDE (2) PF 6037 3/4’’ x 3-3/8’’ x 15-3/4’’ 3’’ 3’’ FACE TO BENCH SUPPORT OUTSIDE FACE, 2’’...
  • Page 49 STEP 37 1-5/8’’ Screws per board PF 6410 3/4’’ x 5-3/8’’ x 41-1/2’’ ARCHED PF 6024 3/4’’ x 3-3/8’’ x 27-3/4’’ Flush Flush 2-1/2’’ Screws PF 6408 3/4’’ x 5-3/8’’ x 41-1/2’’ Flush 31’’ Flush PF 6409 3/4’’ x 3-3/8’’ x 41-1/2’’ 1-3/4’’...
  • Page 50 STEP 38 Flush Flush 30mm Screws 30mm Screws per board per board 2-1/4’’ GAP TO UPRIGHT 1’’ GAP 1’’ GAP SIDES BOTH (5) PF 6407 5/8’’ x 5-3/8’’ x 29-5/8’’ (3) PF 6021 5/8’’ x 5-3/8’’ x 30-3/4’’ (2) PF 6414 5/8’’ x 3-3/8’’ x 29-5/8’’ 2-1/8’’...
  • Page 51 STEP 39 ALIGN SCREWS WITH PRE DRILLS (1) PF 6013 5/8’’ x 5-3/8’’ x 22-3/4’’ ROCKWALL BOARD (6) PF 6389 5/8’’ x 5-3/8’’ x 22-3/4’’ ROCKWALL BOARDS (4) 2’’ Deck Screws per board (1) PF 6013 5/8’’ x 5-3/8’’ x 22-3/4’’ ROCKWALL BOARD 2”...
  • Page 52 STEP 40 Panel Bracket 3/4’’ Pan Screw 2-1/2’’ Screws Underdeck View 2-1/2” Deck Screw (x3) #12 x 3/4” Pan Screw (x4) 1. Attach Rock Wall as shown.
  • Page 53 STEP 41 (2) 1/4’’ T-Nuts (2) 1-1/4’’ Hex Head Bolts (2) 1/4’’ Flat Washer Per Rock (2) 1/4’’ Loc-Washer Per Rock 1. Attach Climbing Rocks as shown.
  • Page 54 STEP 42 (2) PF 6180 5/8’’ x 3-3/8’’ x 10-1/2’’ (6) 30mm Deck Screws Underdeck View Grade 2” (2) 30mm Deck Screws PF 6009 1-3/8’’x3-3/8’’x17-1/4’’ Slide Stake 30mm Deck Screw (x8) 1” Truss Screw (x3) Attach Slide Support Boards and Slide as shown.
  • Page 55 STEP 43 1/4” Washer 1/4’’ x 1-3/4” Pan Screw 11” Back View Front View 1/2” Pan Screw (x2) 1-3/4” Pan Screw (x2) 1. Attach Safety Handle and I.D. Tag as shown.
  • Page 56 STEP 44 FIG. A HD Ring-Trap Combo Assembly 1. Attach Ring-Trap Chain to Swing Hanger as shown in (Fig. A). 2. Tighten Quick Link to secure chains to Swing Hangers as shown in (Fig. A).
  • Page 57 STEP 45 FIG. A 8" Minimum HD Swing Seats 1. Attach Chain to Swing Hanger as shown in (Fig. A). 2. Tighten Quick Link to secure chains to Swing Hangers as shown in (Fig. A). NOTE: Once installed, there must be a minimum 8’’ clearance between the bottom of the swings and the surfacing.
  • Page 58 STEP 46 5/16” Washer Fold up Anchor-It Strap 1-1/2” Lag Screw Anchor-It 5/16’’ x 1-1/2” Lag Screw (x4) 2. Twist the Anchor-It into the ground until only the loop is exposed. 3. Place Anchor-It Strap thru loop, fold the ends together and attach to the unit as shown. Note: Keep as little play as possible using any of the holes in the strap that work best.

  • Page 59: Warranty Registration

    Swing-N-Slide® will repair, or at its discretion, replace any part within the stated warranty period which is defective in workmanship or chase, including the date of purchase. This warranty is valid only if the product is used for the purpose for which it was designed and installed at a residential, single family dwelling.
  • Page 60 Call our Customer Support Representatives 1-800-888-1232 Available Monday - Friday, 7am - 5pm (CST) Weekend support available April through July Technical support from experienced Swing-N-Slide customer service representatives who have actually built a swing set themselves. © Swing-N-Slide Inc. 2018 Printed in USA...
