VIPA TM-E 900-1E640 Manual

Teleservice module
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
This manual is part of the documentation package
with order number VIPA HB39E_TME and relevant for:
Product
Order number
TM-E Analog
VIPA 900-1E640
Manual
VIPA Accessories
Teleservice module
TM-E 900-1E640
Order-No.: VIPA HB39E_TME
Reference: RE_900-1E640
Rev. 09/11
as of state:
HW
FW
01
5.6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TM-E 900-1E640 and is the answer not in the manual?

Questions and answers

Related Manuals for VIPA TM-E 900-1E640

Summary of Contents for VIPA TM-E 900-1E640

  • Page 1 Manual VIPA Accessories Teleservice module TM-E 900-1E640 Order-No.: VIPA HB39E_TME Reference: RE_900-1E640 Rev. 09/11 This manual is part of the documentation package with order number VIPA HB39E_TME and relevant for: Product Order number as of state: TM-E Analog VIPA 900-1E640...
  • Page 3 Manual VIPA TM-E About this manual The information contained in this manual is supplied without warranties. The information is subject to change without notice. © Copyright 2009 VIPA, Gesellschaft für Visualisierung und Prozess- automatisierung mbH Ohmstraße 4, D-91074 Herzogenaurach, Tel.: +49 (91 32) 744 -0 Fax.: +49 (91 32) 744-1864...

  • Page 4: Assembly And Installation Guidelines

    VIPA PLCs. More information concerning this may be found in German and English at: suppport.ewon.biz www.ewon-online.de The module TM-E from VIPA is constructed in the same way as the module "eWON2001". Overview Chapter 1: Assembly and installation guidelines In this chapter you will find all information, required for assembly and installation of the TM-E module.

  • Page 5: Table Of Contents

    Manual VIPA TM-E Contents Contents User considerations ................. 1 Safety information ..................2 Chapter 1 Assembly and installation guidelines......1-1 Safety information for Users..............1-2 Installation dimensions ................. 1-3 Assembly....................1-4 Cabling....................1-6 Installation guidelines ................1-7 Chapter 2 Hardware description ............. 2-1 Properties.....................
  • Page 6 Manual VIPA TM-E Contents HB39E - TME - RE_900-1E640 - Rev. 09/11...

  • Page 7: User Considerations

    Manual VIPA TM-E User considerations User considerations This manual describes the Teleservice-Modul TM-E PSTN from VIPA. It Objective and contains a description of the construction, project implementation and contents usage. The manual is targeted at users who have a background in automation Target audience technology.

  • Page 8: Safety Information

    Manual VIPA TM-E Safety information Safety information The Teleservice-Modul TM-E is constructed and produced for: Applications conforming with • communication and process control specifications • general control and automation applications • industrial applications • operation within the environmental conditions specified in the technical data •...

  • Page 9: Chapter 1 Assembly And Installation Guidelines

    Manual VIPA TM-E Chapter 1 Assembly and installation guidelines Chapter 1 Assembly and installation guidelines In this chapter you will find all information, required for assembly and Overview installation of the TM-E module. Content Topic Page Chapter 1 Assembly and installation guidelines......1-1 Safety information for Users..............

  • Page 10: Safety Information For Users

    Manual VIPA TM-E Chapter 1 Assembly and installation guidelines Safety information for Users VIPA modules make use of highly integrated components in MOS- Handling of Technology. These components are extremely sensitive to over-voltages electrostatic that can occur during electrostatic discharges.

  • Page 11: Installation Dimensions

    Manual VIPA TM-E Chapter 1 Assembly and installation guidelines Installation dimensions Make sure that a clearance of at least 100mm exists above and 70mm Dimensions below the middle of the bus rail. Dimensions 161 mm assembled 145 mm 124 mm...

  • Page 12: Assembly

    Manual VIPA TM-E Chapter 1 Assembly and installation guidelines Assembly The modules are installed on a profile rail. You may use the following General standard 35mm profile rail: 35 mm 35 mm 27 mm 27 mm Assembly procedure The following sequence represents the assembly procedure as viewed from the side.
  • Page 13 Manual VIPA TM-E Chapter 1 Assembly and installation guidelines The following sequence shows the steps required for the removal of Removal modules in a side view. procedure • The enclosure of the module has a spring-loaded clip at the bottom by which the module can be removed from the rail.

  • Page 14: Cabling

    Manual VIPA TM-E Chapter 1 Assembly and installation guidelines Cabling At the lower side of the TM-E module there are connectors for power Overview supply and digital inputs/outputs. The output is designed as low-side output and may be configured. The connectors are plugs with screw contacts. If connected the plugs may be fixed with screws.

  • Page 15: Installation Guidelines

    Manual VIPA TM-E Chapter 1 Assembly and installation guidelines Installation guidelines The installation guidelines contain information about the possible General interference causes. Here we describe possible ways of interference that may disturb the controlling system and how you have to approach shielding and screening issues to ensure the electromagnetic compatibility (EMC).
  • Page 16 Manual VIPA TM-E Chapter 1 Assembly and installation guidelines In the most times it is enough to take care of some elementary rules to Basic rules for guarantee the EMC. Please regard the following basic rules when installing your PLC.
  • Page 17 Manual VIPA TM-E Chapter 1 Assembly and installation guidelines Electrical, magnetically and electromagnetic interference fields are Isolation of weakened by means of an isolation, one talks of absorption. conductors Via the isolation rail, that is connected conductive with the rack, interference currents are shunt via cable isolation to the ground.
  • Page 18 Manual VIPA TM-E Chapter 1 Assembly and installation guidelines 1-10 HB39E - TME - RE_900-1E640 - Rev. 09/11...
  • Page 19 Manual VIPA TM-E Chapter 2 Hardware description Chapter 2 Hardware description Here the hardware components of the TM-E module are more described. Overview The technical data are at the end of this chapter. Content Topic Page Chapter 2 Hardware description ............. 2-1 Properties.....................

  • Page 20: Chapter 2 Hardware Description

    Due to the integrated Web page, for configuration there is no additional software necessary. Due to the predefined server the embedding to a VIPA PLC may be established problem-free. The TM-E module may be integrated as PG/OP interface to the Siemens SIMATIC manager by means of a station file.

  • Page 21: Structure

    Manual VIPA TM-E Chapter 2 Hardware description Structure TM-E Analog LEDs RJ45 Ethernet interface RJ11 PSTN modem (analog) Reset button RS485MPI interface DIP switch MPI interface Connector for DC 12...24V power supply Connector for digital I/O Components At the front-side of the TM-E module there are two rows of LEDs. The...
  • Page 22 Subnet mask: 255.255.255.0 To change the IP address parameters the configuration tool "eBuddy" from VIPA may be used. There is an PSTN modem (analog) integrated to the TM-E module. PSTN RJ11 interface means the analog Public Switched Telephone Network. The connection to PSTN modem your telephone line happens by the RJ11 interface.
  • Page 23 Manual VIPA TM-E Chapter 2 Hardware description MPI interface The TM-E module is connected to your PLC CPU via the MPI interface. The interface is designed as RS485 plug. There is a gender changer in the scope of delivery. This converts the RS485 plug 1:1 to a RS485 jack.
  • Page 24 Chapter 2 Hardware description Manual VIPA TM-E Reset A reset at the TM-E module may be initiated by the Reset button. The Reset button is allocated below the "Line" jack behind an opening. Please use for operation a pointed object.

  • Page 25: Technical Data

    Manual VIPA TM-E Chapter 2 Hardware description Technical Data TM-E Analog Elektrical Data VIPA 900-1E640 DC 12 ... 24V ±20% Power supply (rated value) Power consumption 3 ... 6W Nominal current max. 300mA Mark of conformity and certification Hardware Memory...
  • Page 26 Chapter 2 Hardware description Manual VIPA TM-E HB39E - TME - RE_900-1E640 - Rev. 09/11...

  • Page 27: Chapter 3 Deployment

    Chapter 3 Deployment Chapter 3 Deployment This chapter concerns on the deployment of the TM-E module from VIPA Overview with a PLC. With the fast introduction you will get an overview about the possibilities of teleservice. Another part of this chapter is the configuration of the TM-E module by means of the integrated Web page.

  • Page 28: Fast Introduction

    VIPA PLCs. More information concerning this may be found in German and English at: suppport.ewon.biz www.ewon-online.de The module TM-E from VIPA is constructed in the same way as the module "eWON2001". The TM-E module is to be supplied with DC 12...24V ±20%. The Power supply connection is established by a plug.
  • Page 29 Manual VIPA TM-E Chapter 3 Deployment The software tool "eBuddy" may be found at the download area of Access via www.vipa.de. For installation execute eBuddySetup.exe and follow the eBuddy instructions. • Start eBuddy. • Switch to the list view with "Switch to list mode". Here every TM-E module available in you network is listed.
  • Page 30 • Open the Web page of the corresponding TM-E module. • Open with Configuration > I/O server config. the page for adjusting an I/O server. Set as I/O server "S73&400". • To access the VIPA PLC enter the following parameters: 2 (standard) MPI destination node:...

  • Page 31: Assembly

    Manual VIPA TM-E Chapter 3 Deployment Assembly The modules are installed on a profile rail. You may use the following General standard 35mm profile rail: 35 mm 35 mm 27 mm 27 mm Assembly procedure The following sequence represents the assembly procedure as viewed from the side.

  • Page 32: Cabling

    Manual VIPA TM-E Chapter 3 Deployment Cabling At the lower side of the TM-E module there are connectors for power Overview supply and digital inputs/outputs. The output is designed as low-side output and may be configured. The connectors are plugs with screw contacts. If connected the plugs may be fixed with screws.

  • Page 33: Tm-E - Configuration - Ebuddy

    Manual VIPA TM-E Chapter 3 Deployment TM-E - Configuration - eBuddy To deploy the TM-E module, the VIPA software tool "eBuddy" is necessary. Overview With this new IP address parameters may be assigned to the TM-E module; you may load and transfer new firmware, backup/restore applications and access the integrated web page of the TM-E module.
  • Page 34 Manual VIPA TM-E Chapter 3 Deployment Industrial Ethernet exclusively supports IPv4. At IPv4 the IP address is a Basics - IP 32Bit address that must be unique within the network and consists of 4 address and numbers that are separated by a dot.
  • Page 35 Manual VIPA TM-E Chapter 3 Deployment For IPv4 addresses there are five address formats (class A to class E) that Address classes are all of a length of 4byte = 32bit. Class A 0 Network-ID Host-ID (24bit) (1+7bit) Class B...
  • Page 36 Manual VIPA TM-E Chapter 3 Deployment For the access to the TM-E-Modul valid IP address parameters are Changing the IP necessary. The IP addresses are assigned by the network administrator. address Per default the TM-E module is delivered with the IP address 10.0.0.53.
  • Page 37 In this case, please call the VIPA-Hotline! The proceeding of the update is shown as a proceeding bar. Wait here until the bar is at 100%.
  • Page 38 Open the dialog window with clicking to "Backup/restore application". Backup Select "Backup". Even if you want to forward the backup to the VIPA support the files relevant to the support should also be saved. Here activate the option "Include support files". Click to [Continue >].

  • Page 39: Tm-E - Reset

    Caution! An unauthorized complete reset, which possibly was not carefully executed, leads automatically to the expiring of the warranty! Then the device must be sent back to VIPA for reprogramming. There is the following proceeding for the user reset: User-Reset •...

  • Page 40: Tm-E - Web Page

    Manual VIPA TM-E Chapter 3 Deployment TM-E - Web page • Start the VIPA configuration tool "eBuddy". Access to the Web page • Switch to the list view with "Switch to list mode". Here every TM-E module available in your network is listed.
  • Page 41 Manual VIPA TM-E Chapter 3 Deployment The functionalities of your TM-E module are separated to the areas Main Structure menu and Configuration with the following structure. Each information of the TM-E module may be accessed by the Main menu. Main menu...

  • Page 42: Tm-E - Plc Linking

    Web page of the TM-E module may be accessed. To get access to the VIPA PLC, the VIPA CPU is to be connected to the Connect VIPA PLC MPI jack of the TM-E module via a suited MPI cable.
  • Page 43 Manual VIPA TM-E Chapter 3 Deployment • For the VIPA PLC select as I/O server "S73&400". The following dialog I/O server configuration window is opened: At "Gateway Configuration" and "MPI/Profibus Setup" the values are preset, which are to be used per default.
  • Page 44 Manual VIPA TM-E Chapter 3 Deployment To test the MPI connection a Tag is to be created. In a Tag memory areas Test PLC of you PLC are defined. connection These storage areas may R/W accessed by the Tag. • To establish a Tag open at the Web page the page "Tag setup" and click at "Create new Tag ...".

  • Page 45: Tm-E - Project Integration - Pg/Pc Interface

    With the teleservice the TM-E module works as gateway. As gateway via Teleservice the served communication connections you have access to the VIPA PLC, which is connected via MPI to the TM-E module. So that the TM-E module can work as gateway, you have to integrate this to your hardware configuration.
  • Page 46 Manual VIPA TM-E Chapter 3 Deployment The integration of the TM-E module to your project happens as PG/PC Integrate the TM-E interface. After the configuration this may be defined as access path for the module to the PLC functions. Siemens SIMATIC...
  • Page 47 Manual VIPA TM-E Chapter 3 Deployment • Open the properties of the PG/PC station. Properties PG/PC station • Access the register "Interfaces" and click to [New...]. • Select the type "Industrial Ethernet" and click to [OK]. • De-activate "Set MAC address..."...
  • Page 48 Manual VIPA TM-E Chapter 3 Deployment Now your graphical net view should show the following structure: Import the TM-E To import the TM-E module to your project the first downloaded station file module via station is necessary. file • Start in NetPro the import via Edit > Import.
  • Page 49 Manual VIPA TM-E Chapter 3 Deployment Define access via Depending on the access modes to your TM-E, there are the following IP address possibilities to preset IP address parameters: Access via Ethernet Enter here IP address and subnet mask of your TM-E module. The IP address parameters must correspond to the IP address parameters, which were preset with the software tool "eBuddy".

  • Page 50: Deployment Of Tags

    Let the value at "Standard" Page: Give a comment to the Tag Tag description: I/O server setup For VIPA PLCs select "S73&400" Server name: Devices within an I/O server are grouped by Topic name: Topic name. Enter A, if you have defined your MPI interface as Topic A, as described at "TM-E - PLC linking".
  • Page 51 Manual VIPA TM-E Chapter 3 Deployment The following symbolic names may be used on deployment together with a Name conventions VIPA PLC by selecting "S73&400" server: for Address Symbol Symbol Memory type Modificator Address Data block with No. x B, C, W, S, D, L,...
  • Page 52 Manual VIPA TM-E Chapter 3 Deployment For the further approach it is precondition that you have access to the Web Example page of the TM-E module, your PLC may be reached via the TM-E module and the corresponding Topics are configured.

  • Page 53: Teleservice Via Telephone With Mpi Gateway

    Manual VIPA TM-E Chapter 3 Deployment Teleservice via telephone with MPI gateway With the teleservice via telephone with MPI gateway, a connection via Overview telephone (PPP connection) is directly established from your PC to the TM-E module. Here the CPU is linked to the TM-E module by MPI.
  • Page 54 Manual VIPA TM-E Chapter 3 Deployment • Here enter the following parameters: - "TM-E PPP server IP address": 202.0.0.240 - "PPP client IP address": 202.0.0.1 • Accept the remaining default settings and click at [Update]. Configure your PC modem so that it may establish a connection to the TM- E module.
  • Page 55 "eBuddy". Please regard that your CPU is connected via MPI and the MPI address is accordingly assigned. VIPA CPUs are delivered with MPI address 2. NetPro should now show the following structure. Click in the graphical net view at the CPU and transfer your project with Transfer the Download >...

  • Page 56: Teleservice Via Telephone - Ethernet Gateway

    Manual VIPA TM-E Chapter 3 Deployment Teleservice via telephone - Ethernet gateway With teleservice via telephone with Ethernet gateway, a connection via Overview telephone (PPP connection) is directly established from your PC to the TM-E module. Here the CPU is linked to the TM-E module by Ethernet.
  • Page 57 Manual VIPA TM-E Chapter 3 Deployment To access the TM-E module via PPP connection the server for incoming Configuration of PPP connections is to be configured. the direct • Here open the Web page of the TM-E module. telephone connection •...
  • Page 58 Manual VIPA TM-E Chapter 3 Deployment Configure So that your TM-E module may transfer every IP packages received from forwarding the PPP connection to the PLC, you have to configure Forwarding. • Navigate to the page "Communication" via Configuration > System Setup.

  • Page 59: Teleservice Via Callback Function

    Manual VIPA TM-E Chapter 3 Deployment Teleservice via Callback function With Callback there is the possibility to call the TM-E module with a defined Overview number of ring signals to initiate the callback mode. Now the module accesses the Internet and sends an eMail, which contains in its text a dynamic PPP IP address.
  • Page 60 Manual VIPA TM-E Chapter 3 Deployment Configuration To access the TM-E module via PPP connection the server for incoming PPP connections is to be configured. • Here open the Web page of the TM-E module. • Navigate to the "Communication" page via Configuration > System setup.
  • Page 61 Manual VIPA TM-E Chapter 3 Deployment Activate the dial-up server for the dial-up to the Internet. Configuration of • Here open the Web page of the TM-E module. the dial-up server • Navigate > page Configuration System setup "Communication". Open at the navigation tree Network connection >...
  • Page 62 Manual VIPA TM-E Chapter 3 Deployment • To enter the SMTP server open the page "General" at "System setup". Configuration of the mail server • Navigate at the navigation tree to Net Services > SMTP (mails). • Here enter the following parameters:...

  • Page 63: Sending Sms Via Mail Gateway

    Manual VIPA TM-E Chapter 3 Deployment Sending SMS via mail gateway There is the possibility to send SMS via mail gateway with the TM-E Precondition module. For the further approach it is precondition that you have access to the Web page of the TM-E module and your CPU is connected to the TM-E module via MPI and is accordingly configured.
  • Page 64 Manual VIPA TM-E Chapter 3 Deployment For the dial-up to the Internet the dial-up server is to be activated. Configuration of • Here open the Web page of the TM-E module. the dial-up server • Navigate to the "Communication" page via Configuration > System Setup.
  • Page 65 Manual VIPA TM-E Chapter 3 Deployment • For the eMail configuration navigate via Configuration > System setup Configuration of to the page "General". Open the page "SMTP (Mails)" in the navigation the eMail tree Net services. functionality • Enter the following parameters: Server address of your eMail provider (outbox).
  • Page 66 Manual VIPA TM-E Chapter 3 Deployment The dialog window "Alarm notification ..." is opened • Enter the following parameters: enable the option ALM eMail upon: enable the option "Format as short message". Short message: This limits the mail text to 160 characters (SMS default).

  • Page 67: Index
