Fig. 3 - PD4/PD4CB
F1
Used on
PTC Models
1P, 2P, 3P, 4P = FUSED OUTPUTS
1N, 2N, 3N, 4N = COMMON OUTPUTS
1P
COMMON POWER OUTPUTS
Fig. 4 - PD8/PD8CB
Used on
1
PTC Models
P
FUSED POWER OUTPUTS
N
COMMON POWER OUTPUTS
Fig. 5 - PD16W/PD16WCB
1 2 3 4 5 6 7 8
Used on
PTC Models
- 6 -

Power Distribution Module(s):

F2
F3
1N
2P
2N
3P
3N
DC Output to devices
2
3
4
5
6
DC Output to devices
common
outputs
protected
outputs
For continuous protection against risk of fire
3.5A 250V
F4
LED
4P
4N
INPUT
From Power Supply
Board
(Factory Installed)
7
8
D1
LED
R1
INPUT
From Power Supply
Board
(Factory Installed)
9 10 11 12 13 14 15 16
replace fuses with same type and rating.
SW1
N
P
SMP10C24X Series Installation Guide
