Charlton & Jenrick Infinity 780 BF Owner's Manual

Hide thumbs Also See for Infinity 780 BF:
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual
INCLUDES
User, Maintenance, Service, and Installation
Instructions
780 BF
Keep this booklet for service log and future reference
IMPORTANT
This appliance is guaranteed for 12 months subject to conditions. The 5 year extended parts
warranty will only be valid if the annual service recommended in this manual has been
completed and appliance has been registered online.
For use in Great Britain and Ireland.
Literature NO 6863 (ISS 02)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Infinity 780 BF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Charlton & Jenrick Infinity 780 BF

Summary of Contents for Charlton & Jenrick Infinity 780 BF

  • Page 1 Owner’s Manual INCLUDES User, Maintenance, Service, and Installation Instructions 780 BF Keep this booklet for service log and future reference IMPORTANT This appliance is guaranteed for 12 months subject to conditions. The 5 year extended parts warranty will only be valid if the annual service recommended in this manual has been completed and appliance has been registered online.

  • Page 2: Table Of Contents

    Contents EXTENDED FIVE YEAR PARTS WARRANTY ....2 Benchmark Scheme ............. 3 SECTION ONE Important Information (users EXTENDED FIVE YEAR PARTS instructions) ..............5 WARRANTY SECTION TWO Introduction (users instructions) ..7 SECTION THREE Operation (users instructions) ..7 In order to validate your extended 5 years parts SECTION FOUR Cleaning &...

  • Page 3: Benchmark Scheme

    Benchmark Scheme Charlton and Jenrick Ltd is a licensed member of the Benchmark Scheme which aims to improve the standards of installation and commissioning of domestic heating and hot water systems in the UK and to encourage regular servicing to optimise safety, efficiency and performance. Benchmark is managed and promoted by the Heating and Hotwater Industry Council.
  • Page 4 For future reference we suggest you record the following details here, and keep the receipt as proof of purchase. This information may be asked for when you contact the helpdesk. MODEL: INFINITY 780 BF Serial No. This information can be found on the label attached to the packaging and on the data badge, which is located on the base of the appliance behind the control cover.

  • Page 5: Section One Important Information (Users Instructions)

     As the INFINITY 780 BF is a room sealed appliance (i.e. air for the combustion process is taken from outside the room) no purpose built ventilation is required.
  • Page 6  Although the INFINITY 780 BF is fitted with a glass front which acts as a dress guard it is strongly recommended that a fireguard should be used for the protection of children, the elderly or infirm.

  • Page 7: Section Two Introduction (Users Instructions)

    SECTION TWO Introduction (users instructions)  The INFINITY 780 BF is an inset room sealed decorative fuel-effect gas appliance designed for use in locations that do not have a conventional chimney. The appliance must be installed against an outside wall because the air to support combustion is taken from the outside and the products of combustion are expelled to the outside.
  • Page 8 Room Thermostat mode The remote handset checks the room temperature at a fixed time intervals. Depending on the difference between set room temperature and the actual room temperature the remote proceeds to modulate in one level steps. Once the room temperature is reached it moves to standby position pilot only. The icon “PILOT”...
  • Page 9 To Deactivate the sleep mode: When the fire is next operated, the sleep mode will automatically appear unless it is re-set to zero. This can be done by pressing the key and using the button to decrease the time set by 15 minute intervals until back to zero. If you experience unexplained outing on the fire please check that the sleep mode is switched off.

  • Page 10: Section Four Cleaning & Laying The Fuel Bed (Users Instructions)

    SECTION FOUR Cleaning & Laying the fuel bed (users instructions) Warning:-Before you clean any part of the appliance ensure that the appliance is switched off and cool. CLEANING: BLACK PAINTED SURFACES  These surfaces should be dusted regularly and any marks removed with a soft cloth. ...
  • Page 11 CLEANING AND REPLACING fuel bed shapes Important: - Refer to the ‘Health & Safety Notice located on page 3 of this booklet before cleaning or replacing any refractory material. Use only the shapes provided NO OTHER SHAPES SHOULD BE ADDED to the appliance The Fuel bed set consists of: ...
  • Page 12 Lay the bark chippings and small log shape as shown.  Place two log shapes upon the shelf above the inlet baffle as shown. LT6863 (ISS 02)
  • Page 13  Place a further two log shapes along the front edge of the burner cover.  Place a further two log shapes as shown.  Place a further two log shapes as shown.  Place a further two log shapes as shown. ...

  • Page 14: Section Five Appliance Data (Installation Instructions)

    SECTION FIVE Appliance Data (installation instructions) Fire Box dimensions: Height 740mm Width 843mm Forward Projection: 42mm Weight: 35kg Flue Length………………………………………...100mm (minimum) to 600mm (maximum) No bends or joined flue pipes should be used in the flue system. Pressure Test Point Location: Gas inlet elbow Gas Connection: 8.0mm O/D, tube.

  • Page 15: Section Six Regulations And Warnings (Installation Instruction)

    SECTION SIX Regulations and Warnings (installation instruction)  This appliance must only be installed in Great Britain or Ireland.  The appliance is available in natural gas only.  This appliance must be installed on a suitable outside wall.  No special ventilation bricks or vents are required into the room containing the appliance.

  • Page 16: Section Seven Siting The Appliance (Installation Instructions)

    SECTION SEVEN Siting the Appliance (installation instructions) (When installing in a timber framed dwelling reference must be made to the specific installation requirements stated in Section 8 Installing the Appliance in Timber Framed Dwelling). GENERAL REQUIREMENTS  The flue and air duct length must be between 100mm to 600mm. ...

  • Page 17: Section Eight Preparing The Appliance For Installation (Installation Instructions)

    Ensure that gas supply is suitably sited ALL DIMENSIONS IN mm  Check with the supplier or manufacturer that the surround meets 150 C minimum rating 853 MIN (attention should especially be given to manmade materials such as resin). 870 MAX. 750 MIN ...
  • Page 18 Measurement taken from floor Level to the flue pilot height and lintel minimum clearance Using 150mm core drill cut a holes following the pilot holes. Drill from the outside through to the cavity to give a good finish on the outside. ...
  • Page 19 TIMBER FRAMED DWELLING This method allows for installation in timber frame buildings. Where removal of any part of the inner timber leaf of the wall is involved the structural integrity of the wall must be maintained and the advice of your local Building Control Department should be sought.
  • Page 20 TIMBER FRAMED DWELLING  With the opening prepared slide the timber frame within the opening. Secure the frame assembly back using suitable screws and wall plug.  Loosen the 8 fixing screws retaining the adjustment bracket and slide against the rear fascia brick surface.

  • Page 21: Section Nine Connecting The Gas Supply

    SECTION NINE CONNECTING THE GAS SUPPLY TURN OFF ANY GAS APPLIANCES THAT ARE FED BY THE METER AND ISOLATE THE GAS SUPPLY BY TURNING OFF AT THE METER.  The Gas Connection can be made by removing the gas inlet cover located on the left hand side of the fire box sump assembly.

  • Page 22: Section Ten Assemble The Appliance (Installation Instructions)

    SECTION TEN Assemble the appliance (installation instructions)  Taking special care remove the ceramic liner set from within the packaging. The rear liner is in two pieces. Place the bottom rear liner upon the top edge to the air tray. Angle the upper rear line into the fire box assembly and place on top of the rear bottom line.

  • Page 23: Section Eleven Instruct And Advise The Customer (Installation Instructions)

    SECTION ELEVEN Instruct and Advise the Customer (installation instructions)  Demonstrate the lighting and extinguishing procedure to the consumer/user and the removal and refitting of the trim for cleaning.  Explain that for the first few hours of the fire operating there will be an initial odour.
  • Page 24 3. Turn on the gas supply, check for soundness and re- commission. Replacement of Gas Control 1. Remove the infill strips LH and RH and the inlet cover. 2. Remove the 3 off glass retaining brackets positioned on both sides and top of the glass panel. 3.

  • Page 25: Section Twelve Wiring Diagram (Maintenance Instructions)

    Attach to the valve When ordering parts quote 'INFINITY 780 BF' and the serial number of the fire, which can be found on the data badge on bottom left hand side of fire. (Refer to cleaning instructions for trim removal.) www.charltonandjenrick.co.uk...
  • Page 26 LT6863 (ISS 02)
  • Page 27 www.charltonandjenrick.co.uk LT6863 (ISS 02)
  • Page 28 LT6863 (ISS 02)
  • Page 29 Register your appliance online today to activate your warranty www.charltonandjenrick.co.uk LT6863 (ISS 02)

  • Page 30: Balanced Flue Gas Fire Commissioning Checklist

    BALANCED FLUE GAS FIRE COMMISSIONING CHECKLIST This Commissioning Checklist is to be completed in full by the competent person who commissioned the gas fire as a means of demonstrating compliance with the appropriate Building Regulations and then handed to the customer to keep for future reference. Failure to install and commission according to the manufacturer’s instructions and complete this Benchmark Commissioning Checklist will invalidate the warranty.

  • Page 31: Service Record

    SERVICE RECORD It is essential that your gas fire is serviced regularly and that the appropriate Service Interval Record is completed. Service Provider Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions.
  • Page 32 Product ID Label Serial No Prefix (NG) A-0552 Data Badge Burner Tray / Box Assembly Air Test Completed Warning Label (1409) Grommet (1406) Glass Sub-Assembly Silicone Sealing Strip (4818) x 2 780 BF Log Set (6792) Fireplace Frame (5772) Battery Holder (5775) Inlet Cover (5764) Top Fixing Cover (6780) “AAA”...
