INSTALLATION AND OPERATION INSTRUCTIONS FOR
WALL-MOUNT AND BUILT-IN UNITS
WM-FM-50-BG
SAFETY INFORMATION
WARNING
If the information in these
instructions are not followed exactly,
a fire or explosion may result causing
property damage, personal injury or
loss of life.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
Advertisement
Table of Contents
Related Manuals for Amantii WM-FM-50-BG
Summary of Contents for Amantii WM-FM-50-BG
- Page 1 INSTALLATION AND OPERATION INSTRUCTIONS FOR WALL-MOUNT AND BUILT-IN UNITS WM-FM-50-BG SAFETY INFORMATION WARNING If the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
-
Page 2: Table Of Contents
Please read and carefully follow all of the instruction found in this manual. Please pay special attention to the safety instructions provided in this manual. The instructions included here will as sure that you have many years of dependable and enjoyable service from your Amantii product. -
Page 3: Important Instructions
IMPORTANT INSTRUCTIONS Read all instructions before installing or using this heater. 2. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes and curtains at least 3 feet from the front of the heater; keep them away from sides and rear as well. -
Page 4: Unpacking And Testing Appliance
UNPACKING AND TESTING APPLIANCE Carefully remove the appliance from the box. Prior to installing the appliance, test to make sure the appliance operates properly by plugging the power supply cord into a conveniently located 120 Volt grounded outlet. GROUNDING APPLIANCE This appliance is for use on 120 Volts. -
Page 5: Wm-Fm-50-Bg
WM-FM-50-BG This appliance has been tested in Description Built-in or Wall Mount Appliance accordance with the UL Standard 2021 Voltage 120V AC 60Hz for fixed and location dedicated electric Watts 1500W Max room appliances in the United States NO HEATER and Canada. -
Page 6: Removing Front Glass
REMOVING FRONT GLASS The fireplace have 2 screws that secure the front glass in place. Two people are required for the installation process. 1. The screws are located on the sides of the unit. Once located, unscrew the two or four screws. You can then lift the front glass from the 4 shoulder posts on the sides of the unit and remove the glass. -
Page 7: Installation-Wall Mount
INSTALLATION-WALL MOUNT For wall mount install,please remove the wall mount plate from the back of the appliance. 1. Select a location that is not prone to moisture and is located at least 0.91 m or 3 feet away from combustible materials such as curtains or drapes, furniture, bedding ,paper, etc. -
Page 8: Installation- Built-In
4. Level the fireplace. cord into a conveniently located 120 Volt 5. Drive mounting screws into grounded outlet. mounting brackets on the unit and the The rough wall opening size of the fireplace. wall studs. W(“) D(“) H(“) 48 1/2 WM-FM-50-BG... -
Page 9: Hard- Wire Installation
HARD- WIRE INSTALLATION Turn off the appliance completely and let cool before servicing. Only a qualified service person should service and repair this electric appliance. If it is necessary to hard wire this appliance, a qualified electrician must remove the cord connection, and wire the appliance directly to the house hold wiring. -
Page 10: Media Options
MEDIA OPTIONS The fireplace shipped with an ember log set panels to remove the log set. that is pre-installed. Consumers have their Screw back the side panels after remove the choice of decorative media should they wish log set. to install it. Consumers choose from “EMBER”... -
Page 11: Operation
OPERATION The fireplace can be operated either by the switches located on the left bottom of the fireplace unit or by supplied remote control. Plug the fireplace into a 15 Amp wall socket. MANUAL OPERATION 1. The main power ON/OFF switch in position O, the fireplace is OFF. 2. -
Page 12: Remote Control Operation
REMOTE CONTROL OPERATION For remote to function make sure the heater is plugged in and mains power switch located on the bottom left hand side is at position I. When operating the remote make sure you point the remote to the centre of the fireplace and make sure each time you press the button. -
Page 13: Installing Wall Thermostat
INSTALLING WALL THERMOSTAT WALL THERMOSTAT WIRING DIAGRAMS NOTE: THE WALL THERMOSTAT WILL WOKING WHEN THE HEATER ON TEMP. SETTING.PLEASE REEFER TO THE MANUAL CONTROL AND THE REMOTE CONTROL. Wire the wall thermostat prior to installing the fireplace. WALL THERMOSTAT WIRING(24 VAC) Install Wall Thermostat per instructions provided with kit and per the following information: 1. -
Page 14: Replacement Parts
REPLACEMENT PARTS PART NUMBER DESCRIPTION QTY. FIREPLACE BOX 301506 REMOTE RECEIVER 601097B CIRCUIT BOARD 10104010 SWITCH 601032B CONTROL PANEL TOP PANEL 602067B BLOWER AND HEATER ASSEMBLY 3095006C BLACK PLASTIC 3093003 BLOWER MOUNT GLASS BRACKET LED BRACKET 10702145 BOTTOM GLASS 10101225 FLAME MOTOR 3095502 FLICKER ASSEMBLY... -
Page 15: Exploded View
EXPLODED VIEW... -
Page 16: Truble Shooting
TRUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Dim or no flame Flame LED’s are burnt out Inspect the LED’s and replace them if necessary. Ember Ember LED’s are burnt out Inspect the ember bed LED’s and glowing or dimming replace them if necessary. Appliance turns Appliance... -
Page 17: Service History
SERVICE HISTORY This heater must be serviced annually depending on usage. Date Dealer Service technician Service Performed Special Concerns Name Name NOTES:... -
Page 18: Wrrranty
Products covered by this limited warranty have been tested and inspected prior to shipment and, subject to the provisions of this warranty, Amantii warrants such products to be free from defects in material and workmanship for a period of two (2) years from the date of the first purchase of such products.
