INSTALLATION /OWNER'S MANUAL
WM-FM-26-3623-BG
(WM-G190026-1)
WM-FM-34-4423-BG
(WM-G190034-1)
SAFETY INFORMATION
For your safety, always comply with all
warnings and safety instructions
contained in this manual to prevent
personal injury or property damage.
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this appliance.
INSTALLER: LEAVE OWNER'S MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN OWNER'S MANUAL FOR FUTURE REFERENCE.
WALL-MOUNT & BUILT-IN UNIT
WM-FM-48-5823-BG
(WM-G190048-1)
WM-FM-60-7023-BG
(WM-G190060-1)
WARNING
WM-FM-72-8123-BG
(WM-G190072-1)
WM-FM-88-10023-BG
(WM-G190088-1)
Version:202201

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WM-FM-26-3623-BG and is the answer not in the manual?

Questions and answers

Related Manuals for Amantii WM-FM-26-3623-BG

Summary of Contents for Amantii WM-FM-26-3623-BG

  • Page 1 INSTALLATION /OWNER’S MANUAL WALL-MOUNT & BUILT-IN UNIT WM-FM-72-8123-BG WM-FM-26-3623-BG WM-FM-48-5823-BG (WM-G190072-1) (WM-G190026-1) (WM-G190048-1) WM-FM-88-10023-BG WM-FM-34-4423-BG WM-FM-60-7023-BG (WM-G190088-1) (WM-G190034-1) (WM-G190060-1) SAFETY INFORMATION WARNING For your safety, always comply with all warnings and safety instructions contained in this manual to prevent personal injury or property damage.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Please read and carefully follow all of the instruction found in this manual. The instructions included here will assure that you have many years of dependable and enjoyable service from your Amantii product. IMPORTANT INSTRUCTIONS ............................FCC CAUTIONS ..................................

  • Page 3: Important Instructions

    IMPORTANT INSTRUCTIONS PLEASE RETAIN THIS USER GUIDE FOR FUTURE REFERENCE When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: 1) Read all instructions before using this fireplace 2) The fireplace is hot when in use.

  • Page 4: Fcc Cautions

    FCC CAUTIONS This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 5: Unpacking And Testing The Appliance

    UNPACKING AND TESTING APPLIANCE Carefully remove the appliance from the box. Prior to installing the appliance, test to make sure the appliance operates properly by plugging the power supply cord into a conveniently located 120 Volt grounded outlet. There are two screws on each side to fix the front glass. Screw Please see the figure right side.

  • Page 6: Wm-Fm-26-3623-Bg (Wm-G190026-1)

    WM-FM-26-3623-BG (WM-G190026-1) This appliance has been tested in Description Built-in or Wall Mount Appliance accordance with the UL Standard 2021 Voltage 120V AC 60Hz for fixed and location dedicated Watts 1500W Max electric room appliances in the United NO HEATER States and Canada.

  • Page 7: Wm-Fm-34-4423-Bg (Wm-G190034-1)

    WM-FM-34-4423-BG (WM-G190034-1) This appliance has been tested in Description Built-in or Wall Mount Appliance accordance with the UL Standard 2021 Voltage 120V AC 60Hz for fixed and location dedicated electric Watts 1500W Max room appliances in the United States and NO HEATER Canada.

  • Page 8: Wm-Fm-48-5823-Bg (Wm-G190048-1)

    WM-FM-48-5823-BG (WM-G190048-1) This appliance been tested Description Built-in or Wall Mount Appliance accordance with the UL Standard 2021 for Voltage 120V AC 60Hz fixed and location dedicated electric room Watts 1500W Max appliances in the United States and Canada. NO HEATER If you need assistance during installation, MOTOR HEATER please contact your local dealer.

  • Page 9: Wm-Fm-60-7023-Bg (Wm-G190060-1)

    WM-FM-60-7023-BG (WM-G190060-1) This appliance been tested Description Built-in or Wall Mount Appliance accordance with the UL Standard 2021 for Voltage 120V AC 60Hz fixed and location dedicated electric room Watts 1500W Max appliances in the United States and Canada. NO HEATER If you need assistance during installation, MOTOR HEATER please contact your local dealer.

  • Page 10: Wm-Fm-72-8123-Bg (Wm-G190072-1)

    WM-FM-72-8123-BG (WM-G190072-1) This appliance has been tested in Description Built-in or Wall Mount Appliance accordance with the UL Standard 2021 for Voltage 120V AC 60Hz fixed and location dedicated electric room Watts 1500W Max appliances in the United States and NO HEATER Canada.

  • Page 11: Wm-Fm-88-10023-Bg (Wm-G190088-1)

    WM-FM-88-10023-BG (WM-G190088-1) Description This appliance been tested Built-in or Wall Mount Appliance accordance with the UL Standard 2021 for Voltage 120V AC 60Hz fixed and location dedicated electric room Watts 1500W Max appliances in the United States and Canada. NO HEATER If you need assistance during installation, MOTOR HEATER please contact your local dealer.

  • Page 12: Removing Front Glass

    REMOVING FRONT GLASS Models WM-FM-26-3623-BG , WM-FM-36-4423-BG , WM-FM-48-5823-BG and WM-FM-60 -7023-BG each have 2 screws that secure the front glass in place. Models WM-FM-72- 8123-BG and WM-FM-88-10023-BG have four screws secure the front glass in place. Two people are required for the installation process.

  • Page 13: Installation Wall-Mount

    INSTALLATION WALL MOUNT NOTE: Due to the many different materials used on different walls, it is highly recommended that you consult your local builder before you install this appliance. 1. Select a location that is not prone to moisture and is located at least 0.91 m or 3 feet away from combustible materials such as curtains or drapes, furniture, bedding, paper, etc.

  • Page 14: Installation Built-In

    120 Volt grounded outlet. The rough wall opening size of the fireplace: W(“) D(“) H(“) 6 1/2 20 1/2 WM-FM-26-3623-BG 6 1/2 20 1/2 WM-FM-34-4423-BG 6 1/2 20 1/2 WM-FM-48-5823-BG 60 5/8 6 1/2...

  • Page 15: Mantel Clearance

    MANTEL CLEARANCE The clearance to the mantel should be 1” minimum when a mantel is applied (Measurement is taken from glass front). Wall (Combustible facing allowed) Mantel Fireplace Fireplace Floor HARDWARE INSTALLATION Turn off the appliance completely and let cool before servicing. Only a qualified service person should service and repair this electric appliance.

  • Page 16: Media Options

    MEDIA OPTIONS The fireplace shipped with Birch log set, amber glass and Vermiculite. Consumers may purchase optional decorative media if they choose. See dealer for more details. Birch log set Amber glass Vemiculite DECORATIVE MEDIA INSTALLATION 1. Unplug the unit from the power. 2.

  • Page 17: Operation

    OPERATION The Fireplace operates by using either the touch panel located on the upper left hand corner or by remote control. Plug the fireplace into a 15 Amp wall socket. Plug the fireplace into a 15 Amp wall socket. MANUAL OPERATION Press to turn on and off the fireplace.

  • Page 18: Remote Control Operation

    REMOTE CONTROL OPERATION For remote to function make sure the fireplace is plugged in and the remote has batteries. Important: When operating the remote make sure you point the remote to the center of the fireplace. Each time you press the button, the buzzer inside the unit will beep once. It takes some time for the receiver to respond to the transmitter.
  • Page 19 AUTO means fireplace can automatically adjust to the temperature you set. When in AUTO, you can set the desired temperature with keys. You can switch temperature between Celsius and Fahrenheit with keys.When it is on Auto mode,fireplace operate at 1500W. Press this button to adjust the speed of the flame.
  • Page 20 When the 7 day timer’s set, the icon will be displayed on the LCD screen of the remote control. Press again to cancel the 7 da y timer and the icon will disappears. NOTE: If the 7 day timing and the general timing are set at the same time, the system will respond to an earlier shutdown time.

  • Page 21: Wifi Operation

    WIFI OPERATION INSTALL TuyaSmart life There are 2 ways to install TuyaSmart; 1. Search for “TuyaSmart life” in the APP store on your phone, download and install. 2. Scan the QR code below with your mobile phone. WIFI SETTING AND FIREPLACE OPERATION 1.
  • Page 22 FIG.4 3. Press (flame button) on the touch panel of the fireplace for more than 5 seconds when the fireplace in standby mode. There will be 2 beeps come out from the fireplace and the (flame button) will flash as well indicating that Wi-fi is in EZ mode. Then please confirm to go next.
  • Page 23 6. Now you are in the interface like FIG.7. You can operate the fireplace via Wi-fi. FIG.7 NOTE: Turn off the flashing blue Wifi indicator light Touch the (power button) once, the blue light will stop flashing.

  • Page 26: Exploded View

    EXPLODED VIEW...

  • Page 27: Trouble Shooting

    TRUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Dim or no flame Flame LED’s are burnt out Inspect the LED’s and replace them if necessary. Ember Ember LED’s are burnt out Inspect the ember bed LED’s and glowing or dimming replace them if necessary. Appliance turns off and Appliance has overheated and Turn off the main switch, allow...

  • Page 28: Service History

    SERVICE HISTORY This heater must be serviced annually depending on usage. Date Dealer Service technician Service Performed Special Concerns Name Name NOTES:...

  • Page 29: Warranty

    Products covered by this limited warranty have been tested and inspected prior to shipment and, subject to the provisions of this warranty, Amantii warrants such products to be free from defects in material and workmanship for a period of five (5) years from the date of the first purchase of such products.
  • Page 30 The provisions of the United Nations Convention on Contracts for the Sale of Goods shall not apply to this limited warranty or the sale of products covered by this limited warranty. GENERAL Amantii reserves the right to make changes at any time without notice, in design, material, specifi cations, prices and the right to discontinue styles and products. GLASS...
