INSTALLATION AND OPERATION INSTRUCTIONS FOR WALL-M OUNT
AND BUIL T-IN UNITS
W M -FM -26-3623-BG
W M -FM -34-4423-BG
W M -FM -48-5823-BG
W M -FM -60-7023-BG
W M -FM -72-8123-BG
W M -FM -88-10023-BG
SAFETY INFORM ATION
WARNING
If the information in these instructions are
not followed exactly, a fire or explosion
may result causing property damage,
personal injury or loss of life.
Do not store or use gasoline or ot her flammable vapors
and liquids in t he vicinit y of t his or any ot her appliance.
INSTALLER: LEAVE THIS M ANUAL W ITH THE APPLIANCE.
CONSUM ER: RETAIN THIS M ANUAL FOR FUTURE REFERENCE.
