INSTALLATION AND OPERATION INSTRUCTIONS FOR WALL-MOUNT
AND BUILT-IN UNITS
WM-FM-26-3623-BG
WM-FM-34-4423-BG
WM-FM-48-5823-BG
WM-FM-60-7023-BG
WM-FM-72-8123-BG
WM-FM-88-10023-BG
SAFETY INFORMATION
WARNING
If the information in these instructions are
not followed exactly, a fire or explosion
may result causing property damage,
personal injury or loss of life.
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Amantii WM-FM-26-3623-BG
Summary of Contents for Amantii WM-FM-26-3623-BG
- Page 1 INSTALLATION AND OPERATION INSTRUCTIONS FOR WALL-MOUNT AND BUILT-IN UNITS WM-FM-26-3623-BG WM-FM-34-4423-BG WM-FM-48-5823-BG WM-FM-60-7023-BG WM-FM-72-8123-BG WM-FM-88-10023-BG SAFETY INFORMATION WARNING If the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
Page 2: Table Of Contents
Please read and carefully follow all of the instruction found in this manual. Please pay special attention to the safety instructions provided in this manual. The instructions included here will assure that you have many years of dependable and enjoyable service from your Amantii product. IMPORTANT INSTRUCTIONS............................3 UNPACKING AND TESTING APPLIANCE .......................4... -
Page 3: Important Instructions
IMPORTANT INSTRUCTIONS Read all instructions before installing or using this heater. 2. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes and curtains at least 3 feet from the front of the heater; keep them away from sides and rear as well. 3. -
Page 4: Unpacking And Testing Appliance
UNPACKING AND TESTING APPLIANCE Carefully remove the appliance from the box. Prior to installing the appliance, test to make sure the appliance operates properly by plugging the power supply cord into a conveniently located 120 Volt grounded outlet. There are two screws on each side to fix the front glass. Please see the figure right side. -
Page 5: Wm-Fm-26-3623-Bg
WM-FM-26-3623-BG Description Built-in or Wall Mount Appliance This appliance has been tested in Voltage 120V AC 60Hz accordance with the UL Standard 2021 Watts 1500W Max for fixed and location dedicated NO HEATER electric room appliances in the United MOTOR HEATER States and Canada. -
Page 6: Wm-Fm-34-4423-Bg
WM-FM-34-4423-BG This appliance has been tested in Description Built-in or Wall Mount Appliance accordance with the UL Standard 2021 Voltage 120V AC 60Hz for fixed and location dedicated electric Watts 1500W Max room appliances in the United States and NO HEATER Canada. -
Page 7: Wm-Fm-48-5823-Bg
WM-FM-48-5823-BG This appliance been tested Description Built-in or Wall Mount Appliance accordance with the UL Standard 2021 for Voltage 120V AC 60Hz fixed and location dedicated electric room Watts 1500W Max appliances in the United States and Canada. NO HEATER If you need assistance during installation, MOTOR HEATER please contact your local dealer. -
Page 8: Wm-Fm-60-7023-Bg
WM-FM-60-7023-BG This appliance been tested Description Built-in or Wall Mount Appliance accordance with the UL Standard 2021 for Voltage 120V AC 60Hz fixed and location dedicated electric room Watts 1500W Max appliances in the United States and Canada. NO HEATER If you need assistance during installation, MOTOR HEATER please contact your local dealer. -
Page 9: Wm-Fm-72-8123-Bg
WM-FM-72-8123-BG This appliance has been tested in Description Built-in or Wall Mount Appliance accordance with the UL Standard 2021 for Voltage 120V AC 60Hz fixed and location dedicated electric room Watts 1500W Max appliances in the United States and NO HEATER Canada. -
Page 10: Wm-Fm-88-10023-Bg
WM-FM-88-10023-BG This appliance been tested Description Built-in or Wall Mount Appliance accordance with the UL Standard 2021 for Voltage 120V AC 60Hz fixed and location dedicated electric room Watts 1500W Max appliances in the United States and Canada. NO HEATER If you need assistance during installation, MOTOR HEATER please contact your local dealer. -
Page 11: Removing Front Glass
REMOVING FRONT GLASS Models WM-FM-26-3623-BG , WM-FM-36-4423-BG , WM-FM-48-5823-BG and WM-FM-60 -7023-BG each have 2 screws that secure the front glass in place. Models WM-FM-72- 8123-BG and WM-FM-88-10023-BG have four screws secure the front glass in place. Two people are required for the installation process. -
Page 12: Installation-Wall Mount
INSTALLATION-WALL MOUNT 1. Select a location that is not prone to moisture and is located at least 0.91 m or 3 feet away from combustible materials such as curtains or drapes, furniture, bedding, paper, etc. 2. Referring to Fig. 1 below select a suitable position in which to mount the heater horizontally –... -
Page 13: Installation- Built-In
120 Volt grounded outlet. The rough wall opening size of the fireplace: W(“) D(“) H(“) 6 1/2 20 1/2 WM-FM-26-3623-BG 6 1/2 20 1/2 WM-FM-34-4423-BG 6 1/2 20 1/2 WM-FM-48-5823-BG 60 5/8 6 1/2... -
Page 14: Hard- Wire Installation
HARD- WIRE INSTALLATION Turn off the appliance completely and let cool before servicing. Only a qualified service person should service and repair this electric appliance. If it is necessary to hard wire this appliance, a qualified electrician must remove the cord connection, and wire the appliance directly to the household wiring. -
Page 15: Media Options
MEDIA OPTIONS The fireplace shipped with an ember log set that is pre-installed. Consumers have their choice of decorative media should they wish to install it. Consumers choose from “EMBER” or “ICE:” decorative media. Log set Installing the decorative media HZ-12-EMBER Pour the fire glass media into the tray. -
Page 16: Operation
OPERATION The fireplace can be operated either by the switches located on the left bottom of the fireplace unit or by supplied remote control. Plug the fireplace into a 15 Amp wall socket. MANUAL OPERATION 1. The main power ON/OFF switch in position O, the fireplace is OFF. 2. -
Page 17: Remote Control Operation
REMOTE CONTROL OPERATION For remote to function make sure the heater is plugged in and main power switch located on the bottom left hand side is at position I. When operating the remote make sure you point the remote to the centre of the fireplace and make sure each time you press the button the buzzer inside the unit will beep once. -
Page 18: Installing Wall Thermostat
INSTALLING WALL THERMOSTAT WALL THERMOSTAT WIRING DIAGRAMS NOTE: THE WALL THERMOSTAT WILL WOKING WHEN THE HEATER ON TEMP. SETTING.PLEASE REEFER TO THE MANUAL CONTROL AND THE REMOTE CONTROL. Wire the wall thermostat prior to installing the fireplace. WALL THERMOSTAT WIRING(24 VAC) Install Wall Thermostat per instructions provided with kit and per the following information: 1. -
Page 19: Replacement Parts
REPLACEMENT PARTS PART NUMBER QTY. WM-FM-26- WM-FM-34- WM-FM-48- WM-FM-60- WM-FM-72- WM-FM-88- DESCRIPTION 3623-BG 4423-BG 5823-BG 7023-BG 8123-BG 10023-BG FIREPLACE BOX 301506 REMOTE RECEIVER 601092C CIRCUIT BOARD 10104010 SWITCH 601036 CONTROL PANEL TOP PANEL 602082 BLOWER AND HEATER ASSEMBLY 1070117 1070117 1070117 1070117 BACK BLACK PLASTIC GLASS... -
Page 20: Exploded View
EXPLODED VIEW... -
Page 21: Truble Shooting
TRUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Dim or no flame Flame LED’s are burnt out Inspect the LED’s and replace them if necessary. Ember Ember LED’s are burnt out Inspect the ember bed LED’s and glowing or dimming replace them if necessary. Appliance turns off and Appliance has overheated and Turn off the main switch, allow... -
Page 22: Service History
SERVICE HISTORY This heater must be serviced annually depending on usage. Date Dealer Service technician Service Performed Special Concerns Name Name NOTES:...
