Getting Acquinted With The Screen - Wavetek MS1200 Operation Manual

SNAP SHOT
Hold the measurement. The measurement is retained even
if the cable is disconnected from the input.
CLEAR
Clear-out your entry and start over again.
BACKLIGHT ON/OFF
Quickly turn the backlight on when it is too dark to see the
display.
POSITIVE/NEGATIVE
Enter positive and negative values (when allowed).
HELP
View a description of each icon found in the current soft
key menu.
PRINT
Print a measurement screen, installation report, or
configuration report to a serial printer.
Note:
The following secondary function is not available on the MS1200:
GETTING ACQUAINTED WITH THE SCREEN
There are certain elements of the screen that will become familiar
to you as you use your microStealth.
The Title Bar
Notice the title bar at the very top of the screen. It presents the title
and icon for the current mode you are using.
FILE
9
