PRINTING THE SCREEN

You can print the entire screen at any time by pressing the SHIFT
+ keys. A bar graph appears indicating the status of the printout.

SCAN

The MS1200 includes an additional SCAN mode that can display
up to six video carriers. You can access this mode by choosing the
icon from the NAVIGATOR.
Note
The channels that appear on this screen are the same ones that you
selected when you configured your tilt channels. (see SELECT
TILT CHANNELS).

MOVING THE MARKER

A vertical marker appears over the currently selected carrier. The
channel number, type and label appear in the upper right-hand
portion of the screen. The frequency and level of the selected
carrier can be seen directly beneath the graph. You can use the left
or right arrows to select the previous or next carrier.

ADJUSTING THE REFERENCE LEVEL

The reference level setting is displayed above the graph. This is
the level at the very top line. You can adjust the reference level
using the up and down arrows. When you press the SHIFT +
keys, your microStealth automatically sets the optimum reference
level for you.
41
