Factory Default
Sets all stored preferences to factory presets. Press the
key to initiate the default operation.
Important
All stored settings are lost when you perform this operation.
Test Display
Exercises all pixels on the LCD for test purposes. Re-
peated pressing of the
between all pixels "on", all pixels "off", and the display test
screen.

Measurements Configuration

SIGNAL LEVEL UNITS
Selects the units that will be used for all signal level measurements.
You can select between; dBmV, dBµV and dBm.
PROBE COMPENSATION
This can be used to compensate for losses associated with probe
points found on certain amplifiers. You can enter a value between
-99.9 and +99.9 dB. Probe compensation is added directly to signal
level measurements. The compensation value is indicated in the
upper left-hand corner of the measurement screens. There is no
indication, however, if the compensation value is zero.
Important
The PROBE COMPENSATION value does not affect INSTAL-
LATION or CHANNEL PLAN BUILD mode. Level measurements
made while checking an installation are uncompensated.
FREQUENCY TUNING STEP SIZE
This setting affects the increment/decrement step size when you
are tuning the frequency using the left and right arrows. You can
select a value between 25kHz and 100MHz in steps of 25kHz.
16
key sequences the display
